40MTB2000Z LED FHD TV
Metz 40MTB2000Z Product Information: – Manufacturer: Metz Consumer
Electronics GmbH – Model: 40MTB2000Z – Address: Ohmstrasse 55 –
90513 Zirndorf – Contact: Tel. (0911) 9706-0, Email:
[email protected] Product Usage Instructions: 1. Necessary Tools: –
Screw driver PH2 2. Disassembling the Rear Panel: a) Pull out the
mains plug before removing the rear panel. b) Use a screw driver
PH2 to remove the screws. c) Slightly bend open the tabs while
lifting the rear wall at the same time. 3. Disassembling the
Printed Circuit Boards: – Remove screws with a screw driver PH2.
Note: Elkos (electrolytic capacitors) may contain residual charges,
handle with caution. Please refer to the provided diagram
(U2199_40300_00) for additional guidance.
Metz Consumer Electronics GmbH Ohmstrasse 55 – 90513 Zirndorf
Tel. (0911) 9706-0 – [email protected]
Metz 40MTB2000Z
Notwendige Werkzeuge: Nessesary tools:
Schraubendreher PH2 Screw driver PH2
Demontageanleitung Disassembly instructions
PH2
Vor Entfernen der Rückwand
Netzstecker ziehen.
PH2
Pull out the mains plug before
removing the rear panel.
PH2 PH2
1 Demontage der Rückwand
a) Schrauben mit einem Schraubendreher PH2 entfernen. b) Laschen leicht aufbiegen und Rückwand gleichzeitig anheben.
1 Disassembly the rear panel
a) Remove screws with a screw driver PH2. b) Slightly bend open the tabs and lift the rear wall at the same time.
PH2 PH2
2 Demontage der Leiterplatten
Elkos können Restladung
PH2
enthalten.
Elkos may contain residual
charges.
Schrauben mit einem Schraubendreher PH2 entfernen.
2 Disassembly of the printed circuit boards
Remove screws with a screw driver PH2.
Technische Änderungen und Irrtümer vorbehalten! Technical changes and errors excepted!
PH2 PH2 PH2
U2199_40300_00
