SD1 Ultrasonic Pocket Doppler

SD1 Ultrasonic Pocket Doppler User Manual

CAUTION: Federal (U.S.) Law restricts this
device to sale by or on the order of a physician.

NOTE: This user manual is written to cover the
maximum configuration. Therefore, your model may or may not have
some of the parameters and functions described, depending on what
you have ordered.

This unit is internally powered equipment, and it is an IEC/EN
60601-1 Type BF applied part. Type BF protection means that the
connection between the equipment and personnel complies with
permitted leakage currents and dielectric strength of IEC/EN
60601-1. WARNING and CAUTION
messages must be observed. To avoid the possibility of injury,
observe the following precautions during the operation of the
device.

WARNING: It is to be used by health care
professionals on the order of a physician.
WARNING: The Doppler is a tool to aid the
healthcare professional in hospitals, clinics and should not be
used by untrained personnel.
CAUTION: Refer servicing to qualified
personnel.
CAUTION: Keep the device in a clean
environment and avoid vibration during storage.
CAUTION: Do not sterilize the Doppler.
CAUTION: Electromagnetic Interference – Ensure
that the environment in which the device is operated is free from
electromagnetic interference.
Inspect the equipment for mechanical and functional
damage.
Inspect the safety relevant labels for legibility.

Introduction

Intended Use/Indications for Use: The SD1 is a
pocket Doppler device used for detecting the fetal heartbeat from
the 10th week of gestation. It is intended to be used by medical
professionals only.

Features

FHR detection and display
FH sound
Switching off when no signal received for 2 Min
Sound volume adjustment
Bluetooth connection (Optional)
FH signal intensity indicator
FH icon
Battery indicator
Low battery warning
Sound volume levels

Appearance

Above pictures are just for reference

LCD Screen
Loudspeaker
Touch Keys
Screw
Battery Compartment Cover
Ultrasonic Transducer Head

LCD Display& Touch Keys

Item	Description
Fetal heart icon	Indicates fetal heart beat and flickers to the fetal heart beat.
Fetal heart signal intensity indicator	This indicator displays on the left side of the screen and has three status: empty, half empty and full, which respectively represents low, medium and high fetal heart signal intensity.
FHR numeric	Displays fetal heart rate within the range from 50 bpm to 240 bpm. When fetal heart rate is out of the range, it displays —.
Sound volume numeric	Sound volume numeric is displayed in the center of the screen, the same area as the FHR numeric. When you adjust sound volume, the sound volume numeric will display for 0.5 second before switching back to display FHR numeric. Sound volume ranges from level 0 to 7.
Battery indicator	Battery indicator displays on the right side of the screen. There are 5 battery levels, represented by 0 to 4 panes in the icon. When battery is empty, battery empty icon will be displayed and flickering, and the battery needs replacing.
Sound volume increase touch key	Touch the key to increase sound volume.
Sound volume decrease touch key	Touch the key to decrease sound volume.
On/Off touch key	Touch the key to turn on/off the device.

Product Usage Instructions:

Before using the SD1 Ultrasonic Pocket Doppler, inspect the
equipment for mechanical and functional damage and safety relevant
labels for legibility.
Keep the device in a clean environment and avoid vibration
during storage.
Do not sterilize the Doppler.
Ensure that the environment in which the device is operated is
free from electromagnetic interference.
The SD1 is a pocket Doppler device used for detecting the fetal
heartbeat from the 10th week of gestation. It is intended to be
used by medical professionals only.
The FH signal intensity indicator displays on the left side of
the screen and has three status: empty, half empty, and full, which
respectively represents low, medium, and high fetal heart signal
intensity.
The FHR numeric displays fetal heart rate within the range from
50 bpm to 240 bpm. When fetal heart rate is out of the range, it
displays —.
The sound volume numeric is displayed in the center of the
screen, the same area as the FHR numeric. When you adjust sound
volume, the sound volume numeric will display for 0.5 second before
switching back to display FHR numeric. Sound volume ranges from
level 0 to 7.
The battery indicator displays on the right side of the screen.
There are 5 battery levels, represented by 0 to 4 panes in the
icon. When the battery is empty, the battery empty icon will be
displayed and flickering, and the battery needs replacing.
Touch the key to increase or decrease sound volume as
needed.
Touch the On/Off key to turn on/off the device.

