FT-5000 2.0 Functional Trainer
Product Information
The product model is FT-5004. It is a troubleshooting guide for
the product.
The issue being addressed in this guide is that the cables are
not pre-installed. Additionally, it mentions that a 6mm Allen
wrench and a 13mm wrench are not included with the product.
The guide provides instructions on how to install the cable and
shows an exploded view of a generic pulley.
It also highlights the importance of not losing the small pulley
spacer.
Product Usage Instructions
- Start by uninstalling the pulley.
- Thread the cable through.
- Reinstall the pulley.
- Repeat steps 1-3 for all pulleys.
- Repeat the process for the other frame.
Note: Make sure to use the appropriate wrenches and be careful
not to lose the small pulley spacer.
TROUBLE SHOOTING GUIDE
FT-5004
ISSUE #1: CABLES ARE NOT PRE-INSTALLED
6MM ALLEN WRENCH 1X NOT INCLUDED
13MM WRENCH 1X NOT INCLUDED
1
INSTALL CABLE
E
B
D
TO INSTALL CABLE C
1. UNINTSALL PULLEY 2. THREAD CABLE 3. REINSTALL PULLEY 4. REPEAT 1-3 FOR ALL PULLEYS 5. REPEAT FOR OTHER FRAME
30-0302
PULLEY SPACER 30-0355
PULLEY SPACER
PULLEY COVER
30-0354
PULLEY COVER
30-0356
GENERIC PULLEY EXPLODED VIEW (LARGER VIEW ON NEXT PAGE)
A NOTE: DO NOT LOSE SMALL PULLEY SPACER
BOLT ON THIS END
NOTE: DO NOT LOSE SMALL PULLEY SPACER
30-0302
PULLEY SPACER 30-0355
PULLEY SPACER
PULLEY COVER
30-0354
PULLEY COVER 30-0356
