INSTALLER FRIENDLY SERIES® (IFS) IN-SITE®
SINGLE PHASE SIMPLEX
Demand Dose or Timed Dose, Float or C-LevelTM Sensor Controlled System for Pump Control, System Monitoring, Event Logging and Reporting

3 A 15 C D 16 17

2

9 10 14

1

5 6 B
18 13

Installer Friendly Series®

EF
Get In-Site® to your On-SiteTM Systems!
The IFS In-Site® simplex control panel utilizes an innovative circuit board design to control one 120/208/240V single phase pump in water and sewage applications. IFS panels feature an easy-to-use touch pad on inner door for programming and system monitoring. Quick retrieval of all system events can be done by downloading panel information onto a USB flash drive. The panel configuration can be easily converted in the field to either a timed dose or demand dose. Available with the EZconnex® float system.
Monitor system events including pump run times, pump cycles, alarm conditions, power outages, service calls and more! Quick, convenient reports make diagnosing system conditions easy! Plug the flash drive into the USB port located on the inner door of the IFS In-Site® panel to download system events which occurred. No computer is needed at the site! Use the flash drive (included with panel) with any computer to download system information and reports. The pre-loaded software on the flash drive formulates system data for you, creating reports quickly in an easy-to-read format so system conditions can be easily identified and corrected. In addition to monitoring system events, the IFS In-Site® panel logs any service calls and changes made to system settings, which helps protect service providers.
The panel can utilize the C-LevelTM sensor for continuous level monitoring. It senses the level in the tank and sends a signal to the panel. Pump activation levels can be adjusted by using the panel touch pad. C-LevelTM CL40 sensor operating range is 3-39.9 inches (7.6-101.3 cm). C-LevelTM CL100 operating range is 3-99.5 inches (7.6-252.7 cm).
TOUCH PAD FEATURES
A. Level Status indicators illuminate when floats or set points are activated; alarm will activate if a float operates out of sequence
B. HOA (Hand-Off-Automatic) buttons with indication control pump mode; Hand mode defaults to Automatic when stop level or redundant off level is reached
C. Pump Run indicator illuminates when pump is called to run D. LED display for system information including: level in inches or centimeters
(C-LevelTM sensor only), mode, pump elapsed time (hh:mm), events (cycles), alarm counter, float error count, timed dose override counter (timed dose only), pump ON/OFF times (timed dose only), and sequence ON/OFF times (timed dose only) E. NEXT push button toggles display F. UP and SET push buttons used to set pump ON/OFF times (timed dose only), date and hour, activation levels (C-LevelTM only)

7 8 12

11

Panel layout may vary with options. Reg. Cdn Pat. & TM Off C-LevelTM Sensor US Patent No. 8,336,385; 8,567,242; 8,650,949
COMPONENTS
1. Enclosure base measures 14 x 12 x 6 inches (35.56 x 30.48 x 15.24 cm); NEMA 4X (ultraviolet stabilized thermoplastic with removable mounting feet for outdoor or indoor use)
2. Red LED beacon provides 360° visual check of alarm condition 3. Exterior Alarm Test/Normal/Silence switch allows horn and
light to be tested and horn to be silenced in an alarm condition; alarm automatically resets once alarm condition is cleared 4. Alarm horn provides audio warning of alarm condition (83 to 85 decibel rating) (Not shown) 5. Circuit breaker (optional) provides pump disconnect and branch circuit protection 6. Power relay controls pump by switching electrical lines; definite purpose contactor used when pump full load amps are above 15 7. Float connection terminal block 8. Incoming control/alarm terminal block 9. Control Power indicator/fuse indicator light illuminates if control power is present in panel; alarm will activate if control fuse is blown 10. Alarm Power indicator/fuse indicator light illuminates if alarm power is present in panel 11. Ground lug 12. Incoming pump power connections 13. RF filter 14. Power supply 15. Control fuse 16. Alarm fuse 17. USB port for flash drive to download time-stamped system events 18. Manual report switch date and time stamps service calls Note: Options, voltage, and amp range selected may change enclosure size and component layout. Note: Schematic/Wiring Diagram and Pump Specification Label are located inside the panel.

9500059J Rev 01/23 © 2020 SJE, Inc. All Rights Reserved. SJE Rhombus is a trademark of SJE, Inc.

www.sjerhombus.com · Toll Free 888-342-5753

B.23

Installer Friendly Series®
PRICING WORKSHEET

INSTALLER FRIENDLY SERIES® IN-SITE® SINGLE PHASE SIMPLEX – Demand or timed dose float controlled system for pump control, system monitoring, event logging and reporting.

