USRP-2930 Software Defined Radio Device

Product Information:

Product Name: USRP-2930
Model: USRP-2930/2932
Specifications:
- Bandwidth: 20 MHz
- Connectivity: 1 Gigabit Ethernet
- GPS-Disciplined OCXO
- Software Defined Radio Device

Product Usage Instructions:

Before installing, configuring, operating, or maintaining the
USRP-2930, it is important to read the user manual and any
additional resources provided. Familiarize yourself with the
installation, configuration, and wiring instructions, as well as
the requirements of all applicable codes, laws, and standards.

Safety Precautions:

Follow the safety compliance standards and take precautions to
avoid any potential risks or damage:

Notice Icon: Take precautions to avoid data
loss, loss of signal integrity, degradation of performance, or
damage to the model.
Caution Icon: Consult the model documentation
for cautionary statements to avoid injury.
ESD Sensitive Icon: Take precautions to avoid
damaging the model with electrostatic discharge.

Safety Compliance Standards:

Ensure compliance with safety certifications and standards:

For UL and other safety certifications, refer to the product
label or the Product Certifications and Declarations section.

Electromagnetic and Radio Equipment Compatibility
Guidelines:

Follow the guidelines to ensure electromagnetic and radio
performance:

Notice: Operate this product only with
shielded cables and accessories. The DC power input cables may be
unshielded.
Notice: The length of all I/O cables, except
those connected to the Ethernet and GPS antenna ports, must be no
longer than 3 m to ensure specified performance.
Notice: This product is not approved or
licensed for transmission over the air using an antenna. Operating
this product with an antenna may violate local laws. It is approved
for signal reception using a GPS antenna in the appropriate port.
Ensure compliance with local laws before using an antenna other
than a GPS receive antenna.
Notice: To prevent disruption to the
performance of this product, employ industry-standard ESD
prevention measures during installation, maintenance, and operation
to avoid Electrostatic Discharge (ESD) damage.

Electromagnetic Compatibility Standards:

Follow the electromagnetic compatibility standards:

Note: Group 1 equipment (per CISPR 11) refers
to industrial, scientific, or medical equipment that does not
intentionally generate radio frequency energy for material
treatment or inspection/analysis purposes.
Note: In the United States (per FCC 47 CFR),
Class A equipment is intended for use in commercial,
light-industrial, and heavy-industrial locations. In Europe,
Canada, Australia, and New Zealand (per CISPR 11), Class A
equipment is intended for use only in non-residential
locations.
Note: For EMC declarations, certifications,
and additional information, refer to the Product Certifications and
Declarations section.

Radio Equipment Compatibility Standards:

Use the radio equipment in accordance with the following
parameters:

Antenna: 5 V GPS receiver antenna, part number 783480-01
Software Compatibility: LabVIEW, LabVIEW NXG, LabVIEW
Communications System Design Suite
Frequency Band: 1,575.42 MHz

