D236-90-5000-WH LED Disk Downlight

Product Information

The LED Disk Light is a high-quality lighting fixture that
provides efficient and reliable illumination. It is available in
two models with different wattage and lumen output:

• Model: D236-90-5000-WH, SKU#: 1550458, 15W, 1300Lm
• Model: D228-20W-90-5000-WH, SKU#: 1550459, 20W, 1600Lm

The LED Disk Light features a 6-inch or 8-inch white housing and
has a color temperature of 5000K, providing cool white light. It
operates at an input voltage of 120V and supports TRIAC dimming.
The light is UL and ES certified for safety.

Specifications

Product Usage Instructions

Installation (SKU #: 1550458)

To install the LED Disk Light using surface mount:

1. Ensure all electrical connections are in accordance with local
   and national electrical code standards.
2. Disconnect the main power at the fuse or circuit breaker before
   installing or servicing the fixture.
3. Follow the specific assembly and installation instructions
   provided for IC/AT fixture or retrofit assembly.
4. For IC/AT fixtures, the light is intended for use in suspended
   ceilings with or without insulation.
5. For retrofit installation, follow the provided instructions for
   both incandescent and LED housings.

Recommended Dimmers for LED Housings

The following dimmer models from Lutron and Leviton are
recommended for use with LED housings:

• Lutron: DVCL-153P-WH, MACL-153M-WH, S-600PR-WH, SPSLV-600-WH,
  DVLV-603P-IV, MALV-600-IV, MALV-600, DVW-603PGH-WH, 4X603,
  CTCL-153P, SLV-600P-WH, DVW-603P6H-WH, CT-603PG, NT-1000, S-603P,
  DV-600P, RA-6D
• Leviton: 6683, 6672, 6631, 6633-P, 1A2305, OB33K1

Please refer to the complete user manual for detailed
instructions and additional information.

LED DISK LIGHT

LED DISK LIGHT

UL R
Our LED Disk Light makes it simple to switch your current illuminaon to energy-saving LED technology. Our LED Disk Lights provide adaptable lighng on standard line voltage while yet maintaining the excellent energy savings.Disk Light makes it simple to switch from tradional recessed cans to a more modern, energy-efficient opon. With the oponal hardware mounng adapter, it may be easily installed on a juncon box or retrofied into an exisng recessed can (not included). Our LED Disk Lights are ideal for general lighng in motels, hotels, commercial buildings and homes.

Product Features
· Quick, easy installaon · Dimmable and frosted lens · Suitable for Damp Locaons · Available in 6″ and 8″ · Dry and Damp locaon rated

· DOB (driver on board) technology, Without capacitor, No buzz problem
· Suitable for Surface Mount and Retrofit · UL and Energy Star approved · Steel smooth trim with elegant design · 5 Year Warranty

1

LED DISK LIGHT

LED DISK LIGHT

SKU #

Model #

Wa

1550458 D236-90-5000-WH 15W

1550459 D228-20W-90-5000-WH 20W

Lumens 1300Lm 1600Lm

CCT 5000K

Size Housing 6 Inch White

Input Voltage
120V

Dimming Cerficaons TRIAC UL & ES

5000K 8 Inch White 120V TRIAC UL & ES

SKU Number 1550458

Specificaons

Parameter
General Performance
Electrical
Physical Qualificaon

Descripon
Model # Waage Lumen Lumen Efficacy Color Temperature CRI (Ra) Beam Angle Diffuser Type Input Voltage Frequency Dimming Power Factor Driver Surge Protecon Operang Temperature Operang Humidity Storage Temperature Storage Humidity LED Brand LED Type LED QTY Housing Housing Color IP Rang Warranty

D236-90-5000-WH 15W 1300LM Up to 82LM/W 5000K >90 120 Degree PC 120Vac 50/60Hz TRIAC 0.9 2.5KV -20 ± 40 20% – 90% -30oC – 80oC 10% – 95% HONGLI SMD2835 33PCS Metal White IP43 5 Years Warranty

