MBTAMBABKSA Tamba Bookshelf

TAMBA BOOKSHELF

Model Number: MBTAMBABKSA

Components

• Leg (x2)
• Shelf (x4)
• Pole (x4)
• (16x6mm) Allen Bolt (x24)
• (16x8mm) Washer (x24)
• Allen Key (4mm)
• (10x6mm) Allen Bolt (x4)

Assembly Instructions

1. Attach the legs (1), poles (3), and shelves (2) together by
   lining everything up with the existing holes.
2. Insert the 16x6mm Allen Bolts (4) through the holes and secure
   them with the 16x8mm Washers (5).
3. Use the Allen Key (6) to tighten the bolts securely.
4. Attach the remaining poles using the 10x6mm Allen Bolts
   (7).
5. Gently lift the Bookshelf and place it upright on a level
   surface.

The assembly is now complete!

Notes

If you need additional information or assistance, please visit
help.mattblatt.com.au for the most up-to-date guide for your
product.

TAMBA BOOKSHELF
MBTAMBABKSA

COMPONENTS

1 Leg (x2)

2 Shelf (x4)

3 Pole (x4)

4 (16x6mm) Allen Bolt (x24) 5 (16x8mm) Washer (x24)

6 Allen Key (4mm)

7 (10x6mm) Allen Bolt (x4)

ASSEMBLY
Step 1: Attach the legs (1), poles (3) and shelves (2) together, lining everything up with the existing holes.

Step 2: · Secure the shelves (2) to the legs (1) using the 16×6 bolts (4) and washers (5). · Secure the four poles (3) to the legs (1) using the 10×6 bolts (7).
4 Allen Bolt (x24) 5 Washer (x24) 6 Allen Key 7 Allen Bolt (x8)

Step 3: Gently lift the Bookshelf and place it upright on a level surface.
Complete!

NOTES

NEED MORE INFORMATION?
We hope that this user guide has given you the assistance needed for a simple set-up. For the most up-to-date guide for your product, as well as any additional assistance you may require, head online to help.mattblatt.com.au
