AC4504 · AC8305 · AC10304 AC12810 · AC12824 · AC24016 AC24050 · AC24080 · AC32024
Compressor
Operating Instructions
(Original Instructions)
Betriebsanleitung
(Übersetzung der Ursprünglichen Anweisungen)
Mode d’Emploi
(Traduction des Instructions Originales)
Gebruiksaanwijzing
(Vertaling van de Oorspronkelijke Gebruiksaanwijzing)
Instruções de Operação
(Tradução das instruções originais)
Instrucciones de Empleo
(La Traducción de las Instrucciones Originales)
Instruziono per l’Uso
(Traduzione delle Istruzioni Originali)
( )
Bruksvisning
(Översättning av de Ursprungliga Undervisningarna)
Bruksvisning
(Oversettelse av de Originale Instruksjonene)
Käyttöohjeet
(Alkuperäisten Ohjeiden Käännös)
Brugsanvisning
(Oversættelse af de Originale Instruktioner)
( )
Kasutusjuhend
(Algse juhendi tõlge)
Naudojimo instrukcijos
(Originalios instrukcijos vertimas)
WARNING: Please read the instructions and warnings for this tool carefully before use.
Lietosanas instrukcijas
(Oriinl nordjuma tulkojums)
Instrukcja Obslugi
(Tlumaczenie oryginalnej instrukcji)
Operativní Instrukce
(Peklad pvodního pokynu)
Návod na Pouzívanie
(Preklad pôvodného pokynu)
Használati Utasítások
(Az eredeti utasítás fordítása)
Navodila za Uporabo
(Prevod izvirnega navodila)
Instruciuni de utilizare
(Traducerea instruciunii originale)
( )
Kullanma Talimatlari
(Orijinal talimatlarin çevirisi)
Kyocera Senco Europe Pascallaan 88 8212 NJ Lelystad, The Netherlands +31 320 295 575 www.senco.eu
NFE2AC · Revised July 22, 2021 (Replaces06/06/2021)
© 2021 by Kyocera Senco Europe
TABLE OF CONTENTS
EN
THE IMPORTANCE OF THE MANUAL…………………………………………………………………………….4 ADDRESSEES ………………………………………………………………………………………………………………4
SAFETY WARNINGS ……………………………………………………………………………………………………4 Applied Safety Devices……………………………………………………………………………………………………………………… 4 Safety Marking…………………………………………………………………………………………………………………………………. 5
MACHINE USE …………………………………………………………………………………………………………….5
Destination Of Use …………………………………………………………………………………………………………………………… 5
Use Limits……………………………………………………………………………………………………………………………………….. 6
Command Devices …………………………………………………………………………………………………………………………… 6
Checks Before Switching On……………………………………………………………………………………………………………… 6
Machine Switching On………………………………………………………………………………………………………………………. 6
Machine Switching Off………………………………………………………………………………………………………………………. 7
Restorable Thermal Protection Tripping Reset
7
CONNECTIONS……………………………………………………………………………………………………………7
Electrical Connections ………………………………………………………………………………………………………………………. 7
Connection Of The Air Tube (Extension) And Of The Tools
7
EMERGENCY STOP …………………………………………………………………………………………………….7 Emergency Stop ……………………………………………………………………………………………………………………………… 7 Switching On After An Emergency Stop ……………………………………………………………………………………………… 7
MAINTENANCE……………………………………………………………………………………………………………8 State Of “Switched Off Machine” ………………………………………………………………………………………………………… 8 Routine Maintenance………………………………………………………………………………………………………………………… 8 Supplementary Maintenance……………………………………………………………………………………………………………… 8 Demolition……………………………………………………………………………………………………………………………………….. 8 Trouble Causes Troubleshooting…………………………………………………………………………………………………… 8 Spare Parts……………………………………………………………………………………………………………………………………… 9
PACKAGING ………………………………………………………………………………………………………………..9 Machine Transport And Handlingt ………………………………………………………………………………………………………. 9 Packaging……………………………………………………………………………………………………………………………………….. 9 Unpacking……………………………………………………………………………………………………………………………………….. 9 Positioning ………………………………………………………………………………………………………………………………………. 9 Storage …………………………………………………………………………………………………………………………………………… 9
TECHNICAL SPECIFICATIONS ………………………………………………………………………………….10 RESERVED RIGHTS ………………………………………………………………………………………………….10 DECLARATION OF CONFORMITY……………………………………………………………………………199 LIMITED WARRANTY……………………………………………………………………………………………….202
3
EN
THE IMPORTANCE OF THE MANUAL
Before using the machine, the authorized operators Must read and understand this manual in all its parts.
