NetWay4E1BTWP 4-port Hardened 802.3bt 4PPoE Switches
Product Information
The Altronix NetWay4E1BT Series is a collection of hardened
802.3bt 4PPoE switches designed for fiber solutions. These switches
come in various models, each with different features and
specifications. The models include:
- NetWay4E1BTWP: This model is a 4-port hardened 802.3bt 4PPoE
switch and power supply/charger. It comes with a NEMA4/4X, IP66
rated outdoor enclosure. - NetWay4E1BTWPX: Similar to the NetWay4E1BTWP, this model also
includes an outdoor enclosure. Additionally, it can accommodate up
to four 12VDC/4AH batteries. - NetWay4E1BTWPN: This model is a 4-port hardened 802.3bt 4PPoE
switch that uses an external power supply. It also comes with a
NEMA4/4X, IP66 rated outdoor enclosure. - NetWay4E1BTX: Unlike the previous models, this one has a NEMA1
rated indoor enclosure. - NetWay4E1BTPL: This model is a backplane version of the 4-port
hardened 802.3bt 4PPoE switch and power supply/charger. - NetWay4E1BTB: This model is a board-only version of the 4-port
hardened 802.3bt 4PPoE switch.
The installation guide for the NetWay4E1BT Series is available
with the document number NetWay4E1BT Rev. 031723.
Product Usage Instructions
To install the NetWay4E1BT Series, follow the steps outlined in
the installation guide. The guide covers various topics including
an overview, features, recommended power sourcing equipment,
recommended SFP modules, technical specifications, typical
application drawings, wall mount installation, pole mounting using
an optional kit, and mechanical drawings and dimensions.
Make sure to read and understand the instructions provided in
the installation guide before proceeding with the installation
process. It is important to use the correct model based on your
specific requirements and to follow all safety precautions
mentioned in the manual.
Fiber Solution
NetWay4E1BT Series
4-port Hardened 802.3bt 4PPoE Switches
Models Include:
NetWay4E1BTWP
– 4-port Hardened 802.3bt 4PPoE Switch and Power Supply/Charger
– NEMA4/4X, IP66 rated Outdoor enclosure.
NetWay4E1BTWPX
– 4-port Hardened 802.3bt 4PPoE Switch and Power Supply/Charger
– NEMA4/4X, IP66 rated Outdoor enclosure. – Accommodates up to four (4)
12VDC/4AH batteries.
NetWay4E1BTWPN
– 4-port Hardened 802.3bt 4PPoE Switch (uses external power supply).
– NEMA4/4X, IP66 rated Outdoor enclosure.
NetWay4E1BTX
– 4-port Hardened 802.3bt 4PPoE Switch and Power Supply/Charger
– NEMA1 rated Indoor enclosure.
NetWay4E1BTPL
– 4-port Hardened 802.3bt 4PPoE Switch and Power Supply/Charger
– Backplane version.
NetWay4E1BTB
– 4-port Hardened 802.3bt 4PPoE Switch – Board Only.
Installation Guide
DOC#: NetWay4E1BT Rev. 031723
More than just power.TM
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
Table of Contents:
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 3
Installation Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 4 Power Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 4 Input/Data Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 4 Battery Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 4
Recommended Altronix Power Sourcing Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 5
Recommended Altronix SFP Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 5
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 5
Typical Applications Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 6 NetWay4E1BTB/NetWay4E1BTWPN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 6 NetWay4E1BTWP/NetWay4E1BTWPX/NetWay4E1BTX/NetWay4E1BTPL. . . . . . . . . . . . . . . . . . pg. 7
Wall Mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 8
Pole Mounting Using Optional Pole Mount Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 8
Mechanical Drawings and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 9-12
– 2 –
NetWay4E1BT Series Installation Guide
Overview:
Altronix NetWay4E1BT Series Hardened 802.3bt 4PPoE Switches are equipped with one (1) 1Gb SFP port and four (4) POE IEEE802.3af/3at/3bt PoE ports rated at 90W each, limited to 240W or 320W total power, depending on a model.