View Fullscreen

SD1 Ultrasonic Pocket Doppler User Manual
About this Manual P/N: 01.54.458123 Version 1.5 MPN: 01.54.458123015 Release Date: Mar. 2023 Statement This manual will help you understand the operation and maintenance of the product better. It is reminded that the product shall be used strictly complying with this manual. User’s operation failing to comply with this manual may result in malfunction or accident for which the manufacturer cannot be held liable. The manufacturer owns the copyrights of this manual. Without prior written consent of the manufacturer, any materials contained in this manual shall not be photocopied, reproduced or translated into other languages. Materials protected by the copyright law, including but not limited to confidential information such as technical information and patent information are contained in this manual, the user shall not disclose such information to any irrelevant third party. The user shall understand that nothing in this manual grants him, expressly or implicitly, any right or license to use any of the intellectual properties of the manufacturer. The manufacturer holds the rights to modify, update, and ultimately explain this manual. Responsibility of the Manufacturer The manufacturer only considers itself responsible for any effect on safety, reliability and performance of the equipment if: Assembly operations, extensions, re-adjustments, modifications or repairs are carried out by persons authorized by the manufacturer, and The electrical installation of the relevant room complies with national standards, and The instrument is used in accordance with the instructions for use. The manufacturer will make available on request circuit diagrams, component part lists, descriptions, calibration instructions, or other information that will assist service personnel to repair those parts of the equipment that are designated by the manufacturer as repairable by service personnel. Product Information Product Name: Ultrasonic Pocket Doppler Model:SD1 Terms Used in this Manual This guide is designed to give key concepts on safety precautions. WARNING AWARNING label advises against certain actions or situations that could result in personal injury or death. CAUTION A CAUTION label advises against actions or situations that could damage equipment, produce inaccurate data, or invalidate a procedure. NOTE A NOTE provides useful information regarding a function or a procedure. Safety Precautions
CAUTION Federal (U.S.) Law restricts this device to sale by or on the order of a physician.
NOTE: This user manual is written to cover the maximum configuration. Therefore, your model may or may not have some of the parameters and functions described, depending on what you have ordered.
This unit is internally powered equipment, and it is an IEC/EN 60601-1 Type BF applied part. Type BF protection means that the connection between the equipment and personnel complies with permitted leakage currents and dielectric strength of IEC/EN 60601-1. WARNING and CAUTION messages must be observed. To avoid the possibility of injury, observe the following precautions during the operation of the device.
WARNING 1 It is to be used by health care professionals on the order of a physician. 2 The Doppler is a tool to aid the healthcare professional in hospitals, clinics and should not be
used in place of normal fetal detection. It is not intended for treatment or use during labor and delivery. 3 Placement of the ultrasound transducer on the abdomen is critical to obtaining the fetal heart beat as opposed to maternal heart beat or other abdominal noise. The user should be trained in proper placement techniques either through acceptable Ob/Gyn training and individual state accreditation, or as being prescribed by such a trained clinician and trained in device placement. 4 This device is not explosion-proof and cannot be used in the presence of flammable anesthetics. 5 Magnetic and electrical fields are capable of interfering with the proper performance of the device. For this reason, make sure that all external devices operated in the vicinity of this device comply with the relevant EMC requirements. X-ray equipment and magnetic resonance imaging (MRI) devices can emit high levels of electromagnetic radiation. 6 We recommend that exposure to ultrasound should be kept as low as reasonably achievable. This is considered to be good practice and should be observed at all time. 7 Do not use the device with HF surgical equipment and do not use it in an MRI environment. 8 The device is not protected against defibrillation. 9 SHOCK HAZARD – Do not attempt to replace batteries with wet hands. 10 The device should not be used adjacent to or stacked with other equipment and that if adjacent or stacked use is necessary, the device should be observed to verify normal operation in the configuration in which it will be used. 11 The medical electrical equipment needs to be installed and put into service according to the EMC Information provided in this user manual. 12 Portable and mobile RF communications equipment can affect medical electrical equipment; refer to section Recommended Separation Distances. 13 Do not service or maintain the device or any accessory which is in use with a patient.

CAUTION 1 Refer servicing to qualified personnel. 2 Keep the device in a clean environment and avoid vibration during storage. 3 Do not sterilize the Doppler. 4 Electromagnetic Interference – Ensure that the environment in which the device is operated is
not subject to any source of strong electromagnetic emissions, such as radio transmitters, mobile telephones, etc. 5 Prior to examination using the Doppler, check for visible damages of the main unit and the probe that may endanger the patient/operator or machine performance. If the damage is found, replace them with good ones at once. 6 The following safety checks should be performed once every two years or as specified in the institution’s test and inspection protocol by a qualified person who has adequate training, knowledge, and practical experience to perform these tests.
Inspect the equipment for mechanical and functional damage. Inspect the safety relevant labels for legibility. Inspect the equipment for mechanical and functional damage. Inspect the safety relevant labels for legibility.
The leakage current should never exceed the limit. The data should be recorded in an equipment log. If the device is not functioning properly or fails any of the above tests, the device has to be repaired. 7 The device and accessories are to be disposed of according to local regulations after their useful lives. Alternatively, they can be returned to the dealer or the manufacturer for recycling or proper disposal. Batteries are hazardous waste. Do NOT dispose them together with house-hold garbage.
Introduction

Intended Use/Indications for Use

The SD1 is a pocket Doppler device used for detecting the fetal heartbeat from the 10th week of

gestation. It is intended to be used by medical professionals only.

Features FHR detection and display FH sound Switching off when no signal received for 2 Min Sound volume adjustment Bluetooth connection (Optional)

FH signal intensity indicator FH icon Battery indicator Low battery warning Sound volume levels

AppearanceAbove pictures are just for reference

LCD Screen

Loudspeaker

Touch Keys

Screw

Battery Compartment Cover

Ultrasonic Transducer Head

LCD Display& Touch Keys

Item

Description

Fetal heart icon

Indicates fetal heart beat and flickers to the fetal heart beat.

Fetal heart

signal intensity

indicator

This indicator displays on the left side of the screen and has three status: empty, half empty and full, which respectively represents low, medium and high fetal heart signal intensity.

FHR numeric

Displays fetal heart rate within the range from 50 bpm to 240 bpm. When fetal heart rate is out of the range, it displays “—“.

3
Sound volume numeric

Battery indicator

Sound volume

increase touch

key

Sound volume

decrease touch

key

On/Off touch key

Sound volume numeric is displayed in the center of the screen, the same area as the FHR numeric. When you adjust sound volume, the sound volume numeric will display for 0.5 second before switching back to display FHR numeric. Sound volume ranges from level 0 to 7.
Battery indicator displays on the right side of the screen. There are 5 battery levels, represented by 0 to 4 panes in the icon. When battery is empty, battery
empty icon will be displayed and flickering, and the battery needs replacing.
Touch the key to increase sound volume.
Touch the key to decrease sound volume.
When the Doppler is off, touch this key for a little while to switch it on; When the Doppler is on, touch this key for a little while to switch it off.

Battery

SD1 is powered by two AA alkaline batteries. Battery specification: LR6, AA, 1.5 V;

Note:

You can use AA alkaline batteries of the same specification purchased locally.