This manual of “use and maintenance instructions” was drawn up according to the provisions foreseen by the “Machinery Directive” 2006/42/EC in order to assume an easy and correct comprehension of the contents handled by the authorised operators. Therefore, it must always be placed, well guarded and preserved, near the the machine.
This manual is integral part of the machine and must be preserved for future reference until disposal of the same. This manual must always be available for the charged operators and has to be placed well stored and preserved near to the machine.
The manufacturer cannot be made liable for damages to persons, animals and things, due to the inobservance of the standards and of the instructions described in this manual.
The manual has compulsorily to be delivered together with the machine, in case this latter is transferred to another user.
This manual meets the state of art when the machine is traded and cannot be considered improper just because following to new experiences it can then be updated.
In case of loss or wear of the manual, equest a new copy from the manufacturer or authorised dealer specifying the model of the machine and the revision quoted on the cover.
MECHANICAL / PNEUMATIC MAINTENANCE ENGINEER: This is the trained technical engineer qualified to perform exclusively interventions on the mechanical / pneumatic parts in order to carry out adjustment, maintenance and/or repair procedures even with disabled protections in full observance of the instructions contained in this manual or in any other specific document exclusively supplied by the manufacturer, being equipped with the personal protection equipment.
ELECTRICAL MAINTENANCE ENGINEER: This is a trained technical engineer qualified to perform intervention exclusively on electrical devices in order to carry out adjustment, maintenance and or repair procedures also with live voltage and with disabled protections in full observance of the instructions contained in this manual or in another specific documents exclusively supplied by the manufacturer, being equipped with the personal protection equipment.
COMPANY SAFERY MANAGER: This is a qualified technical engineer, appointed by the employer (in case the machine is used in a company), meeting the technical and professional requirements foreseen by the regulators in force concerning the safety and health of workers in the place of work.
MANUFACTURER’S TECHNICAL ENGINEER: This is a qualified technical engineer supplied by the manufacturer and/or authorized dealer to perform the required technical assistance, as well as interventions of routine and supplementary maintenance and/or procedures not described in this manual requiring a specific knowledge of the machine, being equipped with the personal protection equipment.
ADDRESSEES
This technical manual is destined exclusively to authorised operators charged with the use and maintenance of the machine according to the specific technical and professional competences required for the type of intervention involved. The symbols here below are placed at the beginning of a paragraph and indicate the operator involved in the handed topic.
The authorised operators must perform on the machine only the interventions of their specific competence.
Before performing any intervention on the machine, the authorised operators must make sure they are in full possession of their physical and psychological abilities in order to assure at any time the respect of the safety conditions.
CHARGED OPERATOR: This is an operator being at least 18 years old (private user or worker), who, in compliance with the provisions of the laws in force in the country of use on safety and health in work places, can perform exclusively the switching-on, use and switching-off of the machine in full observance of the instructors container in the manual, being equipped with the personal protection equipment.
SAFETY WARNINGS
APPLIED SAFETY DEVICES
1.SAFETY VALVE: this is a certified safety valve (calibrated on 10,5 bar), installed on the pneumatic plant under the pressure switch. It is used to discharge the overpressure of the plant, when the pressure switch does not work due to possible malfunctions. The tripping of the safety valve obliges the operator to switch off the machine and require the intervention of the maintenance technical engineers.
2.PRESSURE SWITCH: this is an elector-pneumatic device (calibrated on min. 7 bar and max. 10 bar) installed on the pneumatic plant. It is used to command the automatic start of the machine, when the operation pressure falls under 7 bar, as well as the automatic stop when the operation pressure reaches 10 bars.
