HODT11C Outdoor Digital Timer
Product Information
Product Name: Outdoor Digital Timer
SKU: HODT11C
Electrical Ratings:
- Input Voltage: 125V, 60Hz
- Max Power Rating: 125V, 60Hz, 1625W, 13A Resistance, 13A
General Use, 1000W Tungsten, 500VA Electronic Ballast, 120Vac,
60Hz, 8.3A Ballast, 1/2HP - Cord: SJTW 16/3 AWG
Safety Information:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver. - Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for
help.
One Year Limited Warranty:
Supported by our professional R&D team and QC team, we
provide One Year Warranty for materials and workmanship from the
purchase date. Please note that the warranty does not cover damage
caused by personal misuse or improper installation. Please attach
your Order ID and Name so that our dedicated customer service team
can help you better.
Product Usage Instructions
1. Please read the instruction manual carefully before operating
the Outdoor Digital Timer.
2. Ensure that you have a suitable outdoor appliance to use with
the timer. The timer is rain-tight and designed for outdoor
use.
3. Connect the timer to a power source with an input voltage of
125V and 60Hz.
4. Set the timer by following these steps:
- Press the “1” button to select the desired program.
- Use buttons “2” and “3” to set the desired time for the
program. - Press the “OK” button to confirm the settings.
5. The timer has various electrical ratings depending on the
type of appliance being used. Please refer to the electrical
ratings section in the product information for more details.
6. Make sure to properly install and use the timer according to
the provided instructions to avoid harmful interference with radio
communications.
7. If the timer causes harmful interference to radio or
television reception, try one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the timer and receiver.
- Connect the timer into an outlet on a different circuit from
that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for
help.
8. The product is covered by a one-year limited warranty for
materials and workmanship from the purchase date. However, the
warranty does not cover damage caused by personal misuse or
improper installation. Please provide your Order ID and Name when
contacting our customer service team for assistance.
Outdoor Digital Timer
SKU: HODT11C
[Instruction Manual]
Please pay attention to the warning signs Read the instructions with caution before operating
and keep it properly V20718
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR PERSONAL INJURY, PLEASE STRICTLY FOLLOW THE IN-STRUCTIONS. 1.SUITABLE FOR USE WITH OUTDOOR APPLIANCESRAINTIGHT
WHEN MOUNTED VERTICALLY WITH THE RECEPTACLE FACING DOWNWARD. NOT FOR WATER IMMERSION.STORE INDOOR WHEN NOT IN USE. 2.INSTALL THE CORD AND UNIT ABOVE GROUND LEVEL AT LEAST 1.4 M WITH THE RECEPTACLE FACING DOWNWARD. 3.DO NOT CONNECT ANY DEVICES WHICH EXCEED THE MAXIMUM RATINGS OF THE TIMER. 4.DO NOT IMMERSE IN WATER. 5.CHILDREN ARE NOT ALLOWED TO USE THE TIMER WITHOUT SUPERVISION. 6.DO NOT DISASSEMBLE OR REPAIR THE PRODUCT, BUT ONLY BY AUTHORIZED SERVICE PERSONNEL. 7.ALWAYS UNPLUG AND STORE INDOORS WHEN NOT IN USE.
01
Product Layout
1
2
3
Operation Instructions
02
HELPFUL TIPS
When set to”ON”, the timer will provide continual power to attached devices until the timer is switched to “OFF”, or to any of the other operating modes. In the sensor mode, temporary light sources like headlights, porch lights and other external light sources will not interfere with the photocell function unless the external light source is on for more than 15 minutes. In that case, the timer will shut off until darkness is restored. The improvement avoids the flickering. Once programming activates at dusk in the 1-9 hr mode, the program cycle will complete before the timer resets. Headlights, porch lights, street lamps and other external lighting sources will not interfere with the active timer program.
Electrical Ratings
Input Voltage: – 125V, 60Hz. Max Power Rating: – 125V, 60Hz, 1625W, – 13A Resistance, – 13A General Use, – 1000W Tungsten, – 500VA Electronic Ballast, – 120Vac, 60Hz, 8.3A Ballast, – 1/2HP. Cord: – SJTW 16/3 AWG.
Safety Information
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
03
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
One Year Limited Warranty
Supported by our professional R&D team and QC team, we provide One Year Warranty for materials and workmanship from the purchase date. Please note that the warranty does not cover damage caused by personal misuse or improper installation. Please attatch your Order ID and Name so that our dedicated customer service team can help you better.
04