Basic Operation

NOTE: To ensure that the Doppler works properly, please read this chapter and Chapter Safety Precautions before operation; follow the steps when connecting all the components. Opening the Package and Checking Open the package; take out the Doppler and accessories carefully. Keep the package for possible future transportation or storage. Check the components according to the packing list. Check for any mechanical damage. Check all the cables and accessories. If there is any problem, contact us or your local distributor immediately. Installing the Battery a) Unscrew the screw with a cross screwdriver and remove the battery compartment cover. b) Insert the battery into the compartment carefully. Ensure its anode and cathode terminals are aligned
with the anode and cathode marks on the compartment. c) Install the compartment cover and secure it with the screw. Removing/ Replacing the Battery a) Unscrew the screw with a cross screwdriver and remove the battery compartment cover. b) Take out the used battery. You can also replace it with a new one. Ensure the new battery’s terminals
are placed in the right direction as indicated by the anode and cathode marks. c) Install the compartment cover and secure it with the screw.

WARNING 1 Turn off the Doppler before removing or replacing the battery. 2 Replace alkaline batteries with those of identical specifications provided by the
manufacturer or purchased locally. See Chapter Product Specifications for details about battery specifications. 3 If the batteries have been inserted incorrectly, the Doppler will not function or it will be damaged. 4 Do not disassemble or short-circuit batteries. 5 Do not recharge batteries. 6 Do not dispose of batteries in fire or water. 7 Do not allow metal objects to contact the battery terminals. 8 Do not mix with used or other battery type (such as alkaline with carbon zinc). 9 Do not solder the batteries directly. If soldering or welding connection to the battery is required, consult our engineer for proper methods. 10 Do not over-discharge batteries. 11 To install or remove batteries, follow the equipment manufacturer’s instructions. 12 Keep battery away from small children. If swallowed, consult a physician at once. 13 Store the battery in cool, dry place before use. Do not keep batteries at temperature of 45°C or above, or at humidity of 75% or above. 14 Dispose the battery according to the local regulations. Refer to IEC61429 for standard disposal when necessary. 15 Remove the battery and store it at a cool and dry environment if the Doppler is not used for a long time. 16 Batteries have life cycles. If the time that the Doppler using battery becomes much shorter than usual, the battery life is at an end. Replace the battery with a new one of the same specification as the one provided or recommended by the manufacturer.

Switching On

Touch the On/Off touch key for about 1second when the Doppler is off, and the Doppler will display the

switching on interface before switching to display the test interface

Switching Off

Touch the On/Off touch key for about 1second when the Doppler is on, and the Doppler will be switched

off.

If the Doppler is not in operation or no signal is received for 2 minutes, the Doppler will switch off automatically.

FHR Detection

Before applying the Doppler to inspect FHR, you should always check whether the Doppler is in good condition and whether there is evident damage that might affect patient’s safety and the device’s function. If evident damage is found, stop using it at once and replace it with a good one.

Procedures to Detect FHR:

a) Have the patient lie on her back.

b) Apply appropriate amount of coupling gel to the ultrasonic transducer head of

the Doppler and switch on the Doppler.

c) Palpate the patient’s abdomen gently to confirm the fetus’s position.

d) Place the Doppler on the patient’s abdomen, and move it around the fetus’s

position or tilt it until a clear and rhythmic heart sound is heard and FHR

numeric is stably displayed.

The coupling gel should not

Note:

exceed this limit.

1 Do not mistake the maternal heart rate for fetal heart rate. The fetal pulse should be different from the maternal

pulse, which can be measured at the wrist or neck. 2 Do not wear gloves to touch the keys. If there’s water and
coupling gel on the fingers, please clean them first or the

This area can be

touching effect will be influenced.

immerged in coupling gel

How to Find the Best FH Signal:

1) The easiest way: take the position the doctor last detected for FHR as a reference and move the

Doppler around the position slowly until the best FH signal is found.

2) The fetal heart position may change as the fetus moves inside the uterus. You can confirm the fetal

position first according to the position of the uterus fundus in different gestational weeks.

The clearest and loudest fetal heart sound is generally obtained when the Doppler is placed on the

fetus’s back. Fetal movement is usually the movement of fetal limbs. So, if frequent fetal movement

occurs at the right side of the abdomen, the fetus’s back is probably at the left side and vice versa. You

can find the fetus’s back according to fetal movement’s position.

If the fetus is in cephalic delivery position, the fetal heart is either on the right side or on the left side

below the navel; if the fetus is in breech delivery position, the fetal heart is either on the right side or on

the left side above the navel.

Steps to Find Fetal Heart:

Have the patient lie on back and relax >> confirm fetal position by hand >> apply coupling gel to the

Doppler>> place the Doppler on patient’s abdomen and start looking for the fetal heart >> the fetal heart

is found when the Doppler gives out a continuing thumping sound “boom-boom-boom”.

CAUTION 1 The Doppler’s degree of protection against harmful ingress of water is IP22. Do not immerse it
in water. 2 The Doppler is delicate and sensitive. Please handle it with care and try to avoid dropping on to
the ground or any hard surfaces. Any damage caused by dropping is not covered by the warranty. 3 Keep the coupling gel away from children. If swallowed, consult a physician at once.

Note: 1 The best quality of fetal heart signal is obtained only when the Doppler is placed on the best
detection position. 2 Do not place the Doppler near positions where placental sound or umbilical blood flow sound
is loud. 3 If the fetus is in the cephalic position and the mother is supine, the clearest heart sound will
normally be found on the midline below the navel. During detection, the pregnant woman’s prolonged lying in the supine position should be avoided to reduce the possibility of supine hypotension. Putting a pillow or cushion under the patient’s head or feet can be of help. 4 It is not possible to obtain accurate FHR unless a clear fetal heart signal is detected. If the calculated FHR is not in accordance with the beat of the fetal heart sound, the fetal heart sound auscultation result shall prevail. 5 When applied to the patient, the Doppler may warm slightly (less than 2°C (35.6°F) above ambient temperature). When NOT applied, the Doppler may slightly (less than 5°C (41°F) above ambient temperature).
After Detection
1) Switch off the Doppler.
2) Wipe the remaining gel off the patient and the probe with a clean soft cloth or tissue.