3.FIXED PROTECTION GRATING OF THE COOLING FAN : This is affixed protection made up of a grating in plastic material fastened by screws to the base of the bi-cylindrical pumping assembly. It is used to avoid accidental contact with the moving cooling fan.
4.RESTORABLE THERMAL SWITCH: this is a thermal protection installed on the electric plant, stopping the electric motor in case of current overload and/or short-circuit.
The restoration can be performed by the related push-button .
5.TANK PRESSURE GAUGE: this is a measuring device installed on the machine tank. It displays the
4
compressed air pressure present within the tank. 6.PRESSURE GAUGE AT OUTPUT: this is a measuring device
SIGNAL COMPULSORY PPE TYPE OF USE In case maintenance
EN
installed on the machine pneumatic plant upstream of the
interventions are
fast air outlet tap. It displays the output pressure, which is
Hands Protection
required without
adjustable through the proper pressure regulator (0 ÷ 10 bar).
(Heart protecting gloves)
waiting that the electric motor and the
It is strictly to tamper, disconnect and/or remove any safety device existing in the machine.
bi-cylindrical pumping element cool down.
It is strictly forbidden to replace any safety device or any of their components with not original spare parts.
Hearing Protection (Ear muff)
During all processing phases.
It is compulsory to constantly check the correct operation of all safety devices installed on the machine.
Feet protection (Footwear with reinforced cap)
During machine transport.
It is compulsory to immediately replace any safety device malfunctioning and/or being damaged.
SAFETY MARKING The safety marking used is represented by an adhesive label, applied on the outside of the machine. Meaning of the signals:
RESIDUAL RISKS The authorized operators shall be aware that even
though the manufacturer has adopted all possible technical manufacturing precautions to make the machine safe, there is still a potential residual risk.
RESIDUAL RISK
Hazard of burning by accidental contact with the bi-cylindrical pumping assembly and the electric motor.
Hazard: Power supply
Hazard:
Hazard:
Automatic start High temperature
EXPOSURE FREQUENCY
DAMAGE RELEVANCE
Low and accidental. There can be exposure if the operator decides to perform voluntary a wrong action, forbidden and not reasonably foreseeable.
Light lesions (usually reversible).
0 bar
Safety sings. / Obligation of use of the
DAMAGE RELEVANCE
personal protection equipment (PPE) and/
or wait until the machine has cooled.
Read the instructions compulsorily
It is compulsory to It is compulsory to disconnect power protect the hearing
supply
It is compulsory to keep the safety signal well clean to ensure their good visibility.
It is absolutely forbidden to remove and/or damage the safety signals applied to the machine.
It is compulsory to replace the safety signals worn out requesting to the manufacturer and/or authopized dealer.
PERSONAL PROTECTION EQUIPMENT (PPE)
The authorized operators are not allowed to wear cloths and accessories that may be entangled in the machine. It is compulsory to use the ppe foreseen by the manufacturer. The authorized operators must compulsorily use the ppe foreseen by the manudacturers of the tools used and according to the processing type.
MACHINE USE DESTINATION OF USE FIELD OF USE Industrial, raft and civil sector.
PLACE OF USE
Indoor or outdoor (provided that it is not subject to atmospheric agents) sufficiently lighted, ventilated, with ambient air temperature and humidity values complying, suitable in compliance with the law provision in force in the country of use on safety and health in the places of work. The machine has to lean on a surface assuring its stability with reference to its weight and its overall dimensions.
CAUTION IT IS COMPULSORY TO KEEP THE MACHINE OUT OF THE REACH OF CHILDREN.
FORESEEN USE
OPERATORS CHARGED WITH THE USE
Air compression (without oil) for the use of suitable pneumatic tools complying with the regulations in force. (ex: guns for blowing, inflation, washing, painting or sandblasting; screwers; spot welders, riveters or greasers).
An authorized operator meeting the professional requirements described.
5
USE LIMITS
CHECKS BEFORE SWITCHING ON
EN
This machine was designed and produced exclusively for the
intended use described in par.9 , any other use and operation
is therefore absolutely forbidden in order to assure in every
moment the safety of the charged operators, as well as the
Before switching-on of the machine, the authorized operators must compulsory perform the following checks.
efficiency of machine itself.
