MOUNT-SP01CB Black Clamp-on Speaker Stand – 2 Pack
Product Information: Black Clamp-on Speaker Stand – 2 Pack
The Black Clamp-on Speaker Stand – 2 Pack (SKU: MOUNT-SP01CB) is
a set of two stands designed to hold speakers with a weight
capacity of up to 33lbs (15kg). The package contents include (x2)
Mounts, (x2) Speaker Plates, (x4) Soft Pads, (x2) M8x25mm Screws,
(x2) M8 Spacers, (x2) Conical Washers, and (x1) 5mm Allen Wrench.
The stand is adjustable in height and tilt to provide optimal
speaker placement.
Product Usage Instructions
- Loosen the clamp on Mounts (A) and assemble them to the desktop
by re-tightening the clamps. - Loosen the knobs on the front of Mounts (A) to adjust the
height. Insert the into the holes located on the shaft, and
re-tighten the knob to lock the postion. - Remove the adhesive backing from Soft Pads (C) and stick them
to the top surface of Speaker Plates (B). - Assemble Speaker Plates (B) to Mounts (A) using M8x25mm Screws
(S-A) with M8 Spacers (S-B) and Conical Washers (S-C). Tighten
using 5mm Allen Wrench (T-A). - Place speakers on top of the assembled stands. Make tilt and
height adjustments as necessary. If desired, rotate Speaker Plate
(B) so the lip is in the front for the speaker to rest on.
Note: Do not exceed the weight capacity of the stand as it may
result in serious injury. Also, keep small parts away from children
under 3 years of age as they pose a choking hazard and require
adult supervision. If any parts are received damaged or defective,
contact the support team for assistance.
For more VIVO products, check out their website at www.vivo-us.com.
Black Clamp-on Speaker Stand – 2 Pack
Instruction Manual
SKU: MOUNT-SP01CB
Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-sp01cb
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
www.vivo-us.com Chat live with an agent!
309-278-5303
WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or inappropriate use.
PACKAGE CONTENTS
A (x2) Mount
B (x2) Speaker Plate
C (x4) Soft Pad
S-A (x2) M8x25mm Screw
S-B (x2) M8 Spacer
S-C (x2) Conical Washer
T-A(x1) 5mm Allen Wrench
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
33lbs (15kg)
WARNING: CHOKING HAZARD
SMALL PARTS – NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
ASSEMBLY STEPS
STEP 1
Loosen the clamp on Mounts (A) and assemble them to the desktop by re-tightening the clamps.
A
2
STEP 2
Loosen the knobs on the front of Mounts (A) to adjust the height. Insert the into the holes located on the shaft, and re-tighten the knob to lock the postion.
A
STEP 3
Remove the adhesive backing from Soft Pads (C) and stick them to the top surface of Speaker Plates (B).
STEP 4
Assemble Speaker Plates (B) to Mounts (A) using M8x25mm Screws (S-A) with M8 Spacers (S-B) and Conical Washers (S-C). Tighten using 5mm Allen Wrench (T-A).
C B S-C
T-A
S-A
A
S-B B
STEP 5
Place speakers on top of the assembled stans. Make tilt and height adjustments as necessary. If desired, rotate Speaker Plate (B) so the lip is in the front for the speaker to rest on.
B
3
Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us
LAST UPDATED: 06/09/2022 REV1
