UMX™ Turbo Timber®
Instruction Manual
Replacement Parts
| Part # | Description |
| EFLU6953 | Fuselage |
| EFLU6954 | Wing Set |
| EFLU6955 | Tail set with horns |
| EFLU6956 | Landing gear set |
| EFLU6957 | Battery hatch |
| EFLU3956 | Led set |
| EFLU6958 | Decal set |
| EFLU6959 | Spinner |
| EFLU3960 | Leading edge slats |
| EFLU3961 | Pushrods set |
| EFLUM6960 | BL180 Brushless Outrunner 3,400Kv |
| EFLUP120703B | 120mm x 70mm 3 blade propeller |
| SPMSA2030LO | 2.3g linear long throw offset servo |
| SPMA2000 | 3″ Ultra Micro Extension |
| SPMSH2040T* | 2.9g Performance linear high torque servo (for flaps) |
| EFLA6421BLA* | RX DSMX 6-ch AS3X SAFE Brushless ESC |
* E-flite UMX Turbo Timber aircraft produced after December 2021 include an updated electronic speed control/receiver (EFLA6421BLA) and an updated flap servo (SPMSH2040T).
The updated flap servo is not compatible with the receiver used in aircraft produced prior to December 2021.
If the flap servo installed in an older aircraft requires replacement, it must be replaced with the original flap servo part number (SPMSH2040L).
Likewise, if the ESC/receiver installed in an aircraft produced after December 2021 requires replacement, it must be replaced with the updated receiver (EFLA6421BLA).
Optional Parts and Accessories
| Part # | Description |
| PKZ1039 | Hook and Loop Set (5): Ultra Micros |
| SPMA3060 | USB-Interface: UM AS3X Programmer |
| EFLUC1007 | Celectra 2S 7.4V DC Li-Po Charger |
| EFLUC1008 | DC Power Cord for EFLUC1007 |
| EFLB2002S30 | 200mAh 2s 7.4V DC Li–Po, 26AWG |
| EFLB2802S30 | 280mAh 2s 7.4V DC Li–Po, 26AWG |
| EFLC4000/UK/AU/EU | AC to 12V DC, 1.5 Amp Power Supply (Based upon your sales Region) |
| DX6e DSMX 6-Channel Transmitter | |
| SPMR6775 | NX6 6 Ch Transmitter Only |
© 2022 Horizon Hobby, LLC.
E-flite, Timber, AS3X, UMX, SAFE, the SAFE logo, DSM, DSM2, DSMX, ModelMatch, Bind-N-Fly, BNF, Celectra and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC.
The Spektrum trademark is used with permission of Bachmann Industries, Inc.
Futaba is a registered trademark of Futaba Denshi Kogyo Kabushiki Kaisha Corporation of Japan.
All other trademarks, service marks and logos are property of their respective owners.
US 9,930,567. US 10,419,970. US 9,056,667. US 9,753,457. US 10,078,329. US 7,898,130. US D578,146. US 8,672,726. Other patents pending.
www.e-fliterc.com
Created 1/22 61135.3 EFLU6950
