AND-9207-CL-MK Andover One Light Outdoor Post Mount
Product Information:
- Model: AND-9207-CL-MK
- Manufacturer: Crystorama.com
- Part Numbers:
- A. (1)-Top Cage
- B. (1)-Glass Shade; W5.75 x H6.5; XHX9201GLA6.5IN
- C. (4)-Nut; XHX9201MKNUT
- D. (1)-Bottom Cage
- E. (1)-Socket
- F. (1)-Fitter
- G. (3)-Screws
- H. (1)-Post (Not Included)
- Recommended Bulb: 1 – Medium Bulb 60 Watts
- Maximum Bulb Wattage: 100 Watts
- Bulb Type: LED bulbs are recommended for extended use
- Fixture Rating: Wet Rated
Product Usage Instructions:
- To install the glass shade:
- Separate the Bottom Cage by removing the Nut.
- Insert the Glass Shade into the Bottom Cage.
- Install the bulb into the socket.
- Attach the Bottom Cage to the Top Cage by screwing a Nut
securing the two together. - Place the fixture over the post and mark 3 points on the post
at the center of each hole on the post fitter. - Drill the holes at the marked points.
- Make the wire connections, then place the fixture base over the
post and secure it down by tightening the screws.
Glass Replacement:
Follow instruction steps #1-7 in reverse, skipping step #3, #5,
and #6.
Bulb Replacement (Bulb not included):
Follow instruction steps #1-7 in reverse, skipping step #5 and
#6.
ASSEMBLY INSTRUCTION MODEL #AND-9207-CL-MK
Crystorama.com
3″ [76]
You will need 1 – Medium Bulb 60 Watts Recommended 100 Watts Max. (Bulb not included) USE LED BULBS FOR EXTENDED USE THIS FIXTURE IS WET RATED
1. To install the glass shade, separate the Bottom Cage by removing the Nut.
2. Insert the Glass Shade into the Bottom Cage. 3. Install the bulb into the socket. 4. Attach the Bottom Cage to the Top Cage by
screwing a Nut securing the two together. 5. Place the fixture over the post and mark 3 points
on the post at the center of each hole on the post fitter. 6. Drill the holes at the marked points 7. Make the wire connections then place the fixture base over the post and secure down by tightening the screws
Glass Replacement: Follow instruction steps #1-7, in reverse, skipping step #3, #5 and #6.
Bulb Replacement (Bulb not included): Follow instruction steps #1-7, in reverse, skipping step #5 and #6.
ASSEMBLY INSTRUCTION MODEL #AND-9207-CL-MK
Crystorama.com
Part Numbers A. (1)-Top Cage B. (1)-Glass Shade; W5.75″ x H6.5″; XHX9201GLA6.5IN C. (4)-Nut; XHX9201MKNUT D. (1)-Bottom Cage E. (1)-Socket F. (1)-Fitter G. (3)-Screws H. (1)-Post (Not Included)
