SQM5226-00 LCD Wall Mount
Product Information
The Philips LCD wall mount SQM5226 is a universal fixed wall
mount designed to fit most brands of TVs. It is compatible with
LCD, LED, OLED, and QLED TVs, and can be used for both flat and
curved screens. The mount is suitable for TVs with screen sizes
from 26 to 70 inches and has a weight capacity of up to 55kg (121
lbs). The mount comes with an easy 1-2-3 installation kit that
includes all necessary hardware for different wall types and
templates.
Specifications
- Screen sizes: 26 – 70 inches
- Weight capacity: up to 55kg (121 lbs)
- Compatibility: LCD/LED/OLED/QLED, flat & curved TVs
- VESA mounting hole pattern: standard
Accessories
- Mounting hardware (screws, anchors, bolts)
Highlights
- Easy installation kit
- Cable management system
- Level correction feature
- Standard VESA mounting hole pattern
Product Usage Instructions
- Determine the best location on the wall to mount the TV.
- Use the included templates to mark the location of the mounting
holes on the wall. - Attach the mounting bracket to the back of the TV using the
included screws. - Attach the mounting plate to the wall using the included
hardware, making sure to use the appropriate hardware for your wall
type. - Hang the TV on the mounting plate and secure it in place.
- Use the cable management system to neatly tuck away any cables
behind the TV. - If necessary, use the level correction feature to adjust the
position of the TV so that it is level.
Philips LCD wall mount
Universal
Fixed LCD/LED/OLED/QLED compatible Flat & curved TV compatible
SQM5226
Universal fixed wall mount
for TV from 26″ up to 70″
Designed to fit most brands of TV with a focus on safety & ease of use. Easy 1-2-3 installation kit includes necessary hardware for different wall types, templates. Solid design for weight capacity up to 55kg (121 lbs).
Safely mount your TV · Supports weights of up to 55 kg (121 lbs) · Screen sizes 26″ – 70″ Easy installation · Level correction · TV cable management to hide cables for a neater look · Mounting hardware included · Standard VESA mounting hole pattern · Mounting templates included · Safety device to prevent unintentional removal
LCD wall mount
Universal Fixed, LCD/LED/OLED/QLED compatible, Flat & curved TV compatible
Specifications
Dimensions
· Wall mount compatible: 200 x 100 mm, 200 x 200 mm, 300 x 300 mm, 400 x 400 mm
Weight and dimensions
· Extension of articulating arm: 35 cm · Wall Distance: 3.9 cm
Accessories
· Mounting material included · User Manual: Included
Outer Carton
· Gross weight: 33.951 lb · Gross weight: 15.4 kg · GTIN: 1 48 95229 11430 9 · Outer carton (L x W x H): 48 x 21 x 43 cm · Outer carton (L x W x H): 18.9 x 8.3 x 16.9 inch · Nett weight: 20.371 lb
· Nett weight: 9.24 kg · Number of consumer packagings: 14 · Tare weight: 6.16 kg · Tare weight: 13.580 lb
Packaging dimensions
· Packaging dimensions (W x H x D): 47.3 x 2.6 x 19.2 cm
· Packaging dimensions (W x H x D): 18.6 x 1.0 x 7.6 inch
· EAN: 48 95229 11430 2 · Gross weight: 0.99 kg · Gross weight: 2.183 lb · Nett weight: 1.455 lb · Nett weight: 0.66 kg · Number of products included: 1 · Packaging type: Carton · Tare weight: 0.728 lb · Tare weight: 0.33 kg
·
SQM5226/00
Highlights
Screen sizes 26″ – 70″
Screen sizes 26″ – 70″
Mounting hardware included
Includes all necessary screws, anchors and bolts for different types of walls, ensuring the right type of hardware is readily available for the particular type of wall the support is being mounted on.
TV cable management
The cable compartment is designed to tuck your cables in neatly behind the television in one place.
Level correction
If the wall mount is slightly off-level after it is installed, it allows for level corrections to horizontally mount the TV.
Standard VESA mounting hole pa
Standard VESA mounting hole pattern
Issue date 2022-07-14 Version: 4.1.3
12 NC: 8670 001 71923 EAN: 48 95229 11430 2