Value

2

LED DISK LIGHT

LED DISK LIGHT

SKU Number 1550459

Specificaons

Parameter
General Performance
Electrical
Physical Qualificaon

Descripon
Model # Waage Lumen Lumen Efficacy Color Temperature CRI (Ra) Beam Angle Diffuser Type Input Voltage Frequency Dimming Power Factor Driver Surge Protecon Operang Temperature Operang Humidity Storage Temperature Storage Humidity LED Brand LED Type LED QTY Housing Housing Color IP Rang Warranty

Value
D228-20W-90-5000-WH 20W 1600LM Up to 82LM/W 5000K >90 120 Degree PC 120Vac 50/60Hz TRIAC 0.9 2.5KV -20 ± 40 20% – 90% -30oC – 80oC 10% – 95% HONGLI SMD2835 66PCS Metal White IP43 5 Years Warranty

3

LED DISK LIGHT
Correlated Color Temperature (CCT)

5000K

Cool White
Natural White

Warm White

Dimensions

6″

8″

LED DISK LIGHT

4

LED DISK LIGHT
Photomatric Data (SKU #: 1550458)
4.1 Spectral Distribution

LED DISK LIGHT

4.2 ANSI Chromaticity Quadrangles Diagram

Graphical representations of 7-step quadrangle specification of SSL products

0.46

CIE 1931 x, y diagram
0.44

2200K

0.42

0.40

0.38
y
0.36

0.34

Planckian locus

0.32

Center Point

0.30

Measured x,y

0.28 0.28 0.30 0.32 0.34 0.36 0.38 0.40 0.42 0.44 0.46 0.48 0.50 0.52 0.54
x

5

LED DISK LIGHT

LED DISK LIGHT
Goniophotometer Test (SKU #: 1550459) Light Distribuon Curve
Isolux Plot
6

LED DISK LIGHT

LED DISK LIGHT

Installaon (SKU #: 1550458)

6″ LED DISK LIGHT INSTALLATION INSTRUCTIONS
SURFACE MOUNT

Please read carefully and save these instrucons, as you may need them at a later date.
GENERAL: ALL ELECTRICAL CONNECTIONS MUST BE IN ACCORDANCE WITH LOCAL AND NATIONAL ELECTRICAL CODE (N.E.C.) STANDARDS. IF YOU ARE UNFAMILIAR WITH PROPER ELECTRICAL WIRING CONNECTIONS OBTAIN THE SERVICES OF A QUALIFIED ELECTRICIAN.

WARNING – RISK OF ELECTRIC SHOCK. DISCONNECT MAIN POWER AT FUSE OR CIRCUIT BREAKER BEFORE INSTALLING OR
SERVICING THE FIXTURE.

WARNING- RISK OF FIRE OR ELECTRIC SHOCK
· DO NOT MAKE OR ALTER ANY OPEN HOLES IN THE ENCLOSURE TO THE WIRING OR ELECTRICAL COMPONENTS DURING KIT INSTALLATION. · TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR OTHER SHARP OBJECTS. · SUITABLE FOR WET LOCATIONS · SUITABLE FOR TYPE IC OR SUITABLE FOR TYPE NON-IC -USE ONLY IN OPEN LUMINAIRES · THIS DEVICE IS NOT INTENDED FOR USE WITH EMERGENCY EXITS

ASSEMBLY AND INSTALLATION
This IC/AT fixture is intended for use in suspended ceilings (with or without insulaon). Shut off power before installaon

· Prepare fixture for recessed installaon.(FIG.1) · Remove lens by twisng counter clockwise. (FIG.2) · Connect supply wires to wires on fixture with wire nuts or push wires into Quick Connector.Connect white to white , black to black,and copper wire to copper wire as grounding connecon.(FIG.3) · Arrange the wires into the back of the juncon box. · Align appropriate holes in the mounng fixture with the holes in the juncon box.Using 2 of the longer screws (either #6 or #8 screws depending on the size of the holes in your juncon box) aach the mounng fixture is flush with the ceiling. Do not over-ghten screws or fixture will not be ght to ceiling. (FIG.4) · Complete the installaon by turn lens clockwise to lock. (FIG.5)

7

LED DISK LIGHT

LED DISK LIGHT

Installaon (SKU #: 1550458)

