K2649 Thermostat with LCD Display

Product Information: Product Name: Thermostat with LCD Display
Model: K2649 Manufacturer: Velleman NV Features: – Very precise
digital display of set and actual temperature – Connecting
capability for an ‘economy switch’ to decrease the set temperature
– Wide setting range for hysteresis and desired temperature – Can
be used for regulating room temperature and other applications
Specifications: – Power supply and transformer included – Mains
voltage: 220/240V (110V for USA and Canada) – Relay output: 240V,
3A max – Dimensions: 123.5x62x65 mm Product Usage Instructions: 1.
Assembly: – Ensure you have the right tools, including a basic
multi-meter if required. – Carefully solder the components to the
PCB surface, making sure the solder joints are cone-shaped and
shiny. – Trim excess leads as close as possible to the solder
joint. – Always check the value of the components on the parts list
and remove them from the tape one at a time. 2. Construction: –
Power Supply Mode ‘P2649V’: – Diode: Watch the polarity. –
Zenerdiode: Watch the polarity. – Diodes: Watch the polarity. –
Resistors: Mount and solder according to the values listed on the
parts list. – IC socket: Watch the position of the notch. – Ceramic
capacitor: Mount C3 with a value of 100nF (104). – Transistor:
Mount T1 with model BC557B. – Terminal blocks: Mount J1, J4, and J2
according to the instructions provided. – Vertical trimmer: Mount
RV5 with a value of 4M7 (5M). – Horizontal trimmer: Mount RV4 with
a value of 10K. – Electrolytic capacitor: Watch the polarity when
mounting. Note: Always refer to the assembly hints and construction
instructions provided in the manual for a successful project.

View Fullscreen

Total solder points: 166 + 116 Difficulty level: beginner 1 2 3 4 5 advanced
THERMOSTAT WITH LCD-DISPLAY
K2649

ILLUSTRATED ASSEMBLY MANUAL

Digitaal cretuaadlotuetmopf ebroatthursee.t and
Specifications
Adjustable hysteresis: 0,2°C (0,4°F) to 10°C (18°F). Resolution of the display: 0,1°C or 1°F. Mains voltage: 110/230VAC Relay output: 240V, 3A max.
H2649IP-1

VELLEMAN NV Legen Heirweg 33
9890 Gavere Belgium Europe www.velleman.be www.velleman-kit.com

Features & Specifications
The very precise digital display of both the set and actual temperature makes this thermostat very easy to use. Also very useful is the connecting capability for an ‘economy switch’: when the contact is closed then the set temperature is decreased by a number of degrees. No measuring apparatus is needed for adjustments. Thanks to the wide setting range of both the hysteresis and the desired temperature, this kit can also be used for a lot more applications than only regulating room temperature.
Features:
Wide measuring and regulating range: -50 to +150°C (-60 to +300°). Adjustable hysteresis: 0,2°C (0,4°F) to 10°C (18°F). Resolution of the display: 0,1°C or 1°F. Can be set for degrees Celsius or Fahrenheit. Connecting capability for economy switch.
Specifications:
Power supply and transformer included. Mains voltage: 220/240V (110 for USA and Canada). Relay output: 240V, 3A max. Dimensions: 123.5x62x65 mm.
3

Assembly hints

1. Assembly (Skipping this can lead to troubles ! ) Ok, so we have your attention. These hints will help you to make this project successful. Read them carefully.

1.1 Make sure you have the right tools:

· A good quality soldering iron (25-40W) with a small tip.

· Wipe it often on a wet sponge or cloth, to keep it clean; then apply solder to the tip, to give it a wet look. This is called `thinning’ and will protect the tip, and enables you to make good connections. When solder rolls off the tip, it needs cleaning.

· Thin raisin-core solder. Do not use any flux or grease.

· A diagonal cutter to trim excess wires. To avoid injury when cutting excess leads, hold the lead so they cannot fly towards the eyes.

· Needle nose pliers, for bending leads, or to hold components in place.

· Small blade and Phillips screwdrivers. A basic range is fine.