Features:
Agency Listings:
Indicators (LED):
· CE European Conformity.
· Individual PoE On LEDs for each port.
Input: · NetWay4E1BTWP/NetWay4E1BTWPX/
NetWay4E1BTPL/NetWay4E1BTX/: 115VAC, 60Hz, 1.8A or 230VAC, 50/60Hz, 1A. · NetWay4E1BTB/NetWay4E1BTWPN:
· Individual IP Link status, 10/100 Base-T/active LEDs for each port.
· ALOS LED indicates fiber connection for SFP port. · Heartbeat LED indicates proper operation of the unit.
Mechanical:
48-56V UL Listed ITE power supply.
NetWay4E1BTB:
Power Output: · Four (4) 10/100/1000 Mbps Ethernet ports rated at
90W each (240W total power). · NetWay4E1BTB/NetWay4E1BTWPN:
Four (4) 10/100/1000 Mbps Ethernet ports rated at 90W each (depending on the power supply employed, limited to 320W total power). · IEEE 802.3af, 802.3at, 802.3bt compliant.
SFP Ports: · One (1) Gigabit SFP port.
Ethernet Ports: · Four (4) 10/100/1000 Mbps ports. · Connectivity: RJ45, auto-crossover. · Wire type: 4-pair CAT5e or higher structured cable. · Speed: 10/100/1000 Mbps, half/full duplex,
auto negotiation.
Battery Backup
(NetWay4E1BTWP/NetWay4E1BTWPX*/
· Dimensions (L x W x D approx.): 6.25″ x 4.5″ x 1.25″ (158.8mm x 114.3mm x 31.8mm).
NetWay4E1BTPL: · Dimensions (H x W x D approx.):
10.75″ x 8.875″ x 2.375″ (273.1mm x 225.4mm x 60.3mm). NetWay4E1BTWPX: · NEMA4/4X, IP66 Rated enclosure for outdoor use. · Accommodates sealed lead acid or gel type or LiFePO4 (Lithium Iron Phosphate) 12VDC batteries*. · Dimensions (H x W x D approx.): 17.53″ x 15.3″ x 6.67″ (445.3mm x 388.6mm x 169.4mm). NetWay4E1BTWP, NetWay4E1BTWPN: · NEMA4/4X, IP66 Rated enclosure for outdoor use. · Dimensions (H x W x D approx.): 13.31″ x 11.31″ x 5.59″ (338.1mm x 287.3mm x 142mm). NetWay4E1BTX:
NetWay4E1BTX/NetWay4E1BTPL): · 24VDC charging circuit charges
LiFePO4 (Lithium Iron Phosphate) or sealed lead acid* or gel type* batteries.
· NEMA1 Rated enclosure for indoor use · Dimensions (H x W x D approx.):
13.5″ x 13″ x 3.25″ (342.9mm x 330.2mm x 83mm).
· Automatic switch over to stand-by battery
when AC fails.
*CAUTION: When using lead acid or gel type batteries, enclosure must be properly ventilated.
NetWay4E1BT Series Installation Guide
– 3 –
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes and authorities having jurisdiction. All units should be installed by a trained service personnel.
Installation:
NetWay4E1BTB/NetWay4E1BTPL:
1. Mount board/backplane in the desired location/enclosure with hardware supplied.
Fig. 1
2. NetWay4E1BTB: Connect 56VDC/280W max power source
to terminal marked [+] and [].
Note: For proper earth ground connections on NetWay4E1BTB fasten metal spacers (provided) to threaded studs at
NetWay4E1BTB
indicated board mounting holes (shown on the right).
Metal Spacers
SFP1 ALOS
SFP Port
This is recommended for better environmental immunity.
NetWay4E1BTWP/NetWay4E1BTWPX/NetWay4E1BTWPN:
1. Remove backplane from enclosure prior to drilling. Do not discard hardware.
Note: Make sure that hardware will not interfere with components of the circuit board.
