RH-G Luer Adapter

Product Information: Product Name: Plastic Fittings Website:
www.runzeliuti.com Features of Luer Adapter: – Luer adapter is a
standardized micro-permeation-free adapter. – It is usually
connected by male and female luer parts. – Simplifies the
management of liquid or gaseous medical fluids. – Allows multiple
compatible fluids to be managed using the same tube. – Made from
imported PP material, which is non-toxic, odorless, heat and
corrosion resistant. – Suitable for use in biomedical,
environmental, and food industries. Product Usage Instructions: 1.
Hose Connection: – Connect the male luer adapter to the female luer
adapter for hose connection. – Ensure a secure connection. 2. Panel
Installation: – The panel thickness must be 3mm. – Pre-drill the
panel before making any connections. – Use the following hole sizes
for connection: – 1/4-28UNF – M10 – 6.5 – 2-3.0 – 2-4.75 (Unit: mm)
3. RH-M-M10W Connection: – RH-M-M10W can be connected to a
1/4-28UNF male thread adapter. – The other end should be connected
to a Luer adapter through a plate. – Use LM-M10P single tooth nut
for installation. – The panel thickness must be 7mm, and the panel
hole diameter should be 10.5mm. 4. Luer Adapter Installation: – Use
the provided dimensions and materials for different tubing IDs and
thread types. – Follow the specified dimensions for male luer
adapters (RH-G) and female luer adapters (RH-M). – Ensure proper
thread compatibility for connections. Note: For more detailed
information and specific model numbers, refer to the complete user
manual available on the website www.runzeliuti.com.

View Fullscreen

Plastic Fittings

www.runzeliuti.com

Application Note
1
Hose connection available through male luer adapter +female luer adapter
2

Panel thickness must be3mm

The panel is to be pre-drilled prior to connection, with the following hole sizes as indicated:

1/4-28UNF

M10

6.5 2-3.0 2-4.75 Unit: mm
3

2-6.75

10.5

2-3.0

RH-M-M10W can be connected to 1/4-28UNF male thread adapter, and the other end is connected to a Luer adapter through a plate.
To be used with LM-M10P single tooth nut
Panel thickness must be 7mm, panel hole diameter 10.5mm

M10

10-11.10

Unit: mm

6.0

Luer Adapter

Features:
Luer adapter is standardized micro-permeation-free adapters that are usually connected by male and female luer part Simplifies the management of liquid or gaseous medical fluids and allows multiple compatible fluids to be managed using the same tube. Imported PP material, non-toxic, odorless, heat and corrosion resistant; used in biomedical, environmental and food industries

A C

Unit: mm

1
RH-G
Male luer adapter

C 6.5

2
RH-C-M
Bulkhead Luer adapter

11.2 E

RH-M

16.0

Female luer adapter

2.7
14.2
C1/4-28
Fixer
2.5 12.0
LM-1/4-28P
single tooth nut

C10
Fixer

2.7 18.0

2.5
18.0
LM-M10P
single tooth nut

10.0

7.0

18.5

13.0

RH-M-M10W
Female luer bulkhead adapter

2.96

19.2 14.8

RH-2G
Male to male luer

11.39
10.0 7.4

11.2
RH-G-D Male luer plug
Male luer plug

4.5
18.0
M10*1
Fine thread thin nut Standard nut for RH-M-M10W Female luer bulkhead adapter is LM-M10P single tooth nut, but M10*1 nut (pps material ) is also available for purchase, which is easier for installation.

16.0

RH-2M
Female to female luer

9.4 2.8

5
RH-M-D
Female luer plug

10.4

www.runzeliuti.com Plastic Fittings

Luer Adapters Luer Adapters

6
Female Luer adapter can be connected to 1/4-28UNF male fitting and the other end to Luer fitting
7

7.0 17.6
11.2
RH-G-(1/4-28)N
Male luer female thread adapter
9.0 18.6

7.0 18.0

16.0

RH-M-(1/4-28)N

Female luer female thread adapter

10.0 18.5

Male Luer adapter can be connected to 1/4-28UNF female thread, and the other end can be connected to Luer fitting

11.2
RH-G-(1/4-28)W
Male luer male thread adapter

9.12

RH-M-(1/4-28)W

Female luer male thread adapter

18.25

28.68

30.99

28.68

18.31
8

18.25

23.67

28.8

RH-2M-L

RH-3M-T

RH-3M-Y

RH-4M

Model No.

Tubing ID

Dimensionmm

Material

Male luer adapter

RH-G016 RH-G024 RH-G032 RH-G040 RH-G048 RH-G064 Female luer adapter RH-M016 RH-M024

1.0~1.6 mm 1.6~2.4 mm 2.4~3.2 mm 3.2~4.0 mm 4.0~4.8 mm 4.8~6.4 mm
1.0~1.6 mm 1.6~2.4 mm

A=0.99 A=1.58 A=2.46 A=2.96 A=3.94 A=5.42

B=1.60 B=2.40 B=3.20 B=4.00 B=4.80 B=6.35

C=2.80 C=3.40 C=4.20 C=6.00 C=6.80 C=8.40

D=18.6 D=18.6 D=19.6 D=25 D=25 D=27.1

A=0.99 B=1.60 C=2.80 D=20 A=1.58 B=2.40 C=3.40 D=20

PP natural

RH-M032

2.4~3.2 mm

A=2.46 B=3.20 C=4.20 D=20

PP natural

RH-M040

3.2~4.0 mm

A=2.46 B=4.00 C=6.00 D=27.5

PP natural

RH-M048

4.0~4.8 mm

A=2.96 B=4.80 C=6.80 D=27.5

PP natural

RH-M064 Bulkhead Luer adapter

4.8~6.4 mm

A=4.43 B=6.35 C=8.40 D=27.5

PP natural

SKU

Model No.

Tubing ID

Thread

Dimensionmm

Material

1008050037 RH-C-M016 * C1/4-28 * LM-1/4-28P 1008050038 RH-C-M024 * C1/4-28 * LM-1/4-28P 1008050039 RH-C-M032 * C1/4-28 * LM-1/4-28P 1008050040 RH-C-M040 * C10 * LM-M10P 1008050041 RH-C-M048 * C10 * LM-M10P 1008050042 RH-C-M064 * C10 * LM-M10P Female luer bulkhead adapter 1008050043 RH-M-M10W * LM-M10P Luer adapter Model No.

1.0~1.6 mm 1.6~2.4 mm 2.4~3.2 mm 3.2~4.0 mm 4.0~4.8 mm 4.8~6.4 mm

1/4-28UNF 1/4-28UNF 1/4-28UNF M10 M10 M10

A=0.99 A=1.58 A=2.46 A=2.96 A=3.94 A=5.42

B=1.60 B=2.40 B=3.20 B=4.00 B=4.80 B=6.35

C=2.40 C=3.40 C=4.20 C=6.00 C=6.80 C=8.40

D=25 D=25 D=25 D=32.5 D=32.5 D=32.5

E=9.12 E=9.12 E=9.12 E=13.74 E=13.74 E=13.74

PP natural PP natural PP natural PP natural PP natural PP natural

1/4 28UNF female thread/M10 male thread

PP natural

Thread

Material