6″ LED DISK LIGHT INSTALLATION INSTRUCTIONS RETROFIT

ASSEMBLY AND INSTALLATION

INCANDESCENT HOUSINGS
· Unscrew the WING NUT inside the CAN to detach the SOCKET BRACKET from the CAN. Disengage the SOCKET from the SOCKET BRACKET. (FIG. 2) · Thread the SOCKET ADAPTER into the SOCKET. (FIG. 3) · Place spring on mounng bracket and complete the installaon by twisng the lens on the light. (FIG. 4) · If using TORSION SPRINGS, squeeze both TORSION SPRING arms together and insert into the TORSION SPRING SLOTS (orplace spring on mounng bracket RECEIVER BRACKETS) of the CAN. (FIG. 5) · Tuck all wires into the CAN and carefully push the RETROFIT TRIM into CAN. (NOTE: To provide enough room in shallow cans, carefully posion SOCKET ADAPTER and SOCKET adjacent to the long side of the LED DRIVER prior to inserng the RETROFIT TRIM into the CAN.) (FIG. 5)

WARNING – RISK OF ELECTRIC SHOCK. DISCONNECT MAIN POWER AT FUSE OR CIRCUIT BREAKER BEFORE INSTALLING OR
SERVICING THE FIXTURE.

LED HOUSINGS
· Plug the FEMALE CONNECTOR of the RETROFIT TRIM onto the MALE CONNECTOR of the HALO HOUSING. (FIG. 5) · If using TORSION SPRINGS, squeeze both TORSION SPRING arms together and insert into the TORSION SPRING SLOTS (or RECEIVER BRACKETS) of the CAN. (FIG. 5) · Tuck all wires into the CAN and carefully push the RETROFIT TRIM into CAN. (NOTE: To provide enough room in shallow cans, carefully posion SOCKET ADAPTER and SOCKET adjacent to the long side of the LED DRIVER prior to inserng the RETROFIT TRIM into the CAN.) (FIG. 5) DIMMING
Dimming performance may depend on the dimmer, the dimmer range adjustment seng (for dimmers with brightness range adjustments), the wiring method, and/or the number of LED modules installed onto the dimmer circuit. For dimmer selecon, Dimming control manufacturers revise their product oen; for the latest list of compable dimmers please visit our website. For best results, it is recommended to install a minimum of four LED modules onto one dimmer. Before turning on the LED lights, set dimmer posion at maximum before adjusng to a lower light level. Please follow the dimming control manufacturer’s instrucons for the installaon of all dimming controls.

Following is a list of recommended dimmers:

Brand Model

Lutron
DVCL-153P-WH MACL-153M-WH
S-600PR-WH SPSLV-600-WH DVLV-603P-IV MALV-600-IV
MALV-600 DVW-603PGH-WH
4X603 CTCL-153P SLV-600P-WH DVW-603P6H-WH CT-603PG NT-1000
S-603P DV-600P RA-6D

Leviton 6683 6672 6631 6633-P 1A2305 OB33K1

8

LED DISK LIGHT

LED DISK LIGHT

Installaon (SKU #: 1550459) 8″ LED DISK LIGHT SURFACE MOUNT

Please read carefully and save these instrucons, as you may need them at a later date.
GENERAL: ALL ELECTRICAL CONNECTIONS MUST BE IN ACCORDANCE WITH LOCAL AND NATIONAL ELECTRICAL CODE (N.E.C.) STANDARDS. IF YOU ARE UNFAMILIAR WITH PROPER ELECTRICAL WIRING CONNECTIONS OBTAIN THE SERVICES OF A QUALIFIED ELECTRICIAN.
WARNING- RISK OF FIRE OR ELECTRIC SHOCK
· D0 NOT MAKE OR ALTER ANY OPEN HOLES IN THE ENCLOSURE TO THE WIRING OR ELECTRICAL COMPONENTS DURING KIT INSTALLATION. TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR OTHER SHARP OBJECTS. · SUITABLE FOR DAMP LOCATIONS · SUITABLE FOR TYPE IC OR SUITABLE FOR TYPE NON-IC USE ONLY IN OPEN LUMINAIRES THIS DEVICE IS NOT INTENDED FOR USE WITH EMERGENCY EXITS
ASSEMBLY AND INSTALLATION

WARNING – RISK OF ELECTRIC SHOCK. DISCONNECT MAIN POWER AT FUSE OR CIRCUIT
BREAKER BEFORE INSTALLING OR SERVICING THE FIXTURE

