MS964214CEFG 1.28 Gpf Toilet
Product Information:
- Product Name: MS964214CEF CST964CEF CST964CEFT
- Available Colors:
- (#01) Cotton
- (#03) Bone
- (#11) Colonial White
- (#12) Sedona Beige
- (#51) Ebony
Product Usage Instructions:
- Remove the tank lid (Item 1) by detaching the Velcro tape (Item
2). - Inspect and replace the fill valve (Item 3), flapper with chain
(Item 4), and drain valve (Item 5) if necessary. - Check and replace the flush tower (Item 6) if needed.
- If there are any leaks, replace the seal gasket (Item 7 or Item
8). - For top mounting, use the top mounting seat hardware (Item
9). - To control the flushing mechanism, attach the trip lever (Item
10) in the desired finish: Chrome Plated (THU225#CP), Brushed
Nickel (THU225#BN), or Polished Nickel (THU225#PN). - If required, use the rough-in mounting hardware kit (Item
11). - If you need a cover plate set, select the appropriate option
with Velcro tape (Item 12) in your desired color. - If a UniFit rough-in is necessary, choose the suitable option:
10 Rough-In (TSU03W.10R), 12 Rough-In (TSU03W.12R), or 14 Rough-In
(TSU03W.14R). - Refer to the Parts Manual (FEB 2023) for additional
information.
MS964214CEF CST964CEF CST964CEFT
MS964214CEFG CST964CEFG CST964CEFGT
MS964214CEFG
Eco Soirée® 1.28 Gpf Toilet, Elongated, Tornado FlushTM, UniFit Rough-In Universal Height, (including CEFIONTECT®)
Item Part
Description
1 TCU964CRE#01 Tank Lid w/ Velcro Tape – Cotton
TCU964CRE#03 Tank Lid w/ Velcro Tape – Bone
TCU964CRE#11 Tank Lid w/ Velcro Tape – Colonial White
TCU964CRE#12 Tank Lid w/ Velcro Tape – Sedona Beige
TCU964CRE#51 Tank Lid w/ Velcro Tape – Ebony
2 THU107
Velcro Tape
3 TSU81.30-A
Fill Valve
4 THU500S
Flapper w/ Chain
5 THU453.10C-A Drain Valve
6 THU440-A
Flush Tower
7 THU407
Seal Gasket (1 piece)
8 THU370
Seal Gasket (10 pieces)
9 THU651N
Top Mounting Seat Hardware
10 THU225#CP
Trip Lever – Chrome Plated
THU225#BN
Trip Lever – Brushed Nickel
THU225#PN
Trip Lever – Polished Nickel
11 THU020N
Rough-In Mounting Hardware Kit
12 TCU964CV#01 Cover Plate Set w/ Velcro Tape – Cotton
TCU964CV#03 Cover Plate Set w/ Velcro Tape – Bone
TCU964CV#11 Cover Plate Set w/ Velcro Tape – Colonial White
TCU964CV#12 Cover Plate Set w/ Velcro Tape – Sedona Beige
TCU964CV#51 Cover Plate Set w/ Velcro Tape – Ebony
13 TSU03W.10R
UniFit – 10″ Rough-In
TSU03W.12R
UniFit – 12″ Rough-In
TSU03W.14R
UniFit – 14″ Rough-In
Actual Product may vary slightly from illustration.
PD-00364 v.17
Note:
Product Number Explanations
One-Piece Toilet
(MS) Toilet & Seat Combination (CST) Gravity Type Toilet (964) Toilet Model (214) Seat Model (C) Tornado FlushTM (F) Universal Height (G) CEFIONTECT® (T) Drain Valve Tower
Colors
(#01) Cotton (#03) Bone (#11) Colonial White (#12) Sedona Beige (#51) Ebony
Parts Manual FEB 2023
