21170-712 Universal Device Carrier
Product Information
The product is a navigation bracket (Navihalter) designed for
use with the original navigation system of BMW motorcycles. It is
compatible with various models and comes with different components,
including screws, washers, cap nuts, and a threaded washer.
Key Components:
- Navihalter (Navigation Bracket)
- U-Scheibe (Washer M6)
- Hutmutter (Cap Nut M6)
- Linsenflanschschraube (Lens Head Screw M6x14mm)
- Gewindescheibe (Threaded Washer)
- Hutmutter (Cap Nut M5)
- Original Navi-Stecker (Original Navi Connector)
Product Usage Instructions
1. Before starting the installation, it is recommended to remove
the windshield for easier access. Make sure to determine the
desired position of the navigation bracket to avoid contact with
the windshield.
2. Begin by assembling the components:
- Attach the U-Scheibe (Washer M6) to the Navihalter (Navigation
Bracket). - Secure the U-Scheibe (Washer M6) using the Hutmutter (Cap Nut
M6). - Repeat the above step for all three sets of U-Scheibe (Washer
M6) and Hutmutter (Cap Nut M6). - Attach the U-Scheibe (Washer M6) to the Gewindescheibe
(Threaded Washer). - Secure the Gewindescheibe (Threaded Washer) using the Hutmutter
(Cap Nut M5).
3. Once the components are assembled, proceed with the
installation:
- Place the Navihalter (Navigation Bracket) in the desired
position on the motorcycle. - Using the appropriate tools, tighten the screws to the
recommended torque of 2Nm.
4. Connect the Original Navi-Stecker (Original Navi Connector)
to the corresponding port on the motorcycle’s navigation
system.
Note: For specific information on compatibility and optional
components, refer to the product’s Art.Nr. (Article Number)
mentioned in the user manual.
Navihalterung
Navigation bracket | Soporte para GPS | Support pour système de navigation | Supporto per navigatore
Art.-Nr.: 21170-712 Geräteträger Universal / universal device carrier
11
10
9
8
Legende/Key/file Légende
7
Anbau Tipp Fitting tip Astuce de montage Achtung Attention Attention
Schraube Screw Vis Schraubensicherung Thread locking fluid Freinfilets
Vergrößerung Magnification Grossissement Montagepaste Fitting lubricant Lubrifiant de montage
M
Drehmoment Torque
Nm Torque
Reiniger Cleaner Nettoyant
0
100
10
20
30
40
50
60
70
80
90
mm
#
Bezeichnung description
/
DE EN FR
Die Farben der Abbildungen dienen nur der Veranschaulichung. The colors are for illustrating purposes only. Les couleurs utilisées sont à titre indicatif seulement.
DIN
1 Navihalter / navigation bracket
ISO
Menge
Quantity
1
2 Grundplatte mit Klebefläche / adhesive base plate
1
3 U-Scheibe / washer M6
125SA2 7089
3
4 Hutmutter / cap nut M6
917SA2
3
5 U-Scheibe / washer M6
9021SA2 7093
2
6 Linsenflanschschraube / lens head screw M6x14mm
7381SA2 7381SA2
2
7 Flügelschraube / wing screw M5
1
8 Hülse / sleeve 31mm
1
9 Hülse / sleeve 59mm
1
10 Gewindescheibe / threaded washer
1
11 Hutmutter / cap nut M5
917SA2
1
Die Nr. 1 weltweit für hochwertiges BMW Motorradzubehör.
01
Art.-Nr.: 21170-702 orig. Navi / orig. navigation system
4 1
3
6 5
2
1
Wir empfehlen zur einfacheren Montage die
Verkleidungsscheibe zu entfernen. Vorher sollte die
Position des Navihalters festgelegt werden, um einen
Kontakt zur Verkleidungsscheibe zu verhindern.
We recommend for easier installation to remove the windshield. Beforehand, the position of the Navigation bracket should be determined to prevent contact with the windshield.
Pour faciliter l`installation, nous recommandons de retirer le pare-brise. Au préalable, la position du support de navigation doit être déterminée pour éviter tout contact avec le pare-brise.
Markierte Fläche (Bild1) vor dem Bekleben entfetten. Degrease the marked area (Fig.1) before sticking.
Dégraissez la zone marquée (Fig1) avant de coller.
2
3
Die Nr. 1 weltweit für hochwertiges BMW Motorradzubehör.
02
4 Art.Nr.: 21170-702
5 Art.Nr.: 21170-712
6 Art.Nr.: 21170-702 + optional 21098-000
7
Original
BMW
2Nm
Die Nr. 1 weltweit für hochwertiges BMW Motorradzubehör.
03
Original Navi-Stecker
9
Original Navi connector / Connecteur d`origine Navi
8
10
Die Nr. 1 weltweit für hochwertiges BMW Motorradzubehör.
04