This IC/AT fixture is intended for use in suspended ceilings(with or without insulaon). Shut off power
BEFORE INSTALLATION Fix the bracekt to the juncon box with screws.(FIG.1) Connect supply wires to wires on fixture with wire nuts or push wires into Quick Connector.Connect white to white , black to black,and copper wire to copper wire as grounding connecon.(FIG.2) Arrange the wires into the back of the juncon box. · Push the fixture back to the ceiling and make sure the fixture secured in the bracket of juncon box.(FIG.3) · Complete the installaon by push the fixture into the ceiling. (FIG.4)

9

LED DISK LIGHT

LED DISK LIGHT

Installaon (SKU #: 1550459) 8″ LED DISK LIGHT RETROFIT

ASSEMBLY AND INSTALLATION
INCANDESCENT HOUSINGS
· Unscrew the WING NUT inside the CAN to detach the SOCKET BRACKET from the CAN. Disengage the SOCKET from the SOCKET BRACKET. · Thread the SOCKET ADAPTER into the SOCKET. (FIG. 2) · Install the Spring Hooks as FIG.5 (For 6 Inch Can) or FIG.6 (For 8 Inch Can) by using M3*8 self tapping screws. · Match the Male and Female Plugs and connect them frimly. (FIG. 3) Of using TORSION SPRINGS, squeeze both TORSION SPRING arms together and insert into the TORSION SPRING SLOTS (orplace spring on mounng bracket RECEIVER BRACKETS) of the CAN.(FIG. 4) · Tuck all wires into the CAN and carefully push the RETROFIT TRIM into CAN. (NOTE: To provide enough room in shallow cans, carefully posion SOCKET ADAPTER and SOCKET adjacent to the long side of the LED DRIVER prior to inserng the RETROFIT TRIM into the CAN.) (FIG. 4)

WARNING – RISK OF ELECTRIC SHOCK. DISCONNECT MAIN POWER AT FUSE OR CIRCUIT
BREAKER BEFORE INSTALLING OR SERVICING THE FIXTURE.

6 Inch/8 Inch FIG.1

FIG.2

LED HOUSINGS
· Plug the FEMALE CONNECTOR of the RETROFIT TRIM onto the MALE CONNECTOR of the HALO HOUSING. (FIG. 2) · Install the Spring Hooks as FIG.5 (For 6 Inch Can) or FIG.6 (For 8 Inch Can) by using M3*8 self tapping screws. · Match the Male and Female Plugs and connect them frimly. (FIG. 3) · If using TORSION SPRINGS, squeeze both TORSION SPRING arms together and insert into the TORSION SPRING SLOTS (or RECEIVER BRACKETS) of the CAN. (FIG. 4) · Tuck all wires into the CAN and carefully push the RETROFIT TRIM into CAN. (NOTE: To provide enough room in shallow cans, carefully posion SOCKET ADAPTER and SOCKET adjacent to the long side of the LED DRIVER prior to inserng the RETROFIT TRIM into the CAN.) (FIG. 4)

FIG.3 6 Inch

FIG.4 8 Inch

FIG.5

FIG.6

DIMMING
Dimming performance may depend on the dimmer, the dimmer range adjustment seng (for dimmers with brightness range adjustments), the wiring method, and/or the number of LED modules installed onto the dimmer circuit. For dimmer selecon, Dimming control manufacturers revise their product oen; for the latest list of compable dimmers please visit our website. For best results, it is recommended to install a minimum of four LED modules onto one dimmer. Before turning on the LED lights, set dimmer posion at maximum before adjusng to a lower light level. Please follow the dimming control manufacturer’s instrucons for the installaon of all dimming controls.

10

LED DISK LIGHT
Easy to Install in 2 ways

LED DISK LIGHT

Packaging

Size

Carton Size (Inches)

6″

15.94 x 13.38 x 8.346

8″

18.11 x 10.32 x 10.62

Pcs/Carton 1 /6 / 12 1 /4 / 8

Net Weight 9.92 LBS 13.22 LBS

Gross Weight 11.02 LBS 14.33 LBS

Warranty
5 Years Warranty

11

Applicaon

LED DISK LIGHT

LED DISK LIGHT

12