1. Make sure that there are not any non-authorized persons
COMMAND DEVICES They are shown 1. Power supply cable 2. Pressure switch 3. “ON-OFF” switch 4. Pressure regulator at output 5. Fast air outlet tape 6. Pressure gauge at output 7. Tank pressure gauge
close to the machine.
2. Make sure that the safety devices are integral and properly installed and working .
3. Make sure that the machine is properly positioned . 4. Make sure that the “ON-OFF” switch or selector is positioned
on “OFF (0)”.
5. Make sure that the condensate drain valve is closed . 6. Use the compulsory personal protection devices (PPE) . 7. Make sure that you have read and understood the “Use and
Maintenance Instructions ” in all its parts.
2
3
45
1
7
8
It is strictly forbidden to commission the machine in environments with potentially explosive atmosphere and/or in presence of combustible dusts (ex: wood
dusts, flours, sugars and middlings).
Limitations in use: it is strictly forbidden to use the machine for improper used, differing from the foreseen use (par.9).
It is compulsory to keep the machine out of the reach of children.
During the use, it is compulsory to verify that nonauthorized people do not get close to the machine.
It is strictly forbidden to use air tubes (extensions), fittings, and tools not suitable and/or not complying with the regulations in force.
It is strictly forbidden to life the machine with cranes and/or fork lift trucks.
It is strictly forbidden to direct compressed air jets against persons, animals and things. It is strictly forbidden to use the machine to transport and/or lift persons, animals and things. It is strictly forbidden to get on the machine. It is strictly forbidden to tow the machine by any means and/or vehicle whatsoever.
It is strictly forbidden to move the machine manually on upwards and/or downwards slopes with
hazardous grade.
Hazard of burning by accidental contact with the bi-cylindrical pumping assembly and the electric motor. Caution! There is a residual risk.
MACHINE SWITCHING ON
The authorized operators can switch on the machine only after having compulsorly performed the checks described. Before using this machine, the authorized operators must read and understand this manual in all its part. During the use, it is compulsory to verify that nonauthorized people do not get close to the machine. The authorized operators are not allowed to let the machine unattended during operation and maintenace interventions. Hazard of burning by accidental contact with the bi-cylindrical pumping assembly and the electric motor. Caution! There is a residual risk. The manufacturer declines all liability for damages to persons, animals and things, due to the inobservance of the standards and warnings described in this manual. The manufacturer declines all liability on the final result of the processing given that it depends expends exclusively on the type of tool used and on the professional skils of the authorized operators.
1. Connect the machine to the mains by inserting the power supply plug in the proper outlet;
2. Switch on the machine by pulling the “ON-OFF” switch in pos. “ON (I)” (the machine works until the max. operation pressure of 10 bar is reached, then it stops automatically);
3. Adjust pressure at output using the proper regulator, according to the used tool and to the type of processing. Check pressure in the proper pressure gauge ;
It is forbidden to screw the pressure regulator at output. Beyond the end of stroke, in order to avoid damaging the membrane.
4. Connect the tool to the air tube (extension); 5. Connect the air tube (extension) to the fast air
outlet tap of the machine;
It is strictly forbidden to use air tubes (extensions), fittings, and tools not suitable and/or not complying with the regulations in force. It is compulsory to use air tubes (extensions), fittings, and tools, complying with the provisions
6
contained in the use and maintenance instructions supplied by the related manufacturers.
6. Perform the processing (the machine restarts automatically when the operation pressure falls under 7 bar);
7. Once the processing has ended, switch off the machine as described.
changes exceeding the tolerances foreseen by the
EN
distributing entity (voltage ± 10% – frequency ± 2%).
Should it be necessary, it is compulsory to connect
the machine exclusively to generating sets with a
power greater than the installed electric power. To
support the absorption peak at start.
