In Common Augustus Surface Mount Light Instruction Manual

Augustus Surface Mount Light

Product Information:
The Augustus Surface Mount is a lighting fixture that can be
installed on walls or ceilings. It comes with various components
including a backplate, canopy cover, wago clips, G9 LED bulb,
diffuser, mounting screws, glass holder, set screws, and surface
shade. The fixture requires an electrical power source to operate.
Product Usage Instructions:
To install the Augustus Surface Mount, follow these steps:

1. Before starting the installation, ensure that you have received
   all the components mentioned in the guide. Contact us if any
   component is missing.
2. Turn off the electrical power source at the main fuse box or
   circuit panel.
3. Using a Phillips head screwdriver, mount the backplate (Part A)
   to the junction box by tightening the mounting screws (Part
   G).
4. Use the provided wago clips (Part C) to connect the fixture’s
   wires to the corresponding wires from the junction box. Ensure
   proper connections: white for neutral, black for live, and
   green/yellow for ground. If needed, strip 3/8 of insulation from
   each wire using a wire stripper before inserting them into the wago
   clips.
5. Align the holes of the backplate (Part A) with the holes of the
   canopy cover (Part B) and secure them using the set screws (Part
   H).
6. Slide the surface shade (Part I) up the socket and attach it to
   the backplate (Part B) by rotating the glass holder (Part G) until
   all components are fixed in place.
7. Insert the G9 LED bulb (Part D) into the socket of the shade
   assembly.
8. Screw the diffuser (Part E) into the glass holder (Part
   G).
9. Finally, turn the power back on at the main fuse box or circuit
   panel.

Please ensure that you follow all safety precautions mentioned in
the user manual. If you have any questions or concerns, feel free
to reach out to us for assistance.

Augustus Surface Mount
How to Install Your New Light Please check that you received all of the components pictured in this guide. Reach out to us if anything is missing. It’s very rare, but it happens. Don’t forget to turn off the electrical power source.
Tools you will need that aren’t included: standard wire stripper, Phillips head screwdriver.
CAUTION Electrical shock risk. Turn off electrical power at the main fuse box or circuit panel before beginning installation, servicing the light, or installing accessories. We recommend working with a qualified electrician familiar with the type of work you’d like done.
ATTENTION Risque de choc électrique. Coupez l’alimentation électrique au niveau de la boîte à fusibles principale ou du panneau de circuits avant de commencer l’installation, l’entretien de la lumière ou l’installation d’accessoires. Nous vous recommandons de travailler avec un électricien qualifié familier avec le type de travail que vous souhaitez effectuer.

Contents

Part A Backplate

Part B Canopy Cover

Part C Wago Clips (x3)

Part D G9 LED Bulb

Part E Orb 4 Diffuser

Part F Mounting Screws (x2)

Part G Glass Holder

Part H Set Screws (x2)

Part I Augustus Surface Shade

Assembly Guide

1 of 3

incommonwith.com

Augustus Surface Mount

Step 1: Turn off electrical power at the main fuse box or circuit panel before beginning installation.

Step 2: Mount the backplate (A) to the junction box using a phillips head screwdriver to tighten the mounting screws (G)F

A
F
!

Step 3: Use the wago clips (C) to connect the fixture’s wires to the corresponding wires from the junction box in the wall or ceiling. White is neutral; Black is live; Green/ Yellow is ground. One ground wire will be attached to the backplate (A), the other ground wire should come from the junction box. If needed use a wire stripper to remove 3/8″ of the insulation from each wire before inserting them into the corresponding wago clip.

Step 4: Align the holes of the backplate (A) with the holes of the canopy cover (B) and secure the set screws.

A B
C

B

Assembly Guide

2 of 3

incommonwith.com

Augustus Surface Mount

Step 5: Carefully slide the shade (J) up the socket. Attach shade (I) to backplate (B) by rotating glass holder (H) until components are fixed in place.

Step 6: Insert lightbulb (D) into the socket of the shade assembly..

B

I D
G
Step 7: Screw the diffuser (E) into the glass holder (G). Turn the power back on at the main fuse box or circuit panel you disabled before installation.
G
E

Assembly Guide

3 of 3

incommonwith.com