Mobile Application Software (APP)

SD1 can connect to mobile phones with its Bluetooth function (optional). The SD1 Care APP has both

Android and iOS versions.

iOS APP operating environment:

Android APP operating environment:

A) hardware environment

Processor: dual-core Apple A6 RAM: 1GB B) software environment: iOS 8.0 and above

CPU: frequency1.0GHz RAM: 1GB B)software environment: Android 4.3 and above

operating system

C)network environment: support Bluetooth

How to use SD1 Care APP

1. Download and install software

Scan either of the following QR codes to download the SD1Care APP, and install and run it as prompted.

Note:

1 Your mobile phone may prohibit the
installation of “applications from unknown sources”. Enter Settings to allow the installation first.

2 For normal functioning of the APP,

please give the APP function-related permissions.

3 For how to use the APP, read the

iOS Version

Android Version

instructions in the About sub-interface under the Settings

interface of the APP.

2. Activate the device

Open the APP and go to Settings>Activation and input SD1 activation code (14 numbers after 01).

3. Pair device

Open Bluetooth function of the mobile to automatically pair the SD1.

4. Start detection

Put the coupling gel on SD1 and position the probe to the optimal place of maternity’s abdomen. And

click the “start” key. After pressing start, confirm that the data on the APP and the SD1 probe

match. As with any Bluetooth communication, it is important to make sure the connection is not

compromised.

5. Adjust the fetal heart beat sound volume

When using mobile phone to play the fetal heart beat sound, you can adjust the volume with the volume

keys of the mobile phone. When using SD1 to play the heart beat sound, touch `volume+’ or `volume -‘ to

adjust the volume.

6. Finish the detection

When the detection is finished, click `Stop’ touch key and the detection data will be saved automatically.

Note: Please make sure your mobile phone has enough battery power,and avoid killing the process

directly or switching to other applications during the fetal heart detection.

7. Real time detection mode and DEMO mode

We provide DEMO mode for users’ reference. You can turn on DEMO key in Setup and enter fetal heart

detection interface to watch the DEMO. The word `DEMO’ is displayed in the interface to distinguish from

real time detection.

WARNING SD1 complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE:
1. This equipment (SD1) has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
2. Any changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Maintenance and Cleaning
Maintenance Before each use, check if the equipment has visible evidence of damage that may affect the patient and the operator’s safety or the Doppler’s functioning. If the damage is evident, contact the manufacturer for service or replace it. The overall check of the Doppler, including safety check and function check, should be performed by qualified personnel every 12 months, and each time after service. And safety check must include current leakage test and insulation test. Besides the above requirements, comply with local regulations on maintenance and measurement. The accuracy of FHR is determined by the Doppler and cannot be adjusted by user. If you have doubt concerning the accuracy of FHR, verify it with other methods such as using a stethoscope, or contact local distributor or the manufacturer for help. The Doppler is frangible and must be handled with care. Wipe the remaining gel off the Doppler after each use. These measures can help prolong the Doppler’s life. Replace the accessories such as the battery according to use. If any of the accessories are damaged, refer to chapter Ordering Information for details and order new ones. Please check the label for the date of manufacture, the service life is 5 years (The service life is limited to the Doppler, not including the replaceable accessories. The only replaceable accessory of SD1 is battery. The frequency of usage is 8 hours/day). Cleaning Before cleaning, switch off the Doppler. Keep the exterior surface of the device clean and free of dust and dirt. Clean the exterior surface of the Doppler with a dry, soft cloth. If necessary, clean it using a soft cloth dampened with mild near neutral detergent, ethanol (75%) or isopropanol (70%), and then wipe it dry with a dry cloth immediately.

CAUTION 1 Do not use strong solvent, such as acetone. 2 Never use an abrasive such as steel wool or metal polish. 3 The Doppler’s degree of protection against harmful ingress of water is IP22. Do not immerse it
in water. 4 Do not remain any solution on the surface after cleaning.

Disinfection In normal use the Doppler does not need disinfection. In case of being soiled, clean the main unit case and then disinfect it by wiping it with a soft cloth dampened with ethanol (75%) or isopropanol (70%). Then wipe it dry with a dry cloth.

CAUTION Do not immerse the Doppler into the disinfector.

Product Specifications

Product Information

Product Name

Ultrasonic Pocket Doppler

Model

SD1

Complied Standards

IEC 60601-1:2005/A1:2012, EN 60601-1:2006/A1:2013, IEC 60601-1-2:2014, IEC 60601-2-37:2015,IEC

61266:1994

Classification

Anti-electric Shock Type:

Internally powered equipment

Anti-electric Shock Degree:

Type BF equipment

Degree of Protection against Harmful Ingress of IP22. Protection against vertically falling water

Water:

drops when ENCLOSURE tilted up to 15°

Degree of Safety in Presence of Flammable Equipment not suitable for use in presence of

Gases:

flammable gases

Working System:

Continuous running equipment

EMC: Physical Specifications

CISPR 11 Group 1 Class B

Size:

Length*Width* Height: (48±2) mm× (39±2) mm× (147±3) mm

Weight:

< 180g

Size:

(24±2) mm× (13±2) mm

LCD:

Display:

FHR Battery level Signal intensity

Sound volume level FH icon

Coupling pH: 5.5~8.0

Gel:

Acoustic Impedance: 1.5×106 Pa.s/m ~1.7x106Pa.s/m (35°C/95ºF)

Environment

Working:

Temperature:+5°C ~ +40°C ( +41ºF ~ +104ºF) Humidity:15% RH ~ 95% RH(non-condensing) Atmospheric Pressure:70kPa ~ 106 kPa

Transport and Storage:

Temperature:-25°C ~ +70°C (-13ºF ~ +158ºF) Humidity:15% RH ~ 95% RH (non-condensing) Atmospheric Pressure:70 kPa ~106 kPa

Note: The time required for the Doppler to warm from the minimum storage temperature between

uses until it is ready for intended use is at least 2 hours; the time required for the Doppler to

cool from the maximum storage temperature between uses until it is ready for intended use is at

least 2 hours

Performance Specifications

FHR Measuring Range: 50 bpm ~ 240 bpm

FHR

(Essential Accuracy: ±2 bpm

Performance):

Note: FHR measurement result may not be accurate if the equipment is

measuring beyond its measuring range.