MACHINE SWITCHING OFF
0 bar
At the end of the work cycle, switch
off the machine as follows:
1. Switch off the machine by pressing the “ON-OFF” switch on pos. “OFF (0)”;
2. Disconnect the machine from the mains by removing the power supply plug from the proper outlet;
3. Disconnect the tool from the air tube (extension);
4. Disconnect the air tube (extension) from the fast air outlet tap
of the machine;
5. Drain the condensate from the tank only in case of work cycle end.
RESTORABLE THERMAL PROTECTION TRIPPING
RESET
0 bar
Should a current overload and/or short-circuit
occur in the electric plant of the machine,
the restorable thermal switch trips stopping
the electric motor. To reset the restorable
thermal switch, proceed as follows;
1. Press the “ON-OFF” switch on pos. “OFF (0)”; 2. Press the restorable thermal push-button; 3. Before restarting the machine wait some minutes.
Should the machine, after having performed the rest, not switch on, the charged operator must compulsory seek the intervention of the maintenance technical engineers
and/or of the authorized dealer.
CONNECTIONS
ELECTRICAL CONNECTIONS 0 The machine can be connected to the mains
bar
by inserting the power supply plug in the proper outlet.
CONNECTION OF THE AIR TUBE (EXTENSION) AND OF THE TOOLS
1.Connect the tools to the air tube (extension); 2.Connect the air tube (extension) to the
fast air outlet tap of the machine.
It is strictly forbidden to use air tubes (extensions), fittings, and tools not suitable and/or not complying with the regulations in force. It is compulsory to use air tubes (extensions), fittings, and tools, complying with the provisions contained in the use and maintenance instructions supplied by the related manufacturers. The anufacturer declines all liability for damages to persons, animals and things due to the inobservance of the above described warnings.
EMERGENCY STOP
EMERGENCY STOP
The switching-off of the machine can be performed by pressing the “ON-OFF” switch on pos. “OFF (0)”. In order to avoid situations of imminent or close hazard, the authorized operators must compulsorily perform the following operations: 1. Press the “on-off” switch On pos. “Off (0)” in the right time. 2. Immediately inform the “safety manager” of the emergency (if the machine is used in a company).
SWITCHING ON AFTER AN EMERGENCY STOP
Only and exclusively after having removed the emergency causes and having carefully assessed that the same have not caused damaged and/or anomalies to the machine, with the consent of the “Safety Manager” (In case the machine is used in a company), switch on the machine as described.
The mains to which the machine is connected
must comply with the requirements foreseen by the regulation in force in the country of use, as well as meet the technical features quoted in par.2 And be
equipped with a proper “earthing” plant.
Any type of electric material used for the connection must suit the use, be marked “ce” if subjected to the low voltage directive 2006/95/ec, and comply with the requirements set forth by the regulations in force in the country of use of the machine. The inobservance of the above described warnings
can cause irreparable damages to the electric
equipment of the machine and the following
expiration of the warranty. The manufacturers declines all liability for fauilts or malfunctions of the machine due to voltage sudden
7
EN
MAINTENANCE
STATE OF “SWITCHED OFF MACHINE”
SUPPLEMENTARY MAINTENANCE
0 bar
It includes all activities performed in order
to maintain the proper use and operation
0 bar
Before performing any type of maintenance and/or
adjustment intervention on the machine, it is necessary
to compulsorily drain the tank (no pressure), to
disconnect power supply source, as well as to verify
that the machine is actually stopped and cannot be
switched on suddenly (ON-OFF switch on pos. `’OFF
conditions of the machine through different
types of interventions (adjustments, replacements, etc.) carried out exclusively by the technicians of the manufacturer at the established frequency or in case of failure or wear.
(0)” and power supply cable disconnected from the mains outlet and positioned close to the machine).
For any supplementary maintenance intervention, compulsory request the technical assistance to the
manufacturer of the authorized dealer.
ROUTINE MAINTENANCE
0 bar
It includes all activities performed in order to
maintain the proper use and operation conditions
of the machine through different type of
intervention (adjustments, visual checks, cleaning
of air filters, etc.) carried out by the authorized
maintenance technical engineer at the established
frequency.
The authorized operators must perform exclusively the operations of their specific competence. And with the consent of the company safety manager (if the machine is used in a company). The authorized operators are not allowed to leave the
machine unattended during its operation and during
maintenance operations.
