JYL9914 Mila 11 Inch Tall LED Wall Sconce
Product Information
Model: JYL9914
Product Dimensions: 5.5”W X 11.3H X 5.7E
Product Usage Instructions
- Preparation:
- Before beginning assembly, ensure all parts are present.
- Compare parts with the package contents list and hardware
contents list. - If any part is missing or damaged, do not attempt to assemble
the product.
- Fix the mounting bracket (B) to the outlet box with machine
screw (A). - Make wire connections using wire connectors (C) based on the
reference chart below:
- Connect Hot, Black or Red Outlet Supply Wire to Black Parallel
Cord (round & smooth) – Clear, Brown, Gold or Black without
Tracer (colored stripes). - Connect Neutral, White Outlet Supply Wire to White Parallel
Cord (square & ridged) – Clear, Brown, Gold or Black with
Tracer (colored stripes) – Insulated Wire (not green) with copper
metal conductor – Insulated Wire (not green) with Silver metal
conductor.
Note: When using parallel wire (SPT I & SPT II), the
neutral wire is square shaped and ridged while the hot wire is
round and smooth. See illustration on the left.
- For installation in the United States: Wrap the ground wire
from the outlet box around the green ground screw on the mounting
bracket, at least 2 inches from the wire end. Tighten the ground
screw. If the fixture is supplied with a ground wire, connect it to
the outlet ground wire using a wire connector. - For installation in Canada: If the fixture is supplied with a
ground wire, wrap the ground wire around the green grounding screw
on the mounting bracket and tighten the ground screw.
protruding from the mounting bracket goes into the holes in the
back plate, then secure it with the Screwed Nut (F).
enter the hole of the Glass Shade (G) to fix the Glass Shade (G) on
the Back Plate (E).
greater than specified on this fixture. Always make sure that
electrical current is turned off before changing bulbs.
Please use Type A bulb max 40-watt or CFL bulb max 13-watt
or LED max 9-watt. There are 1 x 4W LED bulbs included in the
box.
Enjoy Your Lamp!
WARNING WE RECOMMEND INSTALLATION OF THIS LIGHTING FIXTURE BE DONE BY A LICENSED ELECTRICIAN. WARNING *** SWITCH OFF THE MAIN ELECTRICAL SUPPLY FROM THE MAIN FUSE BOX/CIRCUIT BREAKER BEFORE INSTALLATION. INSPECT ITEM CAREFULLY BEFORE ATTEMPTING TO INSTALL. IF THERE IS ANY DAMAGE OR OBVIOUS DEFECT, DO NOT INSTALL. ITEM MAY NOT BE RETURNED ONCE IT HAS BEEN INSTALLED.
CARE AND MAINTENANCE To clean the outside of the fixture, use a dry or slightly dampened clean cloth (use clean water, never a solvent) to wipe the surface of the fixture. To clean the inside of the fixture, first disconnect power to the fixture by turning off the circuit breaker or by removing the fuse at the fuse box. Next, use a dry or slighly damperned clean clorth (use clean water, never a solvent) to wipe the interior surface of the fixture. Do not use any cleaners with chemical, solvents or harsh abrasives. Use only a dry soft cloth to dust or wipe carefully.
NOTICE& IMPORTANT SAFETY INSTRUCTIONS * Please make sure that you have all parts indicated before you begin assembly of this item * This item should be assembled on a soft surface to prevent scratching the finish during assembly * To reduce the risk of fire, electrical shock or injury to persons or property, please follow the guideline below for safe use and installation *The external flexible cable or cord of this lamp cannot be replaced If the cord is damaged, the lamp shall be destroyed
Part List and Hardware List
Model#: JYL9914 Product Dimensions: 5.5”W X 11.3″H X 5.7″E
1/2
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Time: 20 minutes.
1. Fix the mounting bracket(B) to the outlet box with machine screw(A).
2. Make wire connections, with wire connectors(C), following the reference chart listed below.
Connect, Hot, Black or Red Outlet Supply Wire to: Black
* Parallel Cord (round & smooth)
Clear, Brown, Gold or Black without Tracer (colored stripes)
Connect, Neutral, White Outlet Supply Wire to: White
* Parallel Cord (square & ridged)
Clear, Brown, Gold or Black with Tracer (colored stripes)
Insulated Wire (not green) with copper metal conductor
Insulated Wire (not green) with Silver metal conductor.
*Note: When parallel wire ( SPT I & SPT II ) is used. The neutral wire is square shaped and ridged and the hot wire will be round in shape and smooth. ( See Illustration on left. )
Grounding Instructions: a) For installation in the United States: Wrap ground wire from outlet box around green ground screw on mounting bracket, no less than 2″ from wire end. Tighten ground screw. If fixture is supplied with a ground wire, connect to outlet ground wire with a wire connector. b) For installation in Canada: If fixture is supplied with ground wire, wrap ground wire around green grounding screw on mounting bracket. Tighten ground screw.
3. Orient the Back Plate(E) so that the Machine screw(D) protruding from the mounting bracket go into the holes in the back plate, then secure it with the Screwed Nut(F)
4. The Cylinder Nut( I ) passes through the Rubber Pad(H) and enters the hole of the Glass Shade(G) to fix the Glass Shade(G) on the Back Plate(E)
5. Install bulbs(J). Be sure to use light bulb(J) with wattage no greater than specified on this fixture. Always make sure that electrical current is turned off before changing bulbs.
PLEASUE USE TYPE”A” BULB MAX 40-WATT OR CFL BULB MAX 13-WATT OR LED MAX 9-WATT THERE ARE 1 X 4W LED BULBS IN THE BOX.
ENJOY YOUR LAMP
2/2