2. Mark and drill desired inlets on the enclosure to facilitate wiring. Maximum NEMA type 4X rated fittings
to be used are 0.5″. Follow manufacturer’s specifications for the appropriate size opening.
Note: Inlets for conduit fittings should only be made on the bottom of the enclosure.
To facilitate wire entry utilize weather-tight NEMA rated connectors (supplied), bushings, and cable.
3. Clean out the inside of enclosure before remounting circuit boards/backplane.
4. Mounting NEMA4/4X rated enclosure (Enclosure Dimensions, pg. 9, 10):
Wall mount: Mount unit in desired location. Mark and drill holes to line up with the top and bottom
hole of the enclosure flange. Secure enclosure with appropriate fasteners (e. g. screws
and anchors; bolts and locking nuts, etc.) that are compatible with mounting surface and
are of sufficient length/construction to ensure a secure mount (Fig. 4, pg. 8).
Pole Mount: Refer to Fig. 5 – 9, pg. 8.
5. Mount backplane in enclosure with hardware.
NetWay4E1BTX:
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes
in the enclosure. Install two (2) upper fasteners and screws in the wall with the screw heads protruding.
Place the enclosure’s upper keyholes over the two (2) upper screws; level and secure. Mark the position of
the lower two (2) holes. Remove the enclosure. Drill the lower holes and install two fasteners. Place the
enclosure’s upper keyholes over the two (2) upper screws. Install the two (2) lower screws and make sure to
tighten all screws (Enclosure Dimensions, pg. 11). Secure enclosure to earth ground.
Power Connection:
NetWay4E1BTWP, NetWay4E1BTWPX, NetWay4E1BTX, and NetWay4E1BTPL: 1. Secure cabinet to earth ground. Connect AC power from overcurrent protective device circuit breaker
(20A @ 115VAC, 60Hz, 16A @ 230VAC, 50/60Hz) to the terminals marked [L, N] on power supply board (Fig. 3, pg. 7). Use 14AWG or larger for all power connections (Battery, DC output, AC input). Connect ground lug to earth or green branch wire (12AWG min.). Keep power-limited wiring separate from non power-limited wiring by utilizing separate knockouts/ inlets. Minimum 0.25″ spacing must be provided. CAUTION: Do not touch exposed metal parts. Shut branch circuit power before installing or servicing equipment. There are no user serviceable parts inside. Refer installation and servicing to qualified service personnel.
Input/Data Connections: 1. Connect structured cables from port marked [Port 1] to [Port 4] on NetWay unit to PoE compliant
cameras/edge devices (Fig. 2, pg. 6). 2. Insert SFP module into port marked [SFP], then connect cable to the SFP module on NetWay4E1BTB to
the corresponding input of an SFP switch (Fig. 2, pg. 6).
Battery Backup (NetWay4E1BTWP/NetWay4E1BTWPX*/NetWay4E1BTX/NetWay4E1BTPL): 1. Connect two (2) 12VDC batteries wired in series or one (1) 24V battery to terminals marked [ BAT +] (Fig. 3, pg. 7), carefully observing polarity. When use of stand-by batteries is desired, they can be LiFePO4 (lithium iron phosphate), lead acid or gel type. Note: When batteries are not used, a loss of AC will result in the loss of output voltage. Note: When using two 12V LiFePO4 (lithium iron phosphate) batteries, check with manufacturer specifications that batteries can be connected in series. For outdoor battery backup, battery enclosure must have sufficient ventilation.
– 4 –
NetWay4E1BT Series Installation Guide
Recommended Altronix Power Sourcing Equipment:
NetWaySP4P
Ethernet to Fiber Media Converter with Integral Power Supply/Charger. Four (4) 56VDC non power-limited outputs up to 120W max. full power per port
(240W total power). Four (4) 1Gb SFP ports.
NetWaySP4PX Ethernet to Fiber Media Converter with Integral Power Supply/Charger. Four (4) 56VDC non power-limited outputs up to 120W max. full power per port
(480W total power). Four (4) 1Gb SFP ports.
NetWaySP4P2 Ethernet to Fiber Media Converter with Integral Power-Limited Power Supply/Charger.
