Wireless Barcode Scanner
User Manual
Introduction
A wireless barcode scanner transfers the data to a computer via the receiver.
If the scanner & receiver need to re-pair, scan the “Pairing Function”.
LED Description
Red
- Charging: Light on
- Charging finished: Light off
Green - Slow flash: Scanner is not connected to receiver or USB
- Flash: Scanner is connected to receiver or USB
- Quick flash: Entering the pairing mode
- Flash once: Data upload successfully
Buzzer Description
- Long & high beep: Switch on
- Twice high & low beeps: Switch off, setup code or decode success
- A medium-long & high beep: good scan or pairing up the receiver
- Three continuous short beeps: Alarm prompt
Default Setting
Note: With (*) is the factory default.
Data Transfer Mode
 |  |
Note: Automatic storage mode. Data is automatically saved in the scanner when exceeds communication distance, scan the “Upload all data” code to complete the data transfer.
Note: Inventory mode, the scanned barcode will be automatically saved in the scanner. If the data need to be viewed or uploaded, then scan the “Upload all data” code to complete the data transfer.
 |  |
Note: Clear all data can be effective under Inventory mode & Automatic Storage mode.
USB Interface Type
 |  |
Note: The USB interface type of both scanner and receiver will be changed.
Below is for Bluetooth scanners only. The device named: BarCode Bluetooth HID
Wireless Bluetooth Setting
 |  |  |
Note: Scan the Bluetooth code change to Bluetooth mode. When the scanner is restored, for Bluetooth mode scan the code again.
Bluetooth HID transmission rate
 |  |  |
IOS show/hide the Keyboard
(Under Bluetooth mode)
Pairing Function
Pairing Function
Note: Scan this code, scanner will enter the automatic pairing mode for 1 minute, then re-insert the receiver. There will be a sound heard when pairing successfully.
For Bluetooth pairing setting, search by Bluetooth device
Battery Display
Note: Percentage display
 |  |  |
 |  |  |
Sleeping Settings (2 Types)
Different Sleeping time Choices
 |  |
 |  |
 |  |
 |  |
Language Settings
Terminator
 |  |  |
 |  |
Display Version
