EHDH9W001 Hydra 9 Hand Dryer
Product Information
The Hydra 9 is an indoor hand dryer designed for efficient and
hygienic hand drying. It is important to follow the safety
instructions and technical specifications provided in the user
manual to ensure proper installation and safe operation of the
unit.
Important Safety Instructions
- Ensure installation is done by qualified personnel in
accordance with applicable codes and standards. - Avoid damaging electrical wiring and hidden utilities when
cutting or drilling into walls or ceilings. - Use a dedicated circuit branch protected by a circuit breaker
with the appropriate rating. - Do not install the unit outdoors or close to moisture and heat
generators. - Only qualified personnel should perform maintenance, repair,
and removal of the unit. - Supervise children to prevent them from playing with the
appliance.
Technical Specifications
- Operating Voltage: [Operating Voltage]
- Qmode Voltage: [Qmode Voltage]
- Standby Power: [Standby Power]
- Air Speed (sensing max): [Air Speed]
- Motor Type: [Motor Type]
- Sensor Type: [Sensor Type]
- Sensor Range: [Sensor Range]
- Timing Protection: [Timing Protection]
- Drying Time: [Drying Time]
- Drip Proof: [Drip Proof]
- Isolation: [Isolation]
- Unit Size: [Unit Size]
Product Usage Instructions
Unpacking
- Remove all packing material, recycling is recommended.
- Carefully remove the hand dryer from the shipping carton,
avoiding dropping the appliance. - Inspect the hand dryer for any damage that may have occurred
during transit. Check for loose, missing, or damaged parts. If
damaged, inform the shipper or dealer promptly.
Installation
1. Place the main cover on a cloth
To avoid marking its surface, place the main cover on a
cloth.
2. Remove side security screws
Using the service tool, remove the 2 side security screws to
lift the front cover off the main body.
3. Positioning
- Mark the location on the wall with a pencil using the
Installation Template to mark the locations for the four fixing
points. - Pre-drill the wall using a 5/16 (8mm) drill in the marked
locations, insert the plastic anchors, and tap flush to the wall.
If cable entry is from the wall, provide a proper cable exit.
4. Installing Power cable & Connection terminal block
Connect the ground wire to the terminal block marked “LN”
without over-tightening and crushing the power cable.
5. Quiet Mode Switch
The unit may have a Quiet Mode Switch. Check the factory default
setting and adjust if necessary.
Hydra 9
User Manual
EN
IMPORTANT SAFETY INSTRUCTIONS
WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS OBSERVE THE FOLLOWING:
· Use this unit only in the manner intended by the manufacturer. The manufacturer is not responsible for
any damages caused by misuse or defective installation.
· The instructions contained within the installation Template must be followed carefully when installing
this unit. Failure to accurately follow the instructions may result in the incorrect operation of this unit,
·
damage to property and/or personal injury. Installation work and electrical wiring must be done by qualified person(s) in accordance with all
applicable codes and standards, including fire-rated construction.
·
When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities. This unit must be powered by a dedicated circuit branch protected by a circuit breaker with the
·
appropriate rating. Circuit cable must be fit current consumption for this unit. This unit has been designed for indoor use only, protect from water, sun and extreme temperatures, do
·
not install it outdoors or close to moisture and heat generators. This unit can only be revised, maintained, repaired and removed by qualified person(s).
·
If the unit stops and works strangely, contact your regional dealer or contractor. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
TECHNICAL SPECIFICATIONS
Operating Voltage Qmode Voltage Standby Power Air Speed (sensing max) Motor Type Sensor Type Sensor Range Timing Protection Drying Time Drip Proof Isolation Unit Size
AC 220~240 V, 50 Hz- 60Hz, 840 W AC 220~240 V, 50 Hz- 60Hz, 550 W 1W 100 m/s Brushed Motor, 30,000 RPM Auto Infrared touch free operation 45° 15~25cm 50 seconds auto shut off 10 ~ 12 sec IPX3 CLASS I H 256mm x W 174.5mm x D 110mm
UNPACKING
1. Remove all packing material. Recycling is recommended. 2. Carefully remove the hand dryer from the shipping carton, using care not to drop the appliance. 3.Inspect carefully for any damage that may have occurred during transit. Check for any loose, missing or damaged parts. If the hand dryer is damaged, promptly inform the shipper or dealer where you purchased it. Standard items with the hand dryer are shown in Fig.1 together with tools need by the installer.
1
User Manual
Installation Service Tool
Wall mounting
Unit
User Manual template & Spare Screw anchors with screws
INSTALLATION
1.1 Place the main cover on a cloth to avoid marking its surface. 1.2 Remove 2 side security screws, using the service tool (fig.2) . 1.3 Lift the front cover off the main body. (fig.3).
2
3
Open
Close
CAUTION
· Make sure power supply breaker is switched off. · Check that the electrical supply corresponds to that shown on the rating plate. If the unit is
connected to any electrical supply other than stated on the rating plate of the unit, permanent damage or unsafe operation of the unit may result. · The unit must be mounted on a flat vertical wall capable of supporting the full weight of the unit.
2. Positioning
2.1 Mark the location on the wall with a pencil. Use the Installation Template to mark the locations for the four fixing points (fig. 4). 2.2 Pre-drill the wall in the marked locations using 5/16″ (8mm) drill, insert the plastic anchors and tap flush to the wall. If the cable entry is to be done from the wall provide a proper cable exit (fig. 5)
4
5
146mm
8
Installation Template
110mm 110mm
3. Installing Power cable & Connection terminal block
WARNING: ENSURE POWER NOT CONNECTED 3.1 Pull the cable through the hole in the back panel. Ensure the cable is long enough to the terminal block (fig. 6). 3.2 As shown, connect cable to terminal block. 3.3 The cable must sit in the dedicated channel. If the cable comes through Power cable entry from outside, it is recommended that the cable is routed via the 3 bosses as in fig. 6B. 4. Fix the front cover to unit and insert and tighten the security screw seated on the side surface. 5. Turn power on and test the unit for correct operation.
CAUTION: Connect the ground wire to the terminal block marked ” ” Do not over-tighten and crush the power cable.
6
6A
6B
Power Cable Entry
LN
Power Cable Exit
(in case with power cord cable
Quiet (Q) Mode Switch
Quiet Mode Switch (Factory default setting “OFF”) 7
1. Remove 2 side security screws, using the service tool (fig.2) . 2. Lift the front cover off the main body. (fig.3). 3. To change Quiet mode, use the right swith shown in fig.7. 4. Reposition the front cover on the unit. 5. Refix the screw situated in the side of fornt cover.
WARNING: ENSURE POWER NOT CONNECTED
Back View
Q-Mode ON
Q-Mode ON
Use
1. No touch operation.
8
2. Shake excess water from hands.
3. Place hands under the outlet to start operation (fig. 9).
4. Slowly move hands back and forth under the outlet at the bottom of the dryer.
5. A blue LED light situated at the bottom of the dryer starts with the dryer
operation. This assists the user in keeping the hands in the dryer’s sensing range.
6. The dryer stops when hands are removed.
7. Hand dryer also auto shuts off after 50 seconds of uninterrupted use.
Maintenance and cleaning
Lift the Unit off the wall mounting bracket before maintenance or repair. Regularly clean the outer casing use a soft, damp cloth to gently wipe away any dirt. CAUTION: Never use abrasives or chemicals to clean the cover. Do not soak.
