1.6M 1:5 S.E.5a Balsawood Scale Airplane
Product Information:
The Balsawood Scale Airplane SCG42 is a sophisticated flying
model designed for experienced users. It has been flight tested to
meet or exceed performance and reliability standards in normal use.
The wingspan of the airplane is 1.62 meters (63.8 inches) and the
fuselage length is 1.25 meters (49.2 inches). The fly weight of the
airplane is 3.1 kilograms (6.8 pounds).
The suggested equipment for this airplane includes:
- Motor: 3520-4220 800-500KV
- Prop: 14-inch
- ESC: 60-80A4S
- Battery: 4S 2200-4000mAh
- Servo: 17g*4pcs
- Radio: 4CH+
Product Usage Instructions:
Pre-Flight Checks:
- Check and adjust servo centering for better control surface
adjustment. - Double-check the spinning direction of the motor to ensure it
is suitable for your model. - Set the center of gravity (CG) at the position marked in the
manual. Add weight to the nose or tail if necessary for optimal
flight performance. - Check the inside of the fuselage to ensure all equipment is
correctly connected. Verify the surface of the heat-shrink covering
material and ensure all screws, bolts, cabin, and canopy are
secure. - Take great care when connecting/disconnecting the battery.
Replace the battery immediately if low voltage or damage is
detected. - The way the internal devices of the fuselage are connected
depends on your transmitter-receiver device. For devices with more
functions, you can simplify the connection. Check your device for
details. - When pairing the power system and transmitter-receiver device
for the first time, set the maximum stroke of the throttle
accordingly.
Safety Precautions:
- This product is not a toy and should be treated as a
complicated and sophisticated flying model. Your safety depends on
correct operation. - Do not fly around restricted locations such as airports,
military bases, residential areas, etc. - Perform a range check of the transmitter to ensure no
interference is experienced. - Always turn on the transmitter before turning on the receiver
and turn off the receiver before turning off the transmitter. - If you are a beginner to radio control model flying, seek
assistance or advice from advanced expert fliers before attempting
to fly. - Keep relevant items out of reach of children.
- If performing high-stress flying, take necessary steps to
control movement range and reinforce body strength. - Some parts of the product may cause eye and skin discomfort.
Wear goggles or dust-proof clothes when needed. - The glue mentioned in the list may not be included due to air
traffic safety control. Purchase the glue you need at a local
stationery store.
You can find more information about this product on the official
website: http://www.dwhobby.com/
PRE-FLIGHT CHECKS
Check/adjust servo centering, in order to adjust the control surface better.
Double-check the spinning direction of motor at first usage, and sure it’s suitable for your model.
CG Set the center of gravity (CG) at the position that manual already marked out. If necessary, add weight to the nose or tail to ensure the best flight performance.
Double-check the inside of the fuselage, make sure all the equipments are correctly connected; Check the heat-shrink covering material’s surface, Make certain all screws, bolts, cabin and canopy remain secure.
Take great care when connecting/disconnecting the battery, pls replace the battery immediately once found low voltage or damage to battery.
The way the internal devices of the fuselage are connected will be related to your transmitter-receiver device. For those transmitter-receiver devices with more functions, you can simplify the connection of the internal devices of the fuselage. Check your device for details to see if it meets the features you need.
When the power system and transmitter-receiver device are paired for the first time, you may need to set the maximum stroke of the throttle. Please set it yourself.
SAFETY PRECAUTIONS
14 This product should not be considered a toy, but rather a complicated and sophisticated flying model. Your safety depends on how you use and fly it, If not correctly operated, could cause injury to you or your family members. Children must be accompanied by an adult at all times if operating this product. Not suitable for children under the age of 14. THIS IS NOT A TOY.
Do not fly around some restricted location like airports, military bases, residential areas, etc.
You will need to range check the transmitter to be sure you are not experiencing any interference.
Always turn on the receiver last after turning on the transmitter and shut off the receiver first before turning off the transmitter.
If you are only a beginner to the radio control model flying, do not attempt to fly your model without any assistance or advice from advanced expert fliers.
Keep relevant items out of reach of children.
