DOMUS Surface Mount Path Light
Product Information
- Product Name: DOMUS Surface Mount Path Light
- Available Sizes: 600mm & 900mm
- Available Colors: White or Black
- Product Finishes: Black / White
- Product Head Style: Dome
- Materials: Aluminium and Polycarbonate (stainless steel
screws) - Dimensions:
- Louvre diameter = 150mm
- Post diameter = 125mm
- Base Diameter = 170mm
- Base Depth = 17mm
- Lens Height = 135mm
- Overall Height: 600mm or 900mm
- Included in the Package: Bollard, Allen Key, 3 x Mounting
Screws & Plugs, Waterproof Junction Box, Instructions - Product Warranty: 3 years
- Recommended Bulb: LED Filament GLS or Candle Bulb
- IP Rating: IP44
- Cable: H05VV-F 3 core (approx. 10-15cm from base)
Product Usage Instructions
Cleaning
Occasional cleaning and care is recommended for this product.
Please refer to our website for the best way to clean different
materials.
Returns
If purchased from a 3rd party, please contact your supplier. If
purchased directly from Lumena Lights Ltd, contact us by phone or
email:
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR
Tel: +44 1327 871161
Email: [email protected]
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with
household waste. Please check with your local authority or contact
us for more information. Please recycle packaging whenever
possible.
Installation
IMPORTANT: Cable should be laid inside armoured conduit or
piping to protect from water-logging, chemicals found in soil, and
damage. If buried, it should be buried to at least 0.5m below
ground to reduce damage risk. If this method is not used, cable
warranty will be void.
- Locate/install the mains feed (central to bollard base).
- Use the base to mark the mounting holes on the mounting surface
in the desired location (refer to Image A). - Remove the light and drill out the 3 holes marked at the
relevant depth and dimensions.
Cable Wiring
Neutral (N) = Blue
Live (L) = Brown
Earth = Yellow & Green
Lamp Installation / Replacement
IMPORTANT: Ensure power is turned off prior to changing the
lamp. Alternate the tightening of screws to prevent
misalignment.
IMPORTANT: Condensation can occur due to the warmth inside the
fitting produced by the lamp and the cold air outside. If this is
noticed, on a dry day, turn off the power supply, safely remove the
head, and wipe dry with a soft cloth.
For more information and the full product range, visit our
website: www.lumenalights.com
INSTRUCTIONS DOMUS Surface Mount Path Light
600mm & 900mm / White or Black
WARNINGS
PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE
· If a fitting is found to be damaged, cease use immediately. · This is a Class 1 product and must be earthed. · This unit must be fitted by a competent and qualified electrician. · Install in accordance with IEE wiring regulations and current Building
Regulations. · To prevent electrocution, switch off mains supply before installing or
maintaining this fitting. Ensure other persons cannot restore the electrical supply without your knowledge. · This light fitting should be connected to a circuit with a 30Ma RCD fitted. Maximum 12-15 fittings on each circuit recommended. · If replacing an existing fitting, make a careful note of the connections. · All connections should be made as watertight as possible to avoid electrical shortage. · When changing the bulb, always switch off at the mains & allow to cool before handling. · Always use the correct type & wattage bulb. Never exceed the wattage stated. · The unit may get warm whilst on for a period of time.
Voltage: 220 – 240v 50Hz Max. Wattage: 100w
Bulb Holder: ES / E27 Recommended Bulb: LED Filament GLS or Candle Bulb IP Rating: IP44
3 YEAR
GUARANTEE
Cable: H05VV-F 3 core (approx. 10-15cm from base)
RoHS
see website for
Product Heights: 0.6m / 0.9m
more details
Product Finishes: Black / White
Reduced warranty for
Product Head Style: Dome
specific components
Materials: Aluminium and Polycarbonate (stainless steel screws)
Mount: External Surface Mount
Dimensions: Louvre diameter = 150mm, Post diameter. = 125mm, Base Diameter = 170mm, Base Depth = 17mm,
Lens Height = 135mm, Overall Height 600mm or 900mm
INCLUDED: Bollard, Allen Key, 3 x Mounting Screws & Plugs, Waterproof Junction Box, Instructions
CLEANING: Occasional cleaning and care is recommended for this product. Please refer to our website for the best way to clean different materials.
RETURNS: If purchased from a 3rd party, please contact your supplier. If purchased direct, contact us by phone or email: Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR Tel: +44 1327 871161 Email: [email protected] Our full returns policy is available on our website. Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or contact us for more information. Please recycle packaging whenever possible.
Producer Registration Number: WEE/KC3440XY
Full product range & more information: www.lumenalights.com
INSTALLATION:
IMPORTANT: Cable should be laid inside armoured conduit or piping to protect from water-logging, chemicals found in soil and damage. If buried, it should be buried to at least 0.5m below ground to reduce damage risk. If this method is not used, cable warranty will be void.
This bollard should be securely fixed to a concrete base, brick, paving slab or quality wooden decking. It should not be installed directly into soil. For fixing to a new concrete base, root fixing bolts (j-bolts) will be required (available for sale at Lumena). For fixing into existing paving slabs, concrete or decking, heavy duty fixing screws and bolts will be required (expanding anchor bolts recommended). Ensure the fixing screws / bolts are stainless steel or zinc plated to avoid corrosion.
1. Locate / install the mains feed (central to bollard base). 2. Use the base to mark the mounting holes on the mounting surface in the
desired location (Image A). 3. Remove the light and drill out the 3 holes marked at the relevant depth and
diameter for the mounting screws / wall plugs being used (varies based on mounting surface). For screws supplied, 9-10mm at 60mm depth. 4. Insert plugs into pre-drilled holes. 5. Remove the 3 way block at the bottom of the cable. 6. Lay the post on it’s side on a soft blanket or similar. 7. Pierce two of the rubber cable glands of the waterproof junction box supplied and remove lid. 8. Wire the fitting to the mains feed inside the waterproof junction box with the 3 way block inside. Ensure all supply wires are correctly identified and connections are tight with no loose strands. 9. Replace the lid of the junction box, seal if preferred (recommended). 10. Push the junction box up inside bollard tube. 11. Replace the post light, lining up the 3 x holes at the base with the pre-drilled holes and secure in place with the chosen screws / bolts – large washers may be required. 12. Fit an LED lamp (see below). 13. Test the bollard.
CABLES: Neutral (N) = Blue Live (L) = Brown
Earth = Yellow & Green
Colours of wire sleeving may vary slightly Test prior to use.
Light Earth Fitting
Neutral
N
Live
L
Earth Cable
Mains Power
IMPORTANT: Do not overtighten the base as this could lead to fracture. Do not use high power electric socket tools.
A
B
BASE
Depth = 17mm
C
10mm
123mm
170mm
LAMP INSTALLATION / REPLACEMENT: (Ensure power is turned off prior to changing the lamp)
1. Loosen the two small socket screws (grub screws) holding on the dome of the bollard (do not completely remove) Image B
2. Lift the dome from the louvres. 3. Remove / Insert lamp (screw base E27). 4. Replace dome, lining up the grub screws with the lugs (Image C) and secure with allen key as removed in step `1′.
Alternate the tightening of screws to prevent misalignment.
IMPORTANT: Condensation can occur due to the warmth inside the fitting produced by the lamp and the cold air outside. If this is noticed, on a dry day, turn off the power supply, safely remove the head, and wipe dry with a soft cloth.
Full product range & more information: www.lumenalights.com