0.000

For some projects, a basic multi-meter is required, or might be handy

1.2 Assembly Hints :
Make sure the skill level matches your experience, to avoid disappointments. Follow the instructions carefully. Read and understand the entire step before you perform each operation. Perform the assembly in the correct order as stated in this manual Position all parts on the PCB (Printed Circuit Board) as shown on the drawings. Values on the circuit diagram are subject to changes. Values in this assembly guide are correct* Use the check-boxes to mark your progress. Please read the included information on safety and customer service
* Typographical inaccuracies excluded. Always look for possible last minute manual updates, indicated as `NOTE’ on a separate leaflet.
4

1.3 Soldering Hints : 1- Mount the component against the PCB surface and carefully solder the leads
2- Make sure the solder joints are cone-shaped and shiny 3- Trim excess leads as close as possible to the solder joint
DO NOT BLINDLY FOLLOW THE ORDER OF THE COMPONENTS ONTO THE TAPE. ALWAYS CHECK
THEIR VALUE ON THE PARTS LIST!
REMOVE THEM FROM THE TAPE ONE AT A TIME !

Assembly hints 5

Construction
A. POWER SUPPLY MODE `P2649V’
1. Diode. Watch the polarity ! 4. Resistors
R…
D5 : 1N4148
D…
CATHODE

5. Metal film resistors
R…

2. Zenerdiode. Watch the polarity !

CATHODE

ZD…

ZD1 : 8V2 – 500mW.

3. Diodes. Watch the polarity !

D1 : 1N4007

D2 : 1N4007

D…

D3 : 1N4007 CATHODE

D4 : 1N4007

R1 : R3 : R4 : R6 : R15 : R16 : R17 : R18 : R26 : R27 :
R28 :
R29 :
R34 : R35 :

560 100K 100K 100K 220K 220K 560K 560K 820 1K
10K
82
6K8 5M6

(5 – 6 – 1 – B) (1 – 0 – 4 – B) (1 – 0 – 4 – B) (1 – 0 – 4 – B) (2 – 2 – 4 – B) (2 – 2 – 4 – B) (5 – 6 – 4 – B) (5 – 6 – 4 – B) (8 – 2 – 1 – B) (1 – 0 – 2 – B)
(1 – 0 – 3 – B)
(8 – 2 – 0 – B)
(6 – 8 – 2 – B) (5 – 6 – 5 – B

R20 : 10K (1 – 0 – 0 – 2 – 1) R21 : 10K (1 – 0 – 0 – 2 – 1) R22 : 47K (4 – 7 – 0 – 2 – 1) R23 : 47K (4 – 7 – 0 – 2 – 1)
6. IC socket, Watch the position of the notch !
IC2 : 14P

7. Ceramic capacitor. C3 : 100nF (104)

10. Capacitor

Construction 12. Terminal blocks.

8. Transistor. T1 : BC557B

C10 : 1µF/63V
11. Vertical trimmer
RV…
RV5 :4M7 (5M)

9. Horizontal trimmer

RV4 :10K

R…

J1 : Mains. J4 : “ES” Economy switch.
J2 :
For heaters use the contacts : `C’ & `NO’.
For coolers use the contacts : `C’ & `NC’.
The connection side of the connectors must point to the PCB-opening!

Construction
13. Electrolytic Capacitor. Watch the polarity !
C2 : 100µF
C …

14. Fuse holder & Fuse

F1 : 100mA

(slow)

F…

15. Relay

RY1 : VR15M121C 8

16. Electrolytic Capacitor. Watch the polarity !
C1 : 1000µF

19. Flat cable

C…
J3 : FC8 “9 wire”

17. Transformer

220V

12V

TRANSFORMER

TRAFO1 : 12V – 0,1A
18. IC. Watch the position of the notch!

IC2 : LM324

20. Choosing hysteresis
Small hysteresis
If you desire a small hysteresis (adjustable from 0,2 to 1°C or from 0,4 to 4°F), then fit for R24 and R25 a 180K metal film resistor (brown, grey, black, orange).
Larger hysteresis
If you prefer a larger hysteresis (between 1 and 10°C or 2 and 20° F, for instance for water heaters and such-like), then fit a wire link for R24 an R25.

Construction

B. DISPLAY MODULE `P2649D’

1. Jumpers

3. Resistors
R…

Mount for R13 : 1M (1-0-5-B) for °C. OR 150K (1-5-4-B) for °F.

J (4x) Choose temperature display :
JC for °C JF for °F 2. Metal film resistor
R…
R2 : 91K (9 – 1 – 0 – 2)

R5 : R9 :
R11 : R12 : R19 :
R30 : R31 : R33 :

100K 1K8
120K 18K 4M7
47K 10K 22K

(1 – 0 – 4 – B) (1 – 8 – 2 – B)
(1 – 2 – 4 – B) (1 – 8 – 3 – B) (4 – 7 – 5 – B)
(4 – 7 – 3 – B) (1 – 0 – 3 – B) (2 – 2 – 3 – B)

Mount for R10 : 390 (3-9-1-B) for °C. OR 330 (3-3-1-B) for °F.