ROUTINE MAINTENANCE TABLE
DEMOLITION
0 bar
When the machine is demolished,
compulsorily observe the provisions of the
regulations in force.
Separate the parts making up the machine
according to the different construction
materials (plastic, copper, iron, etc.).
TROUBLE CAUSES TROUBLESHOOTING
0 bar
The following table gives a series of
situations that can occur during the
use of the machine.
The authorized operators must perform exclusively the operations of their specific competence. And with the consent of the company safety manager (if the machine is used in a company).
FREQUENCY POINT OF INTER- TYPE OF INTER-
VENTION
VENTION
EVERY DAY
1
Safety devices
Power supply cable and plug
Make sure that they are integral, properly installed and working.
Visual check of the wear state.
At every work cycle
end lean the machine
on the ground and
Tank
drain the condensate
from the tank, opening
the condensate
valve .
EVERY WEEK
Wheels
Tire pressure control. If necessary, inflate with compressed air up to max. 2.5 bar
7
Unscrew the screw;
Remove the cover;
Extract the filter; and
No.2 Air filters, front and rear side
clean it with air;
Re-assemble the cover properly.
N.B.:REPLACE
IN CASE OF
CLEAR WEAR.
TROUBLE
CAUSES
TROUBLESHOOTING
The machine does not switch on or stops and does not restart.
Lack of power supply.
Tripping of the restorable thermal switch due to current overload and/or shortcircuit.
1. Make sure that the “ONOFF ” switch is on pos. “ON (I)”;
2. Check that the power supply cable plug is working and properly inserted in the suitable outlet;
3. Check that possible extensions used and the power supply outlet are working;
4. Check that the main switch of the mains is working and positioned on “ON (I)”.
Follow the procedure described.
The machine starts many times without using the tools.
Leaks from the air tube,
1. Check that the pneumatic plant has not been damaged;
the tool or the
pneumatic plant.
2. Check the integrity and the connection of the air tube and of the tool.
8
TROUBLE
CAUSES
TROUBLESHOOTING
PACKAGING
EN
The tank in not under pressure.
Switch on the machine and wait until the tank is loaded verifying the pressure on the proper pressure gauge.
MACHINE TRANSPORT AND HANDLINGT The machine can be transported manually by two charged
Air does not come out from the tool.
Wrong adjustment of the output
Check that the value indicated on the pressure gauge at output is greater
operators by seizing it by the bearing foot and the handle or handled manually by a charged operator using the handle and the wheels with which it is equipped.
pressure.
than 0 (zero) bar.
The tool is damaged.
Check the integrity and efficiency of the tool.
Pressure decrease in the air tank.
Leaks from the air tube, the tool or the pneumatic plant.
1. Check the integrity of the pneumatic plant.
2. Check the integrity of the air tube and of the tool.
3. Verify that the machine air tube and air tube tool connections are right.
4. Make sure that the condensate drain valve is well closed.
Tripping of the Pressure safety valve. switch faulty.
Air leak from
the valve of the pressure switch with stopped
Check valve dirty or worn.
machine.
Apply to an authorized dealer.
The machine vibrates and/ or emits a lot of noise.
Mechanical break.
Frequent starts Air filters and low yield. dirty.
Clean the filters.
The transport of the manchine must compulsorily be carried out by two charged operators in compliance with the regulations on the “manual handling of loads”, in order to avoid unfavourable ergonomic conditions that may involve risks of spine/lumbar lesions.
PACKAGING The machine is packed by the Manufacturer in a cardboard box equipped with two handles and containing No. 1 Dry compressor and No. 1 Use and maintenance instructions.
UNPACKING Once the package has been positioned on the floor, on an even surface assuring its stability, unpack the machine removing it from the package observing the instructions contained.
SPARE PARTS
Original spare parts for possible replacements are to be requested exclusively to the manufacyurer or to the authorized dealer. It is strictly forbidden to replace any components of the machine with non original spare parts.
It is recommended to dispose the package according to the different types of materials in full observance of the laws in force in the country of use.
POSITIONING 0 The machine must be used in a work place having bar the features described, positioned on an even floor assuring its stability relation to its overall dimensions and weight.