This product has been flight tested to meet or exceed our rigid performance and reliability standards in normal use,if you plan to perform any high-stress flying, you are solely responsible for taking any and all necessary steps to control movement range and reinforce the body strength.
This product may include some fiberglass and carbon-fiber reinforced plastic parts,which may cause eye and skin discomfort,pls wear the goggles or dust-proof clothes when needed.
Due to air traffic safety control, the products you receive may not have the glue that appears in the list. Please understand and purchase the glue you need at your local stationery store.
http://www.dwhobby.com/
Balsawood Scale Airplane
SCG42
ARF
Specification
Suggested Equipment
:1.62M63.8″ :1.25M49.2″ : 3.1kg
Wingspan:1.62M63.8″ Fuselage Length:1.25M49.2″ Fly weight:3.1kg
3520-4220 800-500KV 14inch 60-80A4S 4S 2200-4000mAh 17g*4pcs 4CH+
Motor : 3520-4220 800-500KV Prop : 14inch ESC60-80A4S Battery4S 2200-4000mAh Servo : 17g*4pcs Radio4CH+
Tools Needed
SCG42-A
/ Photos shown here just for reference, the product you received maybe slightly differ from the photos due to continuous improvement on products.
SCG42-F
SCG42-B
SCG42-E K
SCG42-B
SCG42-H
SCG42-F SCG42-G
SCG42-J SCG42-D
SCG42-C
I
SCG42-H
SCG42-A: Fuselage SCG42-B: Upper Wing SCG42-C: Lower Wing
SCG42-D: Landing Gear SCG42-E: Wing bracket
SCG42-F: Horizontal tail/ Vertical tail
SCG42-J screws & parts
SCG42-H Dummy machine gun Collimator Exhaust pipe
SCG42-G: tail wheel set K:PVC PVC window shield
Rudder horn Wood block; Wood rod Connecting rod Stay wire
Assembly symbol guide
Ensure free rotation
Use medium CA
Use thin CA
Use a pencil
Push tightly
x2 Repeat multiple times
1
Use hobby knife with
Apply threadlock
Fully Tighten
OIL Apply Oil
Assemble right and left
Epoxy glue Use epoxy adhesive
01 Assemble the Landing Gear 01-1
M6x375mm
X2
Screw rod
+
Nut+Screw rod
01-3
X4
Screw M3x10mm
01-2
02 Assemble the Tail Wing and Tail Wheel 02-1
02-2
02-3
1
2
3
X2
++
Wheel axle sleeve+Nut+Self-locking nut
Install the wheel axle sleeve and nut in the sequence shown in the figure
U Install paper hinges on the tail control surface as shown in the figure, and connect the two control surfaces with U-shaped steel wires.
CA The control surface is connected with the tail wing through the paper hinge. After adjusting the clearance, the paper hinge is fixed with CA adhesive and the control surface can rotate freely.
1mm
Epoxy glue
02-4
Part of the covering film on the reverse side of the tail wing is cut off to facilitate subsequent bonding.
02-5
CA Install the vertical tail and horizontal tail to the fuselage tail, adjust them to be perpendicular to each other, and then use CA glue to fix them.
2
02-6 02-8
Epoxy glue
02-7
1mm
02-9
CA Install the steering rudder to the tail wing. After adjusting the clearance, glue the paper hinge at the joint with CA glue. Keep the control surface free to rotate.
tail wheel goes through here
Self-tapping screw M2x10mm
CA A small amount of CA glue is drilled at the screw, and then fix with screw.
03 Wing installation
03-1
Long
Long
Short
Short
Nose
Install the wing brackets, adjust them to the angle shown in the figure, and pay attention to the installation sequence.
03-2
X4
M3*15mm Screw
3
Installation of dummy parts
03-3
Install the dummy exhaust pipe.
03-4
6 carbon rod
X6
CA The bracket is installed into the reserved hole, and a small amount of CA glue is used for fixing. The left and right sides are installed the same.
Self-tapping screw M2x10mm
03-5
Installation of windshield and dummy collimator
Install the exhaust pipe as shown in the figure, with the same installation on the left and right
X2
03-6
Install the dummy machine gun
CA Insert into the reserved hole and fix with a small amount of CA glue.