Four (4) 56VDC power-limited outputs up to 60W max. full power per port
(240W total power). Four (4) 1Gb SFP ports.
WayPoint562 High Current Outdoor Power Supply/Charger. 56VDC/120W output.
Filtered and electronically regulated output. Short circuit and thermal overload protection.
Vertiline563 EIA 19″ 1U Rack Mountable Dual Independent Power Supply/Charger.
56VDC @ 3A each output.
Filtered and electronically regulated output. Short circuit and thermal overload protection.
PoE240
Power Supply/Charger Board. 56VDC/240W output.
Filtered and electronically regulated output. Short circuit and thermal overload protection.
Recommended Altronix SFP Modules:
Altronix P1MM, P1SM10, P1AB2K and P1GCE are hot-pluggable SFP fiber transceiver modules and are readily usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates. P1MM For use with Multi-Mode Fiber for distances up to 550m. P1SM10 For use with Single-Mode Fiber for distances up to 10km. P1AB2K For use with Single Strand Single-Mode Fiber for distances up to 2km. P1GCE For use with CAT5e or better for distances up to 100m.
Technical Specifications:
Parameter Description
Number of Ports
Four (4) 10/100/1000 Mbps Ethernet ports rated at 90W each. IEEE 802.3af, 802.3at, 802.3bt compliant. One (1) Gigabit SFP Port.
Input Power Requirements
NetWay4E1BTWP/NetWay4E1BTWPX/NetWay4E1BTX/NetWay4E1BTPL: 115VAC, 60Hz, 1.8A or 230VAC, 50/60Hz, 1A. NetWay4E1BTB/NetWay4E1BTWPN: 48-56V UL Listed ITE power supply.
Environmental Conditions
Operating Ambient Temperature: 240W: 30ºC to 55ºC ( 22ºF to 131ºF) 180W: 30ºC to 65ºC ( 22ºF to 149ºF) 150W: 30ºC to 75ºC ( 22ºF to 167ºF).
Storage Temperature: 30ºC to 85ºC ( 22ºF to 185ºF) Relative Humidity: 85%, +/ 5% Operating Altitude: 304.8 to 2,000m
Model
Product Weight
Shipping Weight
Weights (approx.)
NetWay4E1BTWP NetWay4E1BTWPX NetWay4E1BTWPN
NetWay4E1BTX NetWay4E1BTPL NetWay4E1BTB
10.5 lb. (4.76 kg) 15 lb. (6.8 kg) 9.5 lb. (4.3 kg)
6.65 lb. (3.02 kg) 2.6 lb. (1.18 kg) 0.4 lb. (0.18 kg)
11.9 lb. (5.4 kg) 17.5 lb. (7.9kg) 10.9 lb. (4.9 kg) 7.55 lb. (3.42kg) 4.0 lb. (1.81kg) 0.75 lb. (0.34 kg)
NetWay4E1BT Series Installation Guide
– 5 –
Typical Applications:
Fig. 2 – NetWay4E1BTB/NetWay4E1BTWPN Typical Application with Hybrid Cable
Carefully observe polarity
IP Device
IP Device
(802.3af / 802.3at / 802.3bt) (802.3af / 802.3at / 802.3bt)
PWR
Input: 48V-56VDC
+
IP Device
(802.3af / 802.3at / 802.3bt)
IP Device
(802.3af / 802.3at / 802.3bt)
SFP1 ALOS SFP Port
Altronix Corp.