FHR Resolution:

1bpm

Audio Output: Auto Power-off: Bluetooth:

Output Power: 2w Background noise: <45dBA Power off when the Doppler receives no signal or operation for 2 minutes. Transmission Range (Without Obstacles) :>5m (Indoor range depends on the building’s structure and material.)

Nominal Frequency: 3MHz

Working Frequency: 3MHz

p_<1 MPa

Iob<10 mW/cm2

Ultrasound:

Ispta<100 mW/cm2 Isata<10 mW/cm2

Isppa.3<190 W/cm2

Ispta.3<94 mW/cm2

Effective Radiating Area: 490mm2 ± 15%

Working Mode: pulse wave

Battery Specifications

Specification:

Two AA 1.5V alkaline batteries (AA, LR6, 1.5V)

Working Duration:

Bluetooth Specifications

FCC ID

SMQSD1

Modulation:

GFSK

Frequency:

2400-2483.5MHz

Tolerance Frequency:

20ppm

RF output power:

20dBm (EIRP)

Occupied Channel Bandwidth: Transmitter Unwanted Emissions:

3MHz 30dBm

Low Output Summary Table

(For systems whose global maximum value does not exceed 1.0)

System: SD1 Ultrasonic Pocket Doppler

Model (MHz)

Ispta.3 (mW/cm2)

TI Type

TI Value

SD1 CD3.0

5.69

TIS TIB

0.05 0.01

0.01

Ordering Information

Isppa.3 (W/cm2)
0.02

CAUTION Only the parts supplied by the manufacturer should be used with the Doppler.

Parts Main Unit SD1 Doppler(Non-Bluetooth version)
SD1 Doppler(Bluetooth version)
Accessories AA Alkaline Battery Normal Carry Case Coupling Gel

Part Number
02.06.262535 02.06.262639
01.21.064086 01.56.466428 01.57.078170

Ultrasound Intensity and Safety

Ultrasound in Medicine The use of diagnostic ultrasound has proved to be a valuable tool in medical practice. Given its known benefits for non-invasive investigations and medical diagnosis, including investigation of the human fetus, the question of clinical safety with regards to ultrasound intensity arises. There is no easy answer to the question of safety surrounding the use of diagnostic ultrasound equipment. Application of the ALARA (As Low As Reasonably Achievable) principle serves as a rule-of-thumb that will help you to get reasonable results with the lowest possible ultrasonic output. The American Institute of Ultrasound in Medicine (AIUM) states that given its track record of over 25 years of use and no confirmed biological effects on patients or instrument operators, the benefits of the prudent use of diagnostic ultrasound clearly outweigh any risks. Ultrasound Safety and the ALARA Principle Ultrasound waves dissipate energy in the form of heat and can therefore cause tissue warming. Although this effect is extremely low with Doppler, it is important to know how to control and limit patient exposure. Major governing bodies in ultrasound have issued statements to the effect that there are no known adverse effects from the use of diagnostic ultrasound,however, exposure levels should always be limited to As Low As Reasonably Achievable (the ALARA principle). Explanation of MI/TI MI (Mechanical Index) Cavitations will be generated when ultrasound wave passes through and contacts tissues, resulting in instantaneous local overheating. This phenomenon is determined by acoustic pressure, spectrum, focus, transmission mode, and factors such as states and properties of the tissue and boundary. This mechanical bioeffect is a threshold phenomenon that occurs when a certain level of ultrasound output is exceeded. The threshold is related to the type of tissue. Although no confirmed adverse mechanical effects on patients or mammals caused by exposure at intensities typical of present diagnostic ultrasound instruments have ever been reported, the threshold for cavitation is still undetermined. Generally speaking, the higher the acoustic pressure, the greater the potential for mechanical bioeffects; the lower the acoustic frequency, the greater the potential for mechanical bioeffects. The AIUM and NEMA formulate mechanical index (MI) in order to indicate the potential for mechanical effects. The MI is defined as the ratio of the peak-rarefactional acoustic pressure (should be calculated by tissue acoustic attenuation coefficient 0.3 dB/cm/MHz) to the acoustic frequency.
MI = Pr, fawf ×CMI
CMI = 1 (MPa / MHz ) TI (Thermal Index) Heating of tissues is caused by absorption of ultrasound when the ultrasound energy is applied. The temperature rise is determined by the acoustic intensity, exposed area and thermo physical properties of the tissue. In order to indicate the potential for temperature rise caused by thermal effects, the AIUM and NEMA formulate thermal index (TI). It is defined as the ratio of the total acoustic power to the acoustic power required to raise the tissue temperature by 1ºC (1.8°F). According to different thermo physical properties of the tissue, TI is divided into three kinds: TIS, TIB and TIC. TIS (Soft Tissue Thermal Index): It provides an estimate of potential temperature rise in soft or similar tissues. TIB (Bone Thermal Index): It provides an estimate of potential temperature rise when the ultrasound beam passes through soft tissue and a focal region is in the immediate vicinity of bone. TIC (Cranial Bone Thermal Index): It provides an estimate of potential temperature rise in the cranial bones or superficial bones. Measurement Uncertainties The uncertainties in the measurements were predominantly systematic in origin; the random uncertainties were negligible in comparison. The overall systematic uncertainties were determined as follows:
1. Hydrophone Sensitivity: ± 12percent for intensity, ± 6 percent for pressure. Based on the hydrophone calibration report by ONDA. The uncertainty was determined within ±1 dB in frequency range 1-15 MHz.
2. Digitizer: ±0.3 percent for intensity. ± 0.15 percent for pressure. Based on the stated accuracy of the 8-bit resolution of the Agilent DSO6012 Digital Oscilloscope and the signal-to-noise ratio of the measurement. 3. Temperature:±2.4 percent for intensity uncertainty, ±1.2 percent for pressure uncertainty. Based on the temperature variation of the water bath of ± 1ºC (1.8°F). 4. Spatial Averaging: ± 3.5 percent for intensity, ± 1.75percent for pressure. 5. Non-linear Distortion: N/A. No effects of nonlinear propagation were observed. Since all the above error sources are independent, they may be added on an RMS basis, giving a total uncertainty of ± 12.73 percent for all intensity values reported, ± 6.37 percent for all the pressure values,,± 12.6 percent for the Mechanical Index, uncertainty of ±12.73% percent for power,±0.15 percent for center frequency, ±6.87%for the MI. Prudent Use Statement Although no confirmed bioeffects on patients caused by exposure from present diagnostic ultrasound equipment have ever been reported, the potential exists that such bioeffects may be identified in the future. Therefore, the ultrasound should be used prudently. High levels of acoustic output and long exposure time should be avoided while acquiring necessary clinical information. Reference for Acoustic Output and Safety 1. “Bioeffects and Safety of Diagnostic Ultrasound” issued by AIUM in 1993 2. “Medical Ultrasound Safety” issued by AIUM in 1994 3. “Acoustic Output Measurement Standard for Diagnostic Ultrasound Equipment, Revision 3” issued by AIUM/NEMA in 2004 4. “Standard for real-time display of thermal and mechanical acoustic output indices on diagnostic ultrasound equipment, Revision 2” issued by AIUM/NEMA in 2004 5. “Information for Manufacturers Seeking Marketing Clearance of Diagnostic Ultrasound Systems and Transducers” issued in 2008. 6. “Medical electrical equipment–Part 2-37: Particular requirements for the basic safety and essential performance of ultrasonic medical diagnostic and detection equipment” issued by IEC in 2007.
Acoustic Output Reporting Table for Track 1 Acoustic output reporting table for
IEC60601-2-37(IEC60601-2-37, Edition 2.1, 2015-0, table 201.103)
Transducer Model: SD1, Operating Mode: PW mode

