BOYA BY-GM18CB Desktop Gooseneck Condenser Microphone

Thanks for choosing BOYAI

BOVA BY-GM 18CB is a cardioid condenser gooseneck microphone.
It’s an Ideal choice for lectures, conferences and meetings.

With excellent cardioid polar pattern, the BY-GM1 see can clearly capture the voice in front of the mic, designed to provide dear and intelligent speech reproduction for lectures, video conferences, meetings, and more.

The BY-GM18CB’s shaft features upper and lower gooseneck sections that enable you to precisely position the capsule In front of the speaker for optimal sound. ON/OFF status Is clearly Indicated by the UD ring below the mic capsule. The BY-GM 18C8 can be powered by 2 AAA batteries or XLR 48V Phantom power.

Package Contents

• 18″ Gooseneck Microphone
• Microphone Base
• User Manual
• Warranty Card

Safety Instructions

• Please read this user manual carefully and completely before using the product, and keep it for future reference.
• Warning: improper Installation could irreparably damage the until
• Place the unit In a location protected from weather and far from water and moisture.
• Keep all liquids away from the product. Liquids entering the product can short-circuit the electronics or damage the mechanics.
• Don’t place this unit close to heat sources (radic1tors, spotlights, amplifie1s etc.)

Introduction

1. Cardioid microphone capsule
2. LED Indicator
3. 18″ XLR dual-section gooseneck

4. PUSH button
5. XLR connector
6. ON/OFF button

7. Anti-slip foot pad
8. Battery compartment

9. Foam windscreen


Operation Guide

1. Insert 2 AAA batteries Into the battery compartment according to the polarity indicated inside the compartment.
   Note: if using phantom power, please skip this step.
2. Insert the gooseneck connector into microphone base surface XLR connector as shown.
3. Connect microphone base to an external unit (mixer, amplifier, etc).
   Note: Switch phantom power on If the external unit can offer 48 phantom power.
4. Press the ON/Off button and start it up. Two LED indicators will light up at the same time.
5. Press the ON/OFF button again to tum off the unit The LED Indicators will be off.

   Note: Please press PUSH button to remove.


Features

• High quality 18″ cardioid condenser gooseneck microphone
• Deliver clear and intelligible sound
• Ideal for lectures, video conferences, meetings, etc
• Flexible dual-section gooseneck enables ease of use and positioning
• Built-in LED Indicators show work! ng status at any time
• Powered by 1.5V AAA battery or 48V phantom power
• Foam windscreen included

Specifications

SHEZNHEN JIAYZ PHTO INDUSTTIAL., Ltd
The BOYA logo is a trademark, which is registered and owned by Shenzhen Jiayz Photo Industrial., Ltd.

TEL: 400 6131096
Email: [email protected]
www.boya-mic.com / www.jiayz.com
