OSSE1A1KIT Speaker Stand Bracket Kit
Product Information
- Product Name: Speaker Stand Bracket Kit
- Model Number: OSSE1A1KIT
- Manufacturer: Legrand AV Inc.
- Contents: Top Bracket x1, Speaker Bracket x2, Speaker / Bracket
Screw x3, Securement Screw x4 - Tools Needed: Screwdriver
- Warning: This product contains small items that could be a
choking hazard if swallowed. Before starting assembly, verify all
parts are included and undamaged.
Product Usage Instructions
- Verify that all parts are included and undamaged.
- Attach the Speaker Brackets to the Top Bracket using the
Speaker / Bracket Screws. - Attach the Securement Screw to the Top Bracket.
- Attach the Top Bracket to the speaker stand.
- Place the speaker on the Speaker Brackets.
- If necessary, remove the Trigger Button to route cables into
the post or prevent accidental lowering. - To raise or lower the speaker, hold the upper post and press
the Trigger Button. Use caution to avoid personal injuries or
property damage.
6901-603101 00
OSSE1A1KIT
Speaker Stand Bracket Kit
For SONOS® Era 100TM
Converts speaker stand models; OSSA1, OSSA2, WSSA1, WSSA2 for use with SONOS® Era 100TM
INSTRUCTION MANUAL
Tools Needed
Screwdriver
We’ll Make It Stress-Free
If you have any questions along the way, just give us a call. US: +1 (800) 359-5520 · EMEA: +31 (0) 495 580 852 · UK: +44 (0) 800 056 2853
We’re ready to help!
Speaker Stand Instruction Manual (OSSA1, OSSA2, WSSA1 or WSSA2)
Included in the Kit
WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged.
If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts!
Top Bracket
1 x1
Speaker Bracket
2 x1
Speaker / Bracket Screw
3 x2
Securement Screw
4 x1
Legrand AV Inc. 6436 City West Parkway Eden Prairie, MN 55344 USA
US: +1 (800) 359-5520
Legrand AV Netherlands B.V. Franklinstraat 14 6003 DK Weert Netherlands
UK: +44 (0) 800 056 2853 EMEA: +31 (0) 495 580 852
Authorized Representative for the UK Starline Holding Technology Ltd. Unit C Island Road Reading RG2 0RP UK
Legrand AV Inc. and its affiliated corporations and subsidiaries (collectively, “Legrand”), intend to make this manual accurate and complete. However, Legrand AV makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this document is subject to change without notice or obligation of any kind. Legrand AV makes no representation of warranty, expressed or implied, regarding the information contained herein. Legrand AV assumes no responsibility for accuracy, completeness or sufficiency of the information contained in this document.
©2022 Legrand AV Inc. All rights reserved. SANUS is a brand of Legrand. All other brand names or marks are used for identification purposes and are trademarks of their respective owners.
Legrand AV Inc. · 6436 City West Parkway · Eden Prairie, MN 55344 USA
1
2
3
M5 x 14mm
1
3
4
1
2
3
M5 x 14mm
5
6
RAISE
LOWER
CAUTION: Avoid potential personal injuries and property damage! Hold upper post BEFORE pressing trigger button.
Trigger button is removable to prevent accidental lowering, or to route cables into post (STEP 6).
1 HOLD
2 PRESS
3 LOWER
4
1
2
4X
6901-603101 00
