2013 RWD L4-2.0L Instrument Panel Fuse Block
Product Information:
The 2013 Cadillac ATS Sedan RWD L4-2.0L Turbo Vehicle has an
Instrument Panel Fuse Block located at the end of the driver side
of the instrument panel. It contains various fuses, circuit
breakers, and relays that control different electrical components
of the vehicle.
Fuses:
- Fuse 20 – Not Used
- Fuse 21 – Not Used
- Fuse 22 – Logistics Shunt 2
- Fuse 23 – Not Used
- Fuse 24 – Not Used
- Fuse 25 – Not Used
- Fuse 27 – RAP Relay
- Fuse 28 – Front Heater, Ventilation, and Air Conditioning
Blower - Fuse 29 – Power Steering Column
- Fuse 30 – Not Used
Circuit Breakers:
- CB7 – Not Used
- CB26 – Not Used
Relays:
- Relay K10 – RAP/Accessory
- Relay K605 – Logistics
- Relay K609 – Not Used
Please note that your specific vehicle may not be equipped with
all of the fuses and relays mentioned above.
Product Usage Instructions:
To access the fuses in the instrument panel fuse block:
- Remove the end panel by gently prying with a plastic tool near
each clip, starting at the indicated point. - To install the end cover, insert the tabs on the back of the
cover into the slots in the instrument panel at the indicated
points. - Align the clips with the slots in the instrument panel and
press the cover into place.
It is important to keep the covers on any electrical component
to prevent damage. Avoid spilling liquid on any electrical
component as it may cause damage.
2013 Cadillac ATS Sedan RWD L4-2.0L Turbo Vehicle > Power and Ground Distribution > Fuse > Locations > Components
INSTRUMENT PANEL FUSE BLOCK – OWNERS MANUAL
INSTRUMENT PANEL FUSE BLOCK The instrument panel fuse block is in the end of the driver side of the instrument panel.
To access the fuses, remove the end panel by gently prying with a plastic tool near each clip, beginning at the point shown.
To install the end cover, insert the tabs on the back of the cover into the slots in the instrument panel at the points shown. Align the clips with the slots in the instrument panel, and press the cover into place.
The vehicle may not be equipped with all of the fuses and relays shown.
Notice: Spilling liquid on any electrical component on the vehicle may damage it. Always keep the covers on any electrical component.
NUMBER ……………….. USAGE Fuse 1 ……………….. Not Used Fuse 2 ……………….. Data Link Connector Fuse 3 ……………….. Not Used Fuse 4 ……………….. Not Used Fuse 5 ……………….. Heater, Ventilation, and Air Conditioning Control Fuse 6 ……………….. Electric Steering Column Lock Fuse 8 ……………….. Battery Fuse 9 ……………….. Heated Steering Wheel Fuse 10 ……………….. Not Used Fuse 11 ……………….. Logistics Shunt 1 Fuse 12 ……………….. SDM/AOS Fuse 13 ……………….. Cluster/HUD/ICS/Steering Wheel Controls Fuse 14 ……………….. Radio/Heater, Ventilation, and Air Conditioning Fuse 16 ……………….. Not Used Fuse 17 ……………….. Accessory Power Outlet 1 Fuse 18 ……………….. Accessory Power Outlet 2 Fuse 19 ……………….. Steering Wheel Controls
Fuse 20 ……………….. Not Used Fuse 21 ……………….. Not Used Fuse 22 ……………….. Logistics Shunt 2 Fuse 23 ……………….. Not Used Fuse 24 ……………….. Not Used Fuse 25 ……………….. Not Used Fuse 27 ……………….. RAP Relay Fuse 28 ……………….. Front Heater, Ventilation, and Air Conditioning Blower Fuse 29 ……………….. Power Steering Column Fuse 30 ……………….. Not Used
CIRCUIT BREAKERS ……………….. USAGE CB7 ……………….. Not Used CB26 ……………….. Not Used
RELAYS ……………….. USAGE Relay K10 ……………….. RAP/Accessory Relay K605 ……………….. Logistics Relay K609 ……………….. Not Used