TIS

TIB

Index label

Below

TIC

Surface Surface surface Surface

Maximum index value

0.01 0.05

0.01

N/A

Index component value

N/A

0.05

0.01

pr.at (MPa)

zMI 0.02

P (mW)

7.35

N/A

Acoustic Parameters

P1x1 (mW) zs(cm) zb(cm)

N/A

3.50

3.70

zMI(cm) zPII. (cm).

3.70 3.70

fawf (MHz)

3.00 3.00

3.00

N/A

prr (Hz)

5000

Other information

srr(Hz)

N/A

npps

Ipa. at zPII. (W/cm2)

0.02

Ispta. at zPII.

5.69

zSII.(mW/cm2)

Ispta at zPII or zSII (mW/cm2)

12.26

pr. at zPII (MPa)

0.04

Operating control conditions

Fixed

Acoustic Output Reporting Table for Track1(Non-autoscanning Mode)

Transducer Model: SD1 ,Operating Model: PW

Acoustic Output

ISPTA.3 (mW/cm^2)

ISPPA.3 (W/cm^2)

Global Maximum Value

0.01

5.69

0.02

Pr.3

(MPa)

0.02

(mW)

7.35

8.97

(MHz)

3.00

Zsp (cm)

3.70

X-6

Associated Acoustic Parameter

Beam dimensions PD

(cm) Y-6 (cm) (usec)

2.50
2.50 72.25

PRF

(Hz)

5000

Az.

EBD

(cm) Ele.

2.50

(cm)

2.50

Operating

Control

Fixed

Conditions

Standard Parameter Equal Contrast List

Parameter pr.
pr P zs P(Zs) Ita.(Zs)
zbp
zb Ipi. Ipi deq(Zb)

IEC60601-2-37 Standard Parameters

Note

Parameter

Note

Attenuated Peak-rare-factional Acoustic Pressure

fawf

Center Frequency, Acoustic Working Frequency

Peak-rare-factional Acoustic Pressure

-12dB Output Beam Dimensions

Output Power

Depth for Soft Tissue Thermal Index

Pulse Duration

Attenuated Output Power

prr

Pulse Repetition Frequency (Pulse Repetition Rate)

Attenuated Temporal-average Intensity

deq

Equivalent Beam Diameter

Break-point Depth

Ipi. at max MI

Attenuated

Pulse-average

Intensity at the point of Maximum

Depth for Bone Thermal Index

Aaprt

-12dB Output Beam Area

Attenuated Pulse-intensity Integral

Mechanical Index

Pulse-intensity Integral

TIS

Soft Tissue Thermal Index

Equivalent Beam Diameter

TIB

Bone Thermal Index

at the point of Zsp

TIC

Cranial-bone Thermal Index

EMC Information

Electromagnetic Emissions

Guidance and manufacturer’s declaration electromagnetic emission

The SD1 Ultrasonic Pocket Doppler is intended for use in the electromagnetic environment specified

below. The customer or the user of the device should assure that it is used in such an environment.

Emission test

Compliance

Electromagnetic environment – guidance

RF emissions CISPR 11

Group 1

The SD1Ultrasonic Pocket Doppler uses RF energy only for its internal function. Therefore, its RF emissions are very low

RF emission CISPR 11 Harmonic emissions IEC/EN61000-3-2 Voltage fluctuations /flicker emissions IEC/EN61000-3-3

Class B Not
applicable Not
applicable

and are not likely to cause any interference in nearby electronic equipment. The SD1 Ultrasonic Pocket Doppler is suitable for use in all establishments, including domestic establishments and those directly connected to the public low-voltage power supply network that supplies buildings used for domestic purposes.

