Uz Cxx172 Electronic Door Handle Instruction Manual

• The square pin must be assembled before installation on the
  electronic door handle (outside).
• Insert the adapter sleeve into the square holder (if
  required).
• Insert the square onto the retaining pin and into the square
  holder.
• Insert the spiral clamping pin into the square.

• Remove the two screws that hold the adapter in place.
• Rotate adapter to adjust to the required position.
• Put adapter back and fix screws.

• Insert the square pin of the electronic door handle into the
  square nut of the lock.
• Insert the mechanical door handle from the other side keeping
  it in a horizontal position.
• Use mounting screws from the mechanical side to attach handle
  to door.
• Check horizontal position and functionality.
• If necessary, remove handles again and adjust to a different
  position.

Clex Electronic door handle
Adapter for Scandinavian doors
Assembly manual

CLEX ELECTRONIC DOOR HANDLE

ASSEMBLY

Imprint Clex Electronic door handle ­ Adapter for Scandinavian doors Assembly manual (original version)
Document number: 12CD Version: 1.0 Status: 10.05.2022
Manufacturer Uhlmann & Zacher GmbH Gutenbergstr. 2­4 97297 Waldbuettelbrunn Germany Tel.: +49 931 40672-0 E-Mail: [email protected] http://www.UundZ.com
This operating and assembly manual is copyright protected. The information contained this manual should not be reproduced, distributed or used for competitive purposes or shared with third parties. It is likewise forbidden to manufacture any component using this manual without prior written consent.
2

CLEX ELECTRONIC DOOR HANDLE

ASSEMBLY

1 Assembly
This document does only cover the assembly in combination with the adapter plate for Scandinavian doors. It does not replace the regular operating and assembly manual. Please consult the regular operating manual for all other product related questions.

1.1 General assembly instructions
CAUTION
The cover of the electronic door handle can be damaged if the mounting screws are too long!
Tighten the mounting screws with a torque of 2 Nm.
If a cylinder holder is present in the door, then it should be sealed properly, for e.g. using a dummy cylinder.
Carry out the assembly with the door open. Ensure that the latches or seals fitted to the door do not hinder the proper
operation of the product. Ensure that the door handle does not protrude and prevent the door from
swinging freely. The hole in the door for inserting the handle pin should have a diameter of at
least 25 mm. Before assembling the door handle, always check whether all the components
can move freely. After assembly, check the function with the door open. The pre-tension in the mortise lock or the deviation of the horizontal basic
position must not exceed 3°. If the deviation is greater, the electronic lever handle cannot engage and disengage

3

CLEX ELECTRONIC DOOR HANDLE

ASSEMBLY

1.2 Assembling the square pin
The square pin has to be assembled before installation on the electronic door handle (outside). This applies to all the versions and is shown here using an example of the circular rosette version.

1
2 3 4
1 Electronic door handle (Scandinavian version different. Picture shows regular product)
2 Spiral clamping pin 3 Square 4 Adapter sleeve for square (only for 7 mm square)

Insert the adapter sleeve into the square holder (if required) Insert the square onto the retaining pin and into the square holder Insert the spiral clamping pin into the square
4

CLEX ELECTRONIC DOOR HANDLE
1.2.1 Adapter adjustment Remove the two screws that hold the adapter in place

ASSEMBLY

Remove adapter

Rotate adapter to adjust to required position Available positions:
5

CLEX ELECTRONIC DOOR HANDLE

ASSEMBLY

Put adapter back and fix screws Insert the square pin of the electronic door handle into the square nut of the
lock. Insert the mechanical door handle from the other side keeping it in a
horizontal position Use mounting screws from the mechanical side to attach handle to door Check horizontal position and functionality If necessary remove handles again and adjust to different position

6