View Fullscreen

USRP-2930

SAFETY, ENVIRONMENTAL, AND REGULATORY INFORMATION
USRP-2930/2932
20 MHz Bandwidth, 1 Gigabit Ethernet, GPS-Disciplined OCXO, USRP Software Defined Radio Device
Read this document and the documents listed in the additional resources section about installation, configuration, and operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards.
Regulatory Icons
Notice Take precautions to avoid data loss, loss of signal integrity, degradation of performance, or damage to the model.
Caution Take precautions to avoid injury. Consult the model documentation for cautionary statements when you see this icon printed on the model.
ESD Sensitive Take precautions to avoid damaging the model with electrostatic discharge.
Safety
Caution Observe all instructions and cautions in the user documentation. Using the model in a manner not specified can damage the model and compromise the built-in safety protection. Return damaged models to NI for repair. Attention Suivez toutes les instructions et respectez toutes les mises en garde de la documentation utilisateur. L’utilisation d’un modèle de toute autre façon que celle spécifiée risque de l’endommager et de compromettre la protection de sécurité intégrée. Renvoyez les modèles endommagés à NI pour réparation. Caution The protection provided by the model can be impaired if it is used in a manner not described in the user documentation.
Attention La protection apportée par le modèle risque d’être endommagée s’il est utilisé d’une autre façon que celle décrite dans la documentation utilisateur.
Safety Compliance Standards
This product is designed to meet the requirements of the following electrical equipment safety standards for measurement, control, and laboratory use: · IEC 61010-1, EN 61010-1 · UL 61010-1, CSA C22.2 No. 61010-1
Note For UL and other safety certifications, refer to the product label or the Product Certifications and Declarations section.
Electromagnetic and Radio Equipment Compatibility Guidelines
This product was designed to support an efficient use of the radio spectrum to avoid harmful interference. This product was tested and complies with the regulatory requirements and limits for electromagnetic compatibility (EMC) as stated in the product specifications. These requirements and limits are designed to provide reasonable protection against harmful interference when the product is operated in its intended operational electromagnetic environment. This product is intended for use in commercial and light-industrial locations. However, harmful interference may occur in some installations, when the product is connected to a peripheral device or test object, or if the product is used in residential areas. To minimize interference with radio and television reception and prevent unacceptable performance degradation, install and use this product in strict accordance with the instructions in the product documentation. Furthermore, any changes or modifications to the product not expressly approved by NI could void your authority to operate it under your local regulatory rules.
Electromagnetic and Radio Performance Notices
Refer to the following notices for cables, accessories, and prevention measures necessary to ensure the specified electromagnetic and radio performance. Notice Operate this product only with shielded cables and accessories. The DC power input cables may be unshielded.

Notice To ensure the specified electromagnetic and radio performance, the length of all I/O cables except those connected to the Ethernet and GPS antenna ports must be no longer than 3 m.
Notice This product is not approved or licensed for transmission over the air using an antenna. As a result, operating this product with an antenna may violate local laws. This product is approved for signal reception using a GPS antenna in the appropriate port. Ensure that you are in compliance with all local laws before operating this product with an antenna other than a GPS receive antenna.
Notice The performance of this product can be disrupted if subjected to Electrostatic Discharge (ESD) during operation. To prevent damage, industry-standard ESD prevention measures must be employed during installation, maintenance, and operation.
Electromagnetic Compatibility Standards
This product meets the requirements of the following EMC standards for electrical equipment for measurement, control, and laboratory use: · EN 61326-1 (IEC 61326-1): Class A emissions; Basic immunity · EN 55011 (CISPR 11): Group 1, Class A emissions · AS/NZS CISPR 11: Group 1, Class A emissions · FCC 47 CFR Part 15B: Class A emissions · ICES-003: Class A emissions
Note Group 1 equipment (per CISPR 11) is any industrial, scientific, or medical equipment that does not intentionally generate radio frequency energy for the treatment of material or inspection/analysis purposes.
Note In the United States (per FCC 47 CFR), Class A equipment is intended for use in commercial, light-industrial, and heavy-industrial locations. In Europe, Canada, Australia and New Zealand (per CISPR 11) Class A equipment is intended for use only in non-residential locations.
Note For EMC declarations, certifications, and additional information, refer to the Product Certifications and Declarations section.

Radio Equipment Compatibility Standards
This product meets the requirements of the following Radio Equipment standards: · ETSI EN 301 489-1: Common Technical Requirements for Radio Equipment · ETSI EN 301 489-19: Specific conditions for GNSS receivers operating in the RNSS band (ROGNSS) providing positioning, navigation, and timing data · ETSI EN 303 413: Satellite Earth Stations and Systems (SES); Global Navigation Satellite System (GNSS) receivers
This radio equipment is for use in accordance with the following parameters:

Antenna Software Frequency band(s)

5 V GPS receiver antenna, part number 783480-01 LabVIEW, LabVIEW NXG, LabVIEW Communications System Design Suite 1,575.42 MHz

Notice Every country has different laws governing the transmission and reception of radio signals. Users are solely responsible for using their USRP system in compliance with all applicable laws and regulations. Before you attempt to transmit and/or receive on any frequency, National Instruments recommends that you determine what licenses may be required and what restrictions may apply. National Instruments does not accept any responsibility for the user’s use of our products. The user is solely responsible for complying with local laws and regulations.