Electromagnetic Immunity

Guidance and manufacture’s declarationelectromagnetic immunity

The SD1 Ultrasonic Pocket Doppler is intended for use in the electromagnetic environment specified

below. The customer or the user of the device should assure that it is used in such an environment.

Immunity test

IEC 60601 test level

Compliance level

Electromagnetic environment-guidance

Floors should be wood,

Electrostatic discharge (ESD) IEC 61000-4-2

8kV contact 15kV air

concrete or ceramic tile. If floor are covered with synthetic material, the relative humidity should be at least 30%.

Electrical Fast Transient/Burst IEC/EN61000-4-4

±2kV for power supply lines
±1kV for input/output lines

Not applicable

Surge IEC/EN61000-4-5

± 1 kV line(s) to line(s) ± 2 kV line(s) to earth

Not applicable

<5%UT(>95% dip inUT)

Voltage dips, short

for 0.5cycle

interruptions, and voltage variations on power supply input lines IEC/EN61000-4-11

40%UT(60%dip in UT) for5 cycles
70%UT(30%dip in UT) for25 cycles
<5%UT(>95% dip inUT)

Not applicable

for 5s

Power

frequency

Power frequency (50Hz/60Hz) magnetic field IEC61000-4-8

30 A/m

magnetic fields should

levels

characteristic of a

typical location in a

typical commercial or

hospital environment.

IMMUNITY to proximity magnetic
fields

8A/m, Modulation: CW Test frequency:30KHz;
65A/m, Modulation: Pulse modulation, 2.1KHz
Test frequency:134.2KHz;
7.5A/m, Modulation: Pulse modulation, 50KHz
Test frequency:13.56MHz;

8A/m, Modulation: CW
Test frequency:30KHz;
65A/m, Modulation: Pulse modulation, 2.1KHz
Test frequency:134.2KHz;
7.5A/m, Modulation: Pulse modulation, 50KHz
Test frequency:13.56MHz;

Electromagnetic Immunity

Guidance and manufacture’s declaration electromagnetic immunity

The SD1 Ultrasonic Pocket Doppler is intended for use in the electromagnetic environment specified

below. The customer or the user of the device should assure that it is used in such an environment.

Immunity test

IEC 60601 test level

Compliance level

Electromagnetic environment-guidance

Conducted RF IEC61000-4-6

3 Vrms

150 kHz ~ 80

MHz

6Vrmsc)in ISM

bands

between

0,15

MHz

and80 MHz

Not Applicable

Portable and mobile RF communications equipment should be used no closer to any part of the SD1 Ultrasonic Pocket Doppler, including cables, than the recommended separation distance calculated from the equation applicable to the frequency of the transmitter. Recommended separation distance:

Radiated RF IEC61000-4-3

10V/m 80 MHz ~ 2.7 GHz

10 V/m 80 MHz to 2.7 GHz

d = 0.35 P 80 MHz to 800 MHz

d = 0.7 P 800 MHz to 2.7 GHz

d = 6 P / E at RF wireless communications

equipment

bands

(Portable

communications equipment (including

peripherals such as antenna cables and

external antennas) should be used no closer

than 30 cm (12 inches) to any part of the SD1

Ultrasonic Pocket Doppler, including cables

specified by the manufacturer).

Where P is the maximum output power rating

of the transmitter in watts (W) according to the

transmitter manufacturer and d is the

recommended separation distance in meters

(m).

Field strengths from fixed RF transmitters, as determined by an electromagnetic site survey,a

should be less than the compliance level in each frequency range.b

Interference may occur in the vicinity of

equipment marked with the following symbol:

NOTE1:At 80 MHz and 800 MHz, the higher frequency range applies.

NOTE2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by

absorption and reflection from structures, objects and people.

a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones

and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be

predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF

transmitters, an electromagnetic site survey should be considered. If the measured field strength in the

location in which the SD1 Ultrasonic Pocket Doppler is used exceeds the applicable RF compliance

level above, the SD1Ultrasonic Pocket Doppler should be observed to verify normal operation. If

abnormal performance is observed, additional measures may be necessary, such as reorienting or

relocating the SD1 Ultrasonic Pocket Doppler. b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m. c The ISM (industrial, scientific and medical) bands between 0,15 MHz and 80 MHz are 6,765 MHz

to6,795 MHz; 13,553 MHz to 13,567 MHz; 26,957 MHz to 27,283 MHz; and 40,66 MHz to 40,70 MHz.

The amateur radio bands between 0,15 MHz and 80 MHz are 1,8 MHz to 2,0 MHz, 3,5 MHz to 4,0

MHz, 5,3 MHz to 5,4 MHz, 7 MHz to 7,3 MHz, 10,1 MHz to 10,15 MHz, 14 MHz to 14,2 MHz, 18,07

MHz to 18,17 MHz,21,0 MHz to 21,4 MHz, 24,89 MHz to 24,99 MHz, 28,0 MHz to 29,7 MHz and 50,0

MHz to 54,0 MHz.

Table-Test specifications for ENCLOSURE PORT IMMUNITY to RF wireless communications

equipment

Test Frequenc y (MHz)

Brand a) (MHz)

Service a)

Modulatio n b)

Maximu m
Power(W )

Distanc e (m)

IMMUNIT Y TEST LEVEL (V/m)

Pulse

385

380-390

TETRA 400

modulation

1.8

0.3

b) 18Hz

FM C)

450

430-470

GMRS 460, FRS 460

±5 kHz deviation

0.3

1kHz sine

710 745 780

704-787

LTE Brand 13, 17

Pulse modulation b) 217 Hz

0.2

0.3

810

GSM

870 930

800-960

800/900,TETR A 800,iDEN 820, CDMA
850, LTE Band

Pulse modulation
b) 18 Hz

0.3

1720

GSM 1800;

