GS-120 Wood Chipper
Product Information
The product is an assembly consisting of various components,
including an infeed hopper, discharge chutes, tires, support feet,
emergency stop switch, and other spare parts. It is designed to be
installed on a foundation for efficient operation.
Assembly Steps:
- Complete the installation of the infeed hopper to the
foundation. - Install Discharge chute 1 to the foundation, ensuring that
rubber pads are used for connections. - Connect the tires to the foundation using the tire axle.
- Assemble the support feet to the foundation.
- Install Infeed hopper 2 to Infeed hopper 1.
- Install Discharge 2 and Discharge 3 to Discharge 1.
- Install the emergency stop switch bracket on Infeed hopper 1
and mount the emergency stop switch on the bracket. Ensure that the
emergency stop switch wire harness is passed through the middle
tube of the feed inlet and connected to the engine.
Spare Parts:
| Name | Part | Qty |
|---|---|---|
| Tire | Bolt M10*30 | 4 |
| Infeed hopper 1 | Flat Washer 10 | 8 |
| Infeed hopper 2 | Spring Washer 10 | 4 |
| Discharge 1 | Washer 10 | 4 |
| Discharge 2 | Nut M10 | 4 |
| Discharge 3 | Bolt M10*50 | 2 |
| Emergency stop switch | Bolt M8*20 | 3 |
| Flat Washer 10 | 6 | |
| Screw Nut M10 | 2 | |
| Screw Nut M8 | 3 |
Note: It is important to read the manual before
installation to avoid errors. If any accessories are missing during
assembly, please contact sales for immediate replacement.
Assembly steps
1,Complete infeed hopper install to foundation . 2, Discharge chute 1 install to foundation
Noticed The connection put rubber pad
Noticed The connection put rubber pad
Spare part Qty
Bolt M10* 30
4
Flat
8
Washer 1 0
S pring
4
washer 1 0
Nut M10
4
. ………………………………………………………………………………………………………
3,Connect tires to the foundation with the tire axle 4.The support feet assemble to
Spare part Qty
foundation
Bolt M1 0 * 3 0
4
Flat
8
Washers 1 0
S pring
4
washer 1 0
Noticed Install the tire with the air hole facing outward.
Nut M10
4
……………………………………………………………………………………………………………………………………………………..
5.Infeed hopper2 install to infeed hopper 2
6 . Discharge 2 . 3 install to
Spare part Qty
discharge 1
Bolt M10* 50
2
Bolt M8 * 2 0
3
Flat Washer 1 0 4
Flat Washer 8
6
Fasten the
2
screw nut M1 0
Fasten the
3
………………………….sc.r.e.w..n.u.t.M..8………………………………………………………
7 . Install the emergency stop switch bracket on
the infeed hopper 1 , and install the emergency
stop switch on the emergency stop bracket
Noticed Pass the emergency stop switch wire harness through the middle tube of the feed inlet and connect it with the engine.
Spare part
Name
Part
QTY
Foundati
1
on
Name Tire
Part
QTY
2
Infeed
1
Support
1
hopper 1
feet
Stop
1
Infeed
1
switch
hopper 2
bracket
Discharg e chute1
Emergency
1
stop switch
1
(including
glasses)
Discharge
1
chute2.3
Head set
1
Infeed
rubber
1
Spark
plug
1
mat
wrench
Discharg
e chute
1
Bolts
1
mat
Shaft
Manual 1
book
As your required
Noticed
Be sure to read this manual before installation to avoid installation errors. If you find that there is a shortage of accessories during assembly due to the negligence of the company, please contact sales immediately for replacement. Sorry for any inconvenience caused, thank you for your cooperation.