Brooklyn, NY US www.altronix.com
NetWay4E1BTB
Hybrid Cable
Fiber Switch
48-55V UL Listed ITE Power Supply Carefully observe polarity
Power Distance Chart
Power
Power
Requirements Cabling
15W
12/2
30W
12/2
45W
12/2
60W
12/2
75W
12/2
90W
12/2
105W
12/2
120W
12/2
Maximum Distance (ft./m) 11,162′ / 3403m 5,581′ / 1702m 3,767 / 1,148m 2,739′ / 835m 2,249′ / 686m 1,872′ / 571m 1,607′ / 490m 1,408′ / 429m
Power Requirements 15W 30W 45W 60W 75W 90W 105W 120W
Power Cabling
16/2 16/2 16/2 16/2 16/2 16/2 16/2 16/2
Maximum Distance (ft./m) 4,415′ / 1,346m 2,207′ / 673m 1,490′ / 454m 1,083′ / 330m
889′ / 271m 740′ / 226m 635′ / 194m 557′ / 170m
Estimated distances are based on starting voltage of 56VDC and accounts for a 10 volt drop.
All distances are per IEEE 802.3at standard for device power requirements of minimum 44VDC and leave an approximate 2 volts for safety and flexibility.
– 6 –
NetWay4E1BT Series Installation Guide
Typical Applications:
Fig. 3 – NetWay4E1BTWP/NetWay4E1BTWPX/NetWay4E1BTX/NetWay4E1BTPL
BAT 24V + DC 56V +
PWR
Input: 48V-56VDC
+
SFP1 ALOS SFP Port Altronix Corp. Brooklyn, NY US www.altronix.com
NetWay4E1BTB
To 24V Stand-by Batteries
5A 250VA
LG N
115/230VAC Input
Cable Guide
Separate Inlets
IP Device
(802.3af / 802.3at / 802.3bt)
IP Device
(802.3af / 802.3at / 802.3bt)
Fiber to Switch
IP Device
(802.3af / 802.3at / 802.3bt)
IP Device
(802.3af / 802.3at / 802.3bt)
NetWay4E1BT Series Installation Guide
– 7 –
Wall Mount Installation
1. Place unit at desired location and secure with mounting screws (not included) (Fig. 4, pg. 8). Fig. 4
Pole Mounting Using Optional Pole Mount Kit PMK1 (NetWay4E1BTWP) or PMK2 (NetWay4E1BTWPX):
This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 and PMK2 outdoor pole mount kits are designed to simplify the installation of Altronix outdoor rated power supplies and accessories housed in models WP1, WP2, WP3 and WP4 NEMA rated enclosures. PMK1 and PMK2 can be mounted on 2″ to 8″ (50.8mm to 203.2mm) diameter round or 5″ (127mm) square poles. Brackets are designed for use with the Wormgear Quick Release Straps (two included). 1. Thread one (1) wormgear quick release strap through the slots on the back of a mounting bracket (Fig. 5, pg. 8). 2. Once the desired height of the top Pole Mount bracket is achieved, tighten the straps down by sliding open
end of the strap through the locking mechanism on the strap, then tighten the screw with flat head screwdriver or 5/16″ hex socket driver (Fig. 6, pg. 8 and Fig. 8, pg. 8).
Fig. 5
Fig. 6
Fig. 7
3. Attach the bottom bracket to the enclosure by inserting bolts through the flange of the enclosure and into the bracket, tightening bolts with a 7/16″ hex socket (Fig. 7, pg. 8).
4. Thread the second wormgear quick release strap through the slots on the back of the bottom mounting bracket (Fig. 5, pg. 8).
5. Mount enclosure onto the top bracket by inserting bolts through flange of the enclosure and into the bracket, tightening bolts with a 7/16″ hex socket (Fig. 7, pg. 8).
6. Tighten the straps of the bottom bracket down by sliding the open end of the strap through the locking mechanism on the strap, then tighten screw with flat head screwdriver or 5/16″ hex socket driver (Fig. 5, pg. 8).