Ain order to allow the authorized operators to work in safe places, it is suggested to assure a minimum distance (1 m) from others, objects and/or obstructions.
STORAGE
0 bar
If the machine is not used for a long time, it is neces-
sary to store it in a safe place, provided with proper
temperature and humidity, as well as to protect it
against dust.
Before storing the machine, it is recommended to drain
the condensate from the air tank.
9
EN
TECHNICAL SPECIFICATIONS
AC4504
Power voltage / Frequency
V / Hz
Rated power
kW
Max. operation pressure
Bar
Assured noise pressure level (Dir.2000/14/CE)
dB
Motor shaft rotation speed
Rpm
Tank volume
litres
Yield (sucked / delivered)
Vmin
Ambient air temperature / humidity / %
Overall weight
Kg
Dimensions (bxlxh)
mm
230 / 50 0.24 8
58
1420 4 45 / 28 5 – 40 / 5 – 95 11 355x258x290
AC8305
Power voltage / Frequency
V / Hz
Rated power
kW
Max. operation pressure
Bar
Assured noise pressure level (Dir.2000/14/CE)
dB
Motor shaft rotation speed
Rpm
Tank volume
litres
Yield (sucked / delivered)
Vmin
Ambient air temperature / humidity / %
Overall weight
Kg
Dimensions (bxlxh)
mm
230 / 50 0.35 9
60
1400 5 83 / 33 5 – 40 / 5 – 95 14.1 435x410x270
AC24050
Power voltage / Frequency
V / Hz
Rated power
kW
Max. operation pressure
Bar
Assured noise pressure level(Dir.2000/14/CE)
dB
Motor shaft rotation speed
Rpm
Tank volume
litres
Yield (sucked / delivered)
Vmin
Ambient air temperature / humidity / %
Overall weight
Kg
Dimensions (bxlxh)
mm
230 / 50 1.5 9
72
1400 50 240 / 170 5 – 40 / 5 95 40.5 730x410x730
AC24016
Power voltage / Frequency
V / Hz
Rated power
kW
Max. operation pressure
Bar
Assured noise pressure level (Dir.2000/14/CE)
dB
Motor shaft rotation speed
Rpm
Tank volume
litres
Yield (sucked / delivered)
Vmin
Ambient air temperature / humidity / %
Overall weight
Kg
Dimensions (bxlxh)
mm
230 / 50 1.5 9
72
1400 16 240 / 170 5 – 40 / 5 95 42.5 720x510x495
AC10304
Power voltage / Frequency
V / Hz
Rated power
kW
Max. operation pressure
Bar
Assured noise pressure level (Dir.2000/14/CE)
dB
Motor shaft rotation speed
Rpm
Tank volume
litres
Yield (sucked / delivered)
Vmin
Ambient air temperature / humidity / %
Overall weight
Kg
Dimensions (bxlxh)
mm
230 / 50 0.55 9
60
1400 4 103 / 55 5 – 40 / 5 95 17.1 405x375x335
AC24080
Power voltage / Frequency
V / Hz
Rated power
kW
Max. operation pressure
Bar
Assured noise pressure level (Dir.2000/14/CE)
dB
Motor shaft rotation speed
Rpm
Tank volume
litres
Yield (sucked / delivered)
Vmin
Ambient air temperature / humidity / %
Overall weight
Kg
Dimensions (bxlxh)
mm
230 / 50 1.5 9
72
1400 80 240 / 170 5 – 40 / 5 95 63.5 545x465x1210
AC12810
AC32024
Power voltage / Frequency
V / Hz 230 / 50
Power voltage / Frequency
V / Hz 230 / 50
Rated power
kW
0.75
Rated power
kW
2.2
Max. operation pressure
Bar
9
Max. operation pressure
Bar
10
Assured noise pressure level (Dir.2000/14/CE)
dB
65
Assured noise pressure level (Dir.2000/14/CE)
dB
78
Motor shaft rotation speed
Rpm 1420
Motor shaft rotation speed
Rpm 1400
Tank volume
litres 10
Tank volume
litres 24
Yield (sucked / delivered)
Vmin
Ambient air temperature / humidity / %
128 / 80 5 – 40 / 5 95
Yield (sucked / delivered)
Vmin
Ambient air temperature / humidity / %
320 / 230 5 – 40 / 5 95
Overall weight
Kg
25.8
Overall weight
Kg
54