For degrees Celsius, the following resistors must be fitted too :
R7 : 100K (1 – 0 – 4 – B) R8 : 100K (1 – 0 – 4 – B) R14 : 150K (1 – 5 – 4 – B)
4. IC socket, Watch the position of the notch !
IC1 : 40P

Construction 5. Ceramic capacitors.
C4 : 100nF (104) C6 : 100pF (101)
6. Transistor.
T2 : BC557B Attention : For °F this transistor should not be fitted!
7. Horizontal trimmers
R…
RV1 : 4K7 RV2 : 100 RV3 : 10K
10

8. LCD display

Fig.1.0

First look for pin 1 : if a colon is displayed when connecting the
battery, then you have the display correctly mounted. If only one point is displayed, then you have to turn the display, fig. 1.0.

Construction

LCD

9. Capacitors

Fig. 2.0

Pay attention to the position : the upper surface must be at 8mm (0,3 inch) above the pcb surface (see drawing 2.0).
You may put some pieces of paper between the LCD and the pcb, to help you holding the display on the right height.

C5 : 10nF / 250V C7 : 100nF / 250V C8 : 220nF / 100V C9 : 470nF / 63V
10. LED. Watch the polarity !

First solder only the pins at the four corners. Verify the height, and correct if necessary. Then solder the remaining pins.
Be very careful, for this part is not cheap!

CATHODE

LD1

LD1: 5mm Red 11

Construction 11. Push button.
S1 : S500

13. Axe.

12. IC. Watch the position of Insert the plastic spindle in trimmer

the notch!

RV1 as displayed.

IC1 : ICL7106 12

Sensor 14. Sensor Calibration is performed by alternately adjusting the meter at the freezing respectively boiling-point of water. Therefore the sensor first has to be prepared.
DON’T shorten the connection wires of the sensor, unless you are not going to fit it directly onto the pcb in the future.
Solder two isolated wires (75 cm or 30″) to the sensor (see fig. 3.0)
Fig. 3.0
Make use of a cable of the desired length (max 10m, and preferably screened to avoid interferences) if you are not going to fit the sensor onto the pcb in the future.
13

Sensor Make the connections waterproof with heat-shrinkable tubing :
Cut off a piece of shrinking tube with a lenght equal to 5cm. Slide the shrinking tube over the wires and over the sensor (Fig. 4.0). Heat the shrinking tube using a hair dryer or, better still, using a paint stripper.
Fig. 4.0
Take care that everything is well covered. Connect the whole to the place marked with ‘R32 SENSOR’. The connection order is unimportant, unless with screened cable: the screen then comes on the side marked with ‘SENSOR’. Connect a mains cable to the screw connector J1-MAINS.
14

15. Flat cable

P2649D

Flat cable

P2649V

Fig. 5.0

Attention : The connecting order (whit regard to the pcb-edge) must be the same as on the power supply module (see fig. 5.0).
15

Adjustment
16. Adjustment
During assembly you already made your choice for degrees Celsius or degrees Fahrenheit version. The adjusting method is the same for both, only the values on the display are different. The figures for Fahrenheit are mentioned within brackets. The first adjustment is done at the freezing-point.
Fill a beaker with ice cubes and plunge the sensor into the melting-water (Fig. 6.0). As long as not all the ice is molten, the temperature of the melting-water is kept at 0°C (32°F), and after a few minutes the sensor will be at 0°C too.
Fig. 6.0
Then adjust with RV2 until the display reads 00.0 (32°F). After zero-adjustment, the sensitivity of the meter has to be adjusted. Plunge the sensor into boiling water, but see to it that the sensor does not come too close to the bottom or wall of the kettle. After a few minutes, the sensor temperature has risen to 100°C (212°F). Then adjust with RV3 until the display reads 100.0 (212°F). Now let it cool down for about half an hour, and do the complete adjustment over again once more.
Remark : when the sensor has to be replaced for any reason, then you have to readjust completely!
16

Use

17. Use

The set temperature is displayed when you push the button S1. You can change it by gradually turning potentiometer RV1 until the display shows the desired temperature. With the standard values for R2 and R33 (91K resp. 22K), the adjusting range is about 5 to 30°C (40 to 85°F).