7. Clip excess straps.
Fig. 8
Fig. 9 2″ to 8″(50.8mm to 203.2mm) diameter round pole
Fig. 9a 5″ (127mm) square pole
– 8 –
NetWay4E1BT Series Installation Guide
NetWay4E1BTWP/NetWay4E1BTWPN Mechanical Drawing and Dimensions (H x W x D approx.):
13.31″ x 11.31″ x 5.59″ (338.1mm x 287.3mm x 142mm)
FRONT VIEW
RIGHT SIDE VIEW
11.31″ (287.3mm)
3.96″ (100.6mm)
1.61″ (40.9mm)
12.75″ (323.9mm)
13.31″ (338.1mm)
13.50″ (342.9mm) 12.00″ (304.8mm)
10.25″ (260.4mm) 5.59″ (142mm)
FRONT VIEW COVER REMOVED
10.75″ (273.1mm) 10.00″ (254mm) 8.25″ (209.6mm)
END VIEW
STAINLESS STEEL PIANO HINGE
10-32 X 0.375″ (9.5mm) BRASS INSERT (X4)
PADLOCK LATCH ATTACHED WITH RIVETS (Ø 0.375″ (9.5mm) PADLOCK EYE)
8.00″ (203.2mm)
Ø 0.32 (8.1mm) MOUNTING HOLE TYP. 4 PLACES
10-32 X 0.25″ (6.4mm) BRASS INSERT (X2)
NetWay4E1BT Series Installation Guide
– 9 –
NetWay4E1BTWPX Mechanical Drawing and Dimensions (H x W x D approx.):
17.53″ x 15.3″ x 6.67″ (445.3mm x 388.6mm x 169.4mm)
FRONT VIEW
RIGHT SIDE VIEW
15.3″ (388.6mm)
1.67″ (42.4mm)
5.00″ (127mm)
17.36″ (441 mm) 16.73″ (425mm)
17.53″ (445.3mm) 16.00″ (406.4mm)
A
A
FRONT VIEW COVER REMOVED
14.54″ (369.3mm) 14.00″ (355.6mm) 12.23″ (310.6mm)
316 STAINLESS STEEL PADLOCK LATCH ATTACHED WITH RIVETS. Ø 0.375 PADLOCK EYE
SECTION A-A
0.125″ (3.2mm)
14.25″ (362mm) 16.74″ (425.2mm) 6.67″ (169.4mm)
4.94″ (125.5mm) 5.77″ (146.6mm) 6.41″ (162.8mm) 0.75″ (19.1mm)
10-32 X 0.250 BRASS INSERT 4 PLCS.
MOUNTING PLATE
END VIEW
Ø 0.32″ (8.1mm) WALL MOUNTING HOLE X 4
12.00″ (304.8mm)
– 10 –
NetWay4E1BT Series Installation Guide
NetWay4E1BTX Mechanical Drawing and Dimensions (H x W x D approx.):
13.5″ x 13″ x 3.25″ (342.9mm x 330.2mm x 82.6mm)
1.40″ (35.6mm)
4.85″ (123.2mm)
4.85″ (123.2mm)
1.40″ (35.6mm)
1.20″ (30.5mm)
3.25″ (82.6mm)
1.20″ (30.5mm)
1.40″ (35.6mm)
0.75″ (19.1mm)
12.5″ (317.5mm) 11.0″ (279.4mm)
0.75″ (19.1mm)
0.9375″ (23.8mm)
1.20″ (30.5mm)
1.40″ (35.6mm)
5.10″ (129.5mm)
5.10″ (129.5mm)
13.0″ (330.2mm)
6.5625″ (166.7mm)
5.10″ (129.5mm)
3.25″ (82.6mm)
0.9375″ (23.8mm)
3.25″ (82.6mm)
3.25″ (82.6mm)
1.0″ (25.4mm)
1.0″ (25.4mm)
10.5″ (266.7mm)
1.0″ (25.4mm)
NetWay4E1BT Series Installation Guide
– 11 –
NetWay4E1BTPL Mechanical Drawing and Dimensions (H x W x D approx.):
10.75″ x 8.875″ x 2.375″ (273.1mm x 225.4mm x 60.3mm)
8.875″ (225.4mm) 8.25″ (209.5mm)
0.25″ (6.4mm)
10.25″ (260.3mm) 10.75″ (273.1mm)
Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: [email protected] | Lifetime Warranty
IINetWay4E1BT Series
C17W
MEMBER
– 12 –
NetWay4E1BT Series Installation Guide
Altronix Home