Dimensions (bxlxh)
mm
495x437x459
Dimensions (bxlxh)
mm
800x560x535
Service class for all modeis: S3 – 20mn ON/ 10mn OFF
AC12824
Power voltage / Frequency
V / Hz
Rated power
kW
Max. operation pressure
Bar
Assured noise pressure level (Dir.2000/14/CE)
dB
Motor shaft rotation speed
Rpm
Tank volume
litres
Yield (sucked / delivered)
Vmin
Ambient air temperature / humidity / %
Overall weight
Kg
Dimensions (bxlxh)
mm
230 / 50 0.75 9
65
1420 24 128 / 80 5 – 40 / 5 95 22.0 571x280x575
RESERVED RIGHTS
The reserved rights on this manual “use and maintenance instructions” remain property of the manufacturer. None part of this manual can be reproduced and disclosed (totally or partially) by any reproduction means without written authorization of the Manufacturer. All quoted trademarks belong to the respective owners.
10
INHALTSVERZEICHNIS
BEDEUTUNG DER BETRIEBSANLEITUNG
12
EMPFÄNGER …………………………………………………………………………………………………………….12
DE
RHEITSHINWEISE ……………………………………………………………………………………………………..12 Angewandte Sicherheitsvorkehrungen ……………………………………………………………………………………………… 12 Sicherheitskennzeichnungen……………………………………………………………………………………………………………. 13 Persönliche Schutzausrüstung (Psa) ………………………………………………………………………………………………… 13 Restrisiken…………………………………………………………………………………………………………………………………….. 13
MASCHINENEINSATZ………………………………………………………………………………………………..13
Bestimmungszweck………………………………………………………………………………………………………………………… 13
Verwendungsgrenzen……………………………………………………………………………………………………………………… 14
Steuereinrichtungen ……………………………………………………………………………………………………………………….. 14
Kontrollen Vor Dem Einschalten ………………………………………………………………………………………………………. 14
Einschalten Der Maschine……………………………………………………………………………………………………………….. 14
Ausschalten Der Maschine………………………………………………………………………………………………………………. 15
Wiederherstellung Der Wärmeschutz Auslösung
15
ANSCHLÜSSE …………………………………………………………………………………………………………..15
Elektrische Anschlüsse……………………………………………………………………………………………………………………. 15
Anschluss Des Luftschlauches (Verlängerung) Und Der Werkzeuge
15
NOT-AUS……………………………………………………………………………………………………………………15 Not-Aus…………………………………………………………………………………………………………………………………………. 15 Wiedereinschalten Nach Einem Not-Aus …………………………………………………………………………………………… 16
WARTUNG …………………………………………………………………………………………………………………16 Zustand Der Ausgeschalteten Maschine ……………………………………………………………………………………………. 16 Routinewartung ……………………………………………………………………………………………………………………………… 16 Zusätzliche Wartung ………………………………………………………………………………………………………………………. 16 Demontierung ……………………………………………………………………………………………………………………………….. 16 Fehler Ursachen Fehlerbehebung……………………………………………………………………………………………….. 16 Ersatzteile …………………………………………………………………………………………………………………………………….. 17
VERPACKUNG …………………………………………………………………………………………………………..18 Maschinentransport Und Handhabung………………………………………………………………………………………………. 18 Verpackung …………………………………………………………………………………………………………………………………… 18 Auspacken ……………………………………………………………………………………………………………………………………. 18 Positionierung ……………………………………………………………………………………………………………………………….. 18 Aufbewahrung ……………………………………………………………………………………………………………………………….. 18
TECHNISCHE DATEN ………………………………………………………………………………………………..19 VORBEHALTENE RECHTE …………………………………………………………………………………………19 KONFORMITÄTSERKLÄRUNG ………………………………………………………………………………..199 GARANTIE ……………………………………………………………………………………………………………….202
11