IFI
CONTROL PANEL

MODEL TYPE

1
ALARM PACKAGE

W
ENCLOSURE RATING

STARTING DEVICE

PUMP FULL LOAD AMPS

PUMP

FLOAT SWITCH

DISCONNECTS APPLICATION

8AC
OPTIONS (LISTED BELOW)

CONTROL PANEL 3 IFI

MODEL TYPE

1 Simplex Timed Dose (includes Option 8AC as standard) 2 Simplex Demand Dose (includes Option 8AC as standard)

ALARM PACKAGE 3 1 Alarm Package (includes test/normal/silence switch, fuse, red light, & horn)

ENCLOSURE RATING 3 W Weatherproof, NEMA 4X (engineered thermoplastic)

STARTING DEVICE

1 120/208/240V 9 120V only

PUMP FULL LOAD AMPS

0 0 – 7 FLA 1 7 – 15 FLA 2 15 – 20 FLA

0 No Pump Disconnect

PUMP DISCONNECTS

4 Circuit Breaker 120V (select STARTING DEVICE Option 9 above) Circuit Breaker 120/208/240V (select STARTING DEVICE Option 1 above)

H

Floats – Pump Down (select Option 17 below) Timed dose = timer enable and alarm / Demand dose = stop, start, and alarm

FLOAT SWITCH APPLICATION

E

EZconnex® Float Switch System (select Option 33, 35 or 36 below)

X No Floats

Timed Dose Demand Dose Timed Dose Demand Dose

C

C-LevelTM Sensor (select Option 24 or 29) Select Option 3E and/ Timed Dose

or 4A & 4D for high water alarm and/or redundant off floats

Demand Dose

NOTE: Pump down applications only. Industry practices suggest that a secondary device, such as a float switch, be used for redundant activation of the high level alarm and pump shut off when using the C-LevelTM sensor.

IFI Simplex Base Price Alarm Package
Enclosure Rating Starting Device
Pump Full Load Amps Pump Disconnects
Float Switch Application Total Options
TOTAL LIST PRICE

OPTIONS 1J 3A 3B

Duo Alarm Inputs Alarm Flasher Manual Alarm Reset

DESCRIPTION

3E

High Water Alarm Float (must also select Option 17) Only Available with Float Switch Application = C

4A

Redundant Off

Timed Dose

(must also select Option 4D if floats are required) Demand Dose

4D Redundant Off Float (must also select Option 4A and Option 17)

6A Auxiliary Alarm Contact, Form C

Display Board – Includes: ETM Counter, Events (Cycles) Counter, 3 8AC Alarm Counter, and Override Counter (Timed Dose Only) (in-
cluded as standard)

10E Lockable Latch – NEMA 4X

10F

Lightning Arrestor (select pump circuit breaker, control and alarm power combined)

10K

Anti-condensation Heater (must select if operating temperature is colder than 0 degrees F or -18 degrees C)

11C Additional NEMA 1 Remote Alarm Panel (must also select Option 6A) 11D Additional NEMA 4X Remote Alarm Panel (must also select Option 6A) 15A Control/Alarm Circuit Breaker 16A 10′ Cord in Lieu of 20′ Cord (per Float) 16B 15′ Cord in Lieu of 20′ Cord (per Float) 16C 30′ Cord in Lieu of 20′ Cord (per Float) 16D 40′ Cord in Lieu of 20′ Cord (per Float)

OPTIONS 17C 17D 17G 17H 17J 18A 24E 24F 24G 24H 24X 29A 29B 29X
33D 33E 33G 33H 35D 35E 35G 35H 36D 36E 36G 36H

DESCRIPTION Sensor Float® / Internally Weighted (per Float) – Mercury Sensor Float® / Externally Weighted (per Float) – Mercury SJE MilliAmpMasterTM / Pipe Clamp (per Float) – Mechanical SJE MilliAmpMasterTM / Externally Weighted (per Float) – Mechanical Sensor Float® / Pipe Clamp (per Float) – Mercury Timer Override Float (Timed Dose Float Panel Only) C-LevelTM CL40 Sensor with 4′ Vent Tube and 20′ Cord C-LevelTM CL40 Sensor with 4′ Vent Tube and 40′ Cord C-LevelTM CL40 Sensor with 8′ Vent Tube and 20′ Cord C-LevelTM CL40 Sensor with 8′ Vent Tube and 40′ Cord No C-LevelTM CL40 Sensor C-LevelTM CL100 Sensor with 10′ Vent Tube and 20′ Cord C-LevelTM CL100 Sensor with 10′ Vent Tube and 40′ Cord No C-LevelTM CL100 Sensor EZconnex® 3-Port, 25′, with 10′ Floats (3) / Pipe Clamp EZconnex® 3-Port, 50′, with 10′ Floats (3) / Pipe Clamp EZconnex® 3-Port, 25′, with 20′ Floats (3) / Pipe Clamp EZconnex® 3-Port, 50′, with 20′ Floats (3) / Pipe Clamp EZconnex® 4-Port, 25′, with 10′ Floats (4) / Pipe Clamp EZconnex® 4-Port, 50′, with 10′ Floats (4) / Pipe Clamp EZconnex® 4-Port, 25′, with 20′ Floats (4) / Pipe Clamp EZconnex® 4-Port, 50′, with 20′ Floats (4) / Pipe Clamp EZconnex® 3-Port, 25′, with 10′ Floats (2) / Pipe Clamp, Sealing Plug EZconnex® 3-Port, 50′, with 10′ Floats (2) / Pipe Clamp, Sealing Plug EZconnex® 3-Port, 25′, with 20′ Floats (2) / Pipe Clamp, Sealing Plug EZconnex® 3-Port, 50′, with 20′ Floats (2) / Pipe Clamp, Sealing Plug

EZconnex® mechanically-activated, narrow angle float switches with quick release connections

B.24

www.sjerhombus.com · email: [email protected] SEE PRICE BOOK FOR PRICING.
