504082 Steel Utility Trailer with Ramp Gate
Product Information
The product is a display and sale setup that includes components
such as tongue, fender, fender light, fork loop, front gate, and
back gate. It is designed to facilitate the display and sale of
items.
Tongue Installation
To install the tongue, you will need the following: – 3/8×6 x 2
screws – 3/8 x 2 screws
Procedure:
1. Take the 3/8×6 x 2 screws and attach the tongue to the
designated area. 2. Use the 3/8 x 2 screws to secure the tongue in
place.
Fender and Fender Light Installation
To install the fender and fender light, follow the steps below.
Procedure:
1. Attach the fender and fender light to the appropriate locations
on the product. 2. Secure them in place using screws or other
fastening mechanisms.
Fork Loop Removal
To remove the fork loop, follow the steps below.
Procedure:
1. Locate and remove two screws holding the fork loop in place. 2.
Push the fork loop up towards the center of the product. 3. Remove
the washer plate from the inside channel of the fork loop.
Front and Back Gate Display
To display the front and back gates, use latch locks to keep them
in an upright position.
Procedure:
1. Attach latch locks to the gates. 2. Ensure that the latch locks
are properly secured to keep the gates in the raised position.
Remember to follow all safety guidelines and recommendations
provided in the user manual for optimal usage and performance of
the product.
TO SETUP FOR DISPLAY & SALE
1: TONGUE INSTALLATION
3/8″x6″ x 2
3/8″ x 2
2: FENDER AND FENDER LIGHT INSTALLATION
3/8″ x 2 3/8″x¾” x 3 PUT BOTH FENDER LIGHT BULLETS INTO LOOSE FEMLAE BULLETS AS SHOWN IN PICTURE
3: FORK LOOP REMOVAL
1. Remove Screws x 2
3
2
2
2. Push up towards the center
3. Remove the washer plate from the inside channel
RECYCLE RECYCLER
4: FRONT AND BACK GATE DISPLAY
Put latch locks to keep gates up