1845 1970

1700-199 0

CDMA 1900; GSM 1900; DECT; LTE Band 1, 3,

Pulse modulation b) 217 Hz

0.3

4,25;UMTS

Bluetooth,

2450

2400-257 0

WLAN,802.11 b/g/n, RFID 2450, LTE

Pulse modulation b) 217 Hz

0.3

Brand 7

5240 5500 5785

5100-580 0

WLAN 802.11 a/n

Pulse modulation b) 217 Hz

0.2

0.3

Note: If necessary to achieve the IMMUNITY TEST LEVEL, the distance between the transmitting

antenna and the ME EQUIPMENT or ME SYSTEM maybe reduce to 1m. The 1 m test distance is

permitted by IEC 61000-4-3.

a) For some services, only the uplink frequencies are included.

b) The carrier shall be modulated using a 50% duty cycle square wave signal.

c) As an alternative FM modulation, 50% pulse modulation at 18 Hz may be used because while it does

not represent actual modulation, it would be worst case

Recommended Separation Distances Recommended separation distances between portable and mobile RF communications equipment and the SD1 Ultrasonic Pocket Doppler
The SD1 Ultrasonic Pocket Doppler is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of theSD1 Ultrasonic Pocket Doppler can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the SD1 Ultrasonic Pocket Doppler as recommended below, according to the maximum output power of the communications equipment.

Rated maximum

Separation distance according to frequency of transmitter (m)

output power of transmitter (W) 0.01

150 kHz to 80 MHz
d = 1.2 P
/

80 MHz to 800 MHz d = 0.35 P 0.035

800 MHz to 2.7GHz
d = 0.7 P
0.07

0.1

0.11

0.22

0.35

0.7

1.11

2.21

100

3.5

For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.

NOTE 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies. NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people.

Overall Sensitivity

40.9

44.4

1.58

3MHz

100

46.9

200

52.9

39.0

42.5

2.38

3MHz

100

45.0

200

51.0

Doppler Frequency (Hz)

5#4#

0 77.0

77.0

5#3#

0 68.4

68.4

5#3#

0 69.6

69.6

5#3#

0 68.4

75.1

5#4#

0 77.0

77.0

5#4#

0 77.0

77.0

5#3#

0 68.4

68.4

5#4#

0 77.0

75.1

505

D: Diameter of Target Reflector(mm)

A: Attenuation A(dB))

Note

d: Distance (d)(mm)

VS: Signal RMS (mV)

B:Two-wayAttenuation(dB) B=Ba+Bw

Vn: Noise RMS (mV)

140 75 5.42 123.32

40 6.02 118.82

180 90 6.02 122.52

42 5.92 127.22

130 69 5.50 121.50

115 55 6.41 125.91

130 65 6.02 119.42

78 43

5.17 133.17

Velocity of Target (cm/s)

SOverall Sensitivity

(S=A+B+C)dB

C:Signal to Noise Ratio (dB)

20log10

V s
V n

(r.m.s.) (r.m.s.)

Troubleshooting

Problem

Possible Cause

Solution

Battery level is very low.

Replace the battery.

Fail to power on, or shut down shortly after switching on

Battery is not installed properly. Fail to switch on the Doppler as instructed.

Re-install the battery. Touch the On/Off touch key for a while to power on the Doppler.

The Doppler has malfunctions.

Contact service personnel.

Loudspeaker does not work.

Sound volume has been turned down to the lowest level. If the Doppler is configured with Bluetooth, fetal heart sound can be played by mobile phone.

Adjust sound volume to appropriate level. Set to play fetal heart sound by mobile phone or the Doppler on the APP.

The Doppler has malfunctions.

Contact service personnel.

FHR cannot be displayed stably. Sensitivity is low and noise is too much.

There is strong interference source such as high frequency machines and mobile phones nearby. The fetal heart position has changed because of fetal movement. Friction between the Doppler and patient’s abdomen causes false displaying. There is strong interference source such as high frequency machines and mobile phones nearby. The Doppler is not applied with coupling gel. The Doppler is not placed at the best detection position.

Use the Doppler away from strong interference sources. Relocate the Doppler to the best fetal heart rate detection position. Find the best fetal heart rate detection position.
Use the Doppler away from strong interference sources.
Apply coupling gel to the Doppler. Relocate the Doppler to the best fetal heart rate detection position.

The Doppler has malfunctions.

Contact service personnel.

Doppler cannot be connected to mobile phone.

The Bluetooth of mobile is not open. The Doppler used is not configured with Bluetooth function.
The Bluetooth function of Doppler has malfunctions.

Warranty and Service

Open the Bluetooth of mobile. Use the Doppler with Bluetooth function.
Use the FHR and sound detected and displayed on the SD1 itself, and contact service personnel.

Warranty The manufacturer warrants that the manufacturer’s products meet the labeled specifications of the products and will be free from defects in materials and workmanship that occur within warranty period. The warranty is void in cases of: A.damage caused by mishandling during shipping. B.subsequent damage caused by improper use or maintenance. C.damage caused by alteration or repair by anyone not authorized by the manufacturer. D.damage caused by accidents. E.replacement or removal of serial number label and manufacture label. If a product covered by this warranty is determined to be defective because of defective materials, components, or workmanship, and the warranty claim is made within the warranty period, the manufacturer will, at its discretion, repair or replace the defective part(s) free of charge. the manufacturer will not provide a substitute product for use when the defective product is being repaired. Contact Information If you have any question about maintenance, technical specifications or malfunctions of devices, contact your local distributor.
EDAN INSTRUMENTS, INC. Address: #15 Jinhui Road, Jinsha Community, Kengzi Sub-District, PingshanDistric, 518122 Shenzhen, P.R. China Email: [email protected] Tel: +86-755-2689 8326 Fax: +86-755-2689 8330 www.edan.com

EC REPRESENTATIVE Shanghai International Holding Corp. GmbH Eiffestrasse 80, 20537 Hamburg Germany Tel. : +49-40-2513175
E-mail: [email protected] Definition of Symbols

No.

Symbol

Definition

No.

CE marking

The

products

marked with this

symbol apply to the

European WEEE

directive.

This