You can change this range by using other values for R2 and R33 :

Range -50°C (-60°F) to 0°C (32°F) +50°C (120°F) to 100°C (212°F) +100°C (212°F) to 150°C (300°F)

R2 R3 51K 7K5 33K 12K 33K 16K

You can also experiment yourself in order to obtain an optimum adjusting range for your application.
Solder a 1M trimmer parallel to both R2 and R33 (see fig. 7.0). Adjust both trimmers so that you obtain the optimum range. Afterwards replace the trimmers by normal resistors which approximate the set value as close as possible.

Use
FIG. 7.0
You can lower the set temperature by a number of degrees (preset with RV5), e.g. by night or during your absence, by connecting a switch or a relay contact (e.g. a timer such like K2603 or K1682) at the place marked with ‘E.S.’ (Economy Switch). The hysteresis is the difference between the temperatures at which the output is switched on resp. switched off. Depending on the application, a smaller or larger hysteresis may be desired: to regulate the room temperature for instance, a small hysteresis is desirable. On the contrary, this makes no sense with waterheaters, so, in this case, you should select a larger hysteresis. You can adjust the hysteresis with RV4. The adjusting range is about 0,2 to 2°C (0,4 to 4°F) when R24 and R25 are 180K resistors, and 1 to 10°C (2 to 18°F) when you fitted wire links. 18

Use
The setting of the hysteresis does not depend on the set temperature. Do not set the minimum hysteresis right from the beginning: in this case the regulation is most precise, however it could happen that the heating gets switched on and off much too fast and too often (e.g. when the thermostat is located near the radiator). This is not too healthy for the heating installation and/or relay, and too much energy is consumed. Therefore start with RV4 in the middle position, and then search the ideal position for your application.
Suppressing inductive loads :
Should the operation of the thermostat get disturbed by the switching of inductive loads (even if the switched power is not so high), then this is due to the sparks produced in the relay. In most cases this can be remedied by putting a VDR (e.g. VDR300) over the contacts. Moreover a series connection of a 100 ohm resistor with a 47 or 100nF/400V capacitor can be placed in parallel with the VDR in order to further reduce the sparks (see Fig. 8.0).
LOAD

VDR (VDR300)

100 ohm / 0,5W 100nF/400V

MAINS
FIG. 8.0
19

Mounting 18. Mounting * Spacers & screws are not included.

FIG. 9.0
20

FLAT CABLE

SENSOR

Mounting
The rectangular opening in the power supply module is used as a passage for the wiring to the mains input, the relay output and the E.S. (Economy Switch), see fig. 10

Mains

Economy switch

Relay output

FIG. 10
21

Mounting The display module can be mounted above the power supply module using spacers (See fig. 11).
FIG. 11
22

Mounting
This thermostat exactly fits into the box type B2649.
In case you use this box, you can fit the sensor onto the pcb in such a way that it passes through the opening in the side of the bottom. In this way, the sensor reacts more quickly and accurately upon the room temperature, and it doesn’t get influenced by the heat-dissipation of the transformer and such-like.
In case of panel-mounting, you may use a some what longer flat cable, so you can simply mount the pcb’s with their solder sides towards each other, and the connections are easily accessible.
You also could use screw connectors for the sensor connection. Wherever and for whatever application the thermostat may be used, always take into account that the mounting of the sensor determines the quality of the regulation: the quicker it reacts upon the changing temperature, the better. In case of liquids, this is not such a problem: you can attach the sensor on the outside of the metal pipe or boiler (you could use a little bit of heat-conducting paste), or make the sensor waterproof and plunge it into the liquid. Air however is a much worse heat-conductor, so that the body of the sensor does not heat up/cool down that quickly. This can be improved by circulating the air around the sensor. Especially in large rooms, which are heated by means of hot air, it can be interesting to place the sensor in the (cold) air circulation, for instance nearby the air inlet of the convector. The intake air (which has the actual room temperature) then makes the sensor warm up quickly as the room temperature increases.
23

PCB 19. PCB layout (Display module)
24

PCB PCB layout (power module)
25

Diagram

20. Diagram

TRAF01 D1…D4

220VAC

+V2 4
A1 … A4 = IC2 11
R2 RV1

+V1

C3 C2 +V2

R34

RV2

+V1 +V2