Environmental Guidelines
Notice This model is intended for use in indoor applications only.

Environmental Characteristics

Temperature and Humidity
Operating Temperature Operating Humidity Pollution Degree Maximum altitude

0 °C to 45 °C 10% to 90% relative humidity, noncondensing 2 2,000 m (800 mbar) (at 25 °C ambient temperature)

Shock and Vibration
Operating shock Random Vibration
Operating Nonoperating

30 g peak, half-sine, 11 ms pulse
5 Hz to 500 Hz, 0.3 grms 5 Hz to 500 Hz, 2.4 grms

Environmental Management
NI is committed to designing and manufacturing products in an environmentally responsible manner. NI recognizes that eliminating certain hazardous substances from our products is beneficial to the environment and to NI customers.

2 | ni.com | USRP-2930/2932

For additional environmental information, refer to the Commitment to the Environment web page at ni.com/environment. This page contains the environmental regulations and directives with which NI complies, as well as other environmental information not included in this document.
Waste Electrical and Electronic Equipment (WEEE)
EU Customers At the end of the product life cycle, all NI products must be disposed of according to local laws and regulations. For more information about how to recycle NI products in your region, visit ni.com/environment/weee.
RoHS
National Instruments (RoHS) National Instruments RoHS ni.com/environment/rohs_china(For information about China RoHS compliance, go to ni.com/environment/ rohs_china.)

Power Requirements

Total power, typical operation Typical Maximum
Power requirement

12 W to 15 W 18 W Accepts a 6 V, 3 A external DC power source

Caution You must use either the power supply provided in the shipping kit, or another listed ITE power supply marked LPS, with the device.

Attention Vous devez utiliser avec l’appareil soit l’alimentation livrée dans le kit, soit une autre alimentation ITE (équipement informatique) agréée, portant le symbole LPS.

Physical Characteristics
Physical dimensions (L × W × H) Weight

15.875 cm × 4.826 cm × 21.209 cm (6.25 in. × 1.9 in. × 8.35 in.) 1.193 kg (2.63 lb)

Maintenance
If you need to clean your device, wipe it with a dry towel.

CE Compliance
This product meets the essential requirements of applicable European Directives, as follows: · 2014/53/EU; Radio Equipment Directive (RED) · 2011/65/EU; Restriction of Hazardous Substances (RoHS)
Product Certifications and Declarations
Hereby, National Instruments declares that the device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. To obtain product certifications and the DoC for NI products, visit ni.com/product-certifications, search by model number, and click the appropriate link.
Additional Resources
Visit ni.com/manuals for more information about your model, including specifications, pinouts, and instructions for connecting, installing, and configuring your system.
Worldwide Support and Services
The NI website is your complete resource for technical support. At ni.com/support, you have access to everything from troubleshooting and application development self-help resources to email and phone assistance from NI Application Engineers. Visit ni.com/services for information about the services NI offers. Visit ni.com/register to register your NI product. Product registration facilitates technical support and ensures that you receive important information updates from NI.

NI corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504. NI also has offices located around the world. For support in the United States, create your service request at ni.com/support or dial 1 866 ASK MYNI (275 6964). For support outside the United States, visit the Worldwide Offices section of ni.com/niglobal to access the branch office websites, which provide up-to-date contact information.
Information is subject to change without notice. Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for information on NI trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the National Instruments Patent Notice at ni.com/patents. You can find information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/ legal/export-compliance for the NI global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES AS TO THE ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS. U.S. Government Customers: The data contained in this manual was developed at private expense and is subject to the applicable limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015. © 2019 National Instruments. All rights reserved. 377753A-01 September 13, 2019