03-7
6x100mm Carbon tube
6x100mm Carbon tube
03-8
Self-tapping screw M2x10mm
10x525mm Carbon tube
Epoxy glue
03-9
03-10
03-903-10 Note: The upper and lower wing control surfaces shall be installed according to steps 03-9 and 03-10, and the left and right wing control surfaces shall be installed the same.
4
03-11 03-14 03-15
Installation of lower wing servo
03-12
Epoxy glue
03-13
EZ-connecor
control horn
Servo wire goes through here
6x100mm Carbon tube
One on the left and one on the right 10x275mm Carbon tube
Epoxy glue
steel wire linkage rod
EZ-connecor
control horn
Install the control horn in the reserved hole on the rudder surface, install the EZ-connector on the rudder arm, and connect the rudder arm with the control horn through the steel wire.
2 Detail 2
Install the wing onto the fuselage, and pay attention to several installation details.
2 Detail 2
Back of upper wing
1 Detail 1
1 Detail 1
Back of lower wing
servo wire lead-in hole
X2
M4x10mm Hand screw
X2
M4x10mm Hand screw
03-17 Rotate the collet to adjust the length of the linkage rod, and adjust it to a proper length in combination with the distance of 03-17, and then install it.
03-16
5
03-17
Epoxy glue
Epoxy glue
Epoxy glue
Epoxy glue
The wing bracket is installed between the upper and lower wings, inserted into the reserved hole on the wing, and the joint is bonded with epoxy adhesive. Pay attention to the adjustment direction when installing the bracket.
X4
04 Installation of control servos for horizontal tail and vertical tail
03-16 Install the control horn on the reserved hole of the control surface, connect the upper and lower wing control surfaces with the 03-16 adjusted steel wire connecting rod, and keep them linked.
EZ-connecor
control horn
control horn
steel wire linkage rod EZ-connecor
control horn
Install the servo at the servo position shown in the figure, install the EZ-connecor on the rudder arm, install the control horn at the reserved hole of elevator and rudder, and connect the servo and control horn with steel wire connecting rod.
EZ-connecor
6
05 Install the motor and cowling
05-1
05-2
05-3
2 Detail 2
3 Detail 3
05-4
05-5
05-6
05-4,05-6 In combination with steps 05-4 and 05-6, adjust the position of the motor base according to the size of the motor, and then use epoxy adhesive to fix the motor base.
Install the propller and fix with adapter.
Note: The motor base has been designed with right pull and pull down angles.
06 Install the stay wire 2 Detail 2 5
1 Detail 1
2
1 Detail 1
4
7
3 Detail 3
1 8
1 Detail 1
3
6
18 There is one wing stay wire, which shall be threaded and installed in numerical order. Start at 1 and end at 8. Pay attention to several installation details during installation.
Stay wire 12345678
7
M2*10mm+ Screw+Self-locking nut
X2
Self-tapping screw M2x10mm
23 CA Insert a small amount of CA glue into the reserved screw holes in Details 2 and 3, and then install the self-tapping screws and relevant fasteners as shown in the figure.
X2
Self-tapping screw M2x10mm
Installation of dummy parts
dummy machine gun
Self-tapping screw M3x15mm
07 Set and Adjust
Display the C.G
105mm C.G
8
Usually, the control throws set as below:
105mm
C.G
Aileron
20°-35° 20°-35°
25° 25°
Elevator
25° 25°
Rudder
(Normal Flying)
3D (3D Flying only support some models)
Aileron
±15°-30°
±40° (or larger)
Elevator
±15°
±40° (or larger)
Rudder
±15°
±40° (or larger)
Flap take-off15°-20° Landing20°-40°
V Some special models will have V-tails, flaps, leading edge wings, etc., which can be used as a reference for conventional flight angles. If you do not confirm and there is no experienced person to guide you, we recommend that you first test at a small angle to confirm that your settings are correct.
Control Directions Tests
Lifting rod down
Elevator
Lifting rod up
Steering rod to the right
Aileron
Steering rod to the left
Direction rod to the right
Rudder
Direction rod to the left
More details about power system adjustment, please refer to below link: (You can scan QR Code directly.)
http://www.dwhobby.com/art/connection
9
