ADL10-E Din Rail Energy Meter
241
ADL10-E
ACREL Co,.Ltd
Declare
The copyright is the property of Acrel. Any information in any paragraph or section cannot be extracted, copied or otherwise reproduced or propagated. Otherwise offenders shall take all consequences.
All rights are reserved.
Acrel reserves the right to modify the product specifications herein without notification. Please consult the local agent about the latest specifications before placing a purchase order.
1 General…………………………………………………………………………………………………………………. 1 2 Functions………………………………………………………………………………………………………..1 3 Technical parameter………………………………………………………………………………………… 1 4 Outline……………………………………………………………………………………………………………2 5 Wiring and installing…………………………………………………………………………………….3 6 Display description…………………………………………………………………………………………. 3 7 Communication description………………………………………………………………………………3
1 General
ADL10-E LCD IEC62053-21IEC62053-22
ADL10-E single phase electric energy meter is a new generation energy meter designed by Acrel Co,.Ltd with many years’ experience in designing electricity meters. Measurement, statistic, communication and LCD display functions are installed in the power meter. This power meter has advantages of high stability, low power consumption and data saving after blackout etc. All meters
meet the related technical requirements of electronic power meter in the IEC62053-21 IEC62053-22 standards.
2 Functions
Function
Function description
Measurement of kWh
Measurement of electrical parameters
LCD LCD Display
Communication
() Single-phase active kWh (positive and negative) UI PQSPFF Voltage, Current, Active power, Reactive power, Apparent power, Power factor and Frequency 8 LCD 8 bits section LCD display RS485 MODBUS-RTU Communication interface: RS485, Communication protocol: MODBUS-RTU
( means standard; means optional)
3 Technical parameter
3.1 Electric performance
Reference voltage
Input voltage
Reference frequency
Power consumption
Input current
Basic current
AC220V 50Hz <10VA 10A
Function provide
C
Measurement performance
Communication
Maximum current Starting current Consumption Accuracy of measuring Range of measuring Interface Connection mode Protocol
60A
0.004Ib
<4VA () (Maximum current)
1 1 Class 000000.00~999999.99kWh
RS485(A+B-)
Shielded twisted pair conductors MODBUS-RTUDL/T645-07
3.2 Mechanical performance
××
18mm×96 mm×70mm
Outline (Length × Width × Height)
3.3 Work environment
Range of temperature
Working temperature
Storing temperature
Relative humidity Altitude
-25~55 -40~70 95%(No condensation) <2000m
4 Dimension drawings
4.0N·m
5 Wiring and installing
5.1 Wiring diagram
5.2 Installing notices ADL10
ADL10 single phase electric meter used the direct connecting method. Please pay attention to the direction of input and output while wiring and screw tightly (torque less than 12Nm) prevent the
meter from the abnormal work.
6 Display description
The meter shows total energy first while turning on and then shows voltage, current and power, etc. in turn. The example shows as following:
Current total energy 12.34kWh Current voltage 220.0V
Current current10.00A
Current power 2.20kW
Power factor 1.00
Current even test, baud rate 9600
Current address 001
Current version V1.00
7 Communication description
7.1 Communication protocol MODBUS-RTU DL/T645-2007
The meters adapt Modbus and DL/T645 protocol. Please refer to the relevant standards for
more information.
7.2 MODBUS Communication address table
Address Variable
Length
R/W
0000H
4
R
0001H 0002H
Current total electricity
…
Reserved
000AH 000BH 000CH
Voltage Current
2
R
2
R
000DH
2
R
000EH
Active power
2
R
000FH
Reactive power
2
R
Apparent power
0010H
2
R
0011H
Power factor
2
R
0012H
Frequency
…
Reserved
0014H
0015H
Address
1
R/W
0015H
Communication baud rate
1
R/W
0016H … 0047H
0048H
0049H …
Reserved
Method of testing Device ID
2
R/W
6
R/W
Notes unit: 0.01kWh
unit0.1V unit0.01A unit 0.001kw unit 0.001kvar unit 0.001kVA unit0.001
unit 0.01Hz
1247
009600 014800 022400 03:1200
02: even 00: none
004BH
004CH
4
004DH Forward reactive electric energy
004EH
004FH Reversing reactive electric energy
4
0050H … 0067H
Reserved
0068H 0069H
Forward active electric energy
4
006AH … 0071H
Reserved
0072H
4
0073H
Reversing active electric energy
R
unit 0.01kWh
unit
R
0.01kWh
R
0.01kWh
R
0.01kWh
