PSE Series Photoelectric Sensor

Product Information:
Product Name: PSE series
Detection Types: Through beam, Polarized reflection, Diffuse
reflection
NPN Cable Models: PSE-TM20D, PSE-TM20DNB, PSE-TM10DR, PSE-TM10DNBR,
PSE-TM5DR, PSE-TM5DNBR
PNP Cable Models: PSE-TM20D, PSE-TM20DPB, PSE-TM10DR, PSE-TM10DPBR,
PSE-TM5DR, PSE-TM5DPBR
NPN Connector Models: PSE-TM20D-E3, PSE-TM20DNB-E3, PSE-TM10DR-E3,
PSE-TM10DNBR-E3, PSE-TM5DR-E3, PSE-TM5DNBR-E3
PNP Connector Models: PSE-TM20D-E3, PSE-TM20DPB-E3, PSE-TM10DR-E3,
PSE-TM10DPBR-E3, PSE-TM5DR-E3, PSE-TM5DPBR-E3
Sensing Distance: 0…20m, 0…10m, 0…5m, 0…3m*, 0…100cm,
0…30cm
Spot Diameter: 8mm@30cm
Product Usage Instructions:
1. Connect the appropriate cable or connector to the sensor based
on your application requirements. Use NPN cable models for
NPN-compatible devices and PNP cable models for PNP-compatible
devices. 2. Mount the emitter and receiver units in a suitable
position facing each other for through beam detection. Ensure that
there are no obstacles between the emitter and receiver. 3. For
polarized reflection detection, position the sensor to reflect the
light beam off a polarized surface and receive it back at the
receiver unit. 4. For diffuse reflection detection, position the
sensor to detect the presence or absence of an object based on the
reflected light from the surface of the object. 5. Adjust the
sensing distance according to your application needs. Use the
provided adjustment settings or refer to the user manual for
specific instructions on adjusting the sensing distance. 6. Ensure
that the spot diameter is suitable for your application. Adjust the
position of the sensor or use additional lenses or accessories if
necessary. 7. Take into consideration the hysteresis range to
prevent false triggering of the sensor due to small changes in the
detected object. 8. Consider the direction angle of the sensor and
position it accordingly to achieve optimal detection performance.
9. The light source of the sensor is built-in and does not require
any additional setup or maintenance. 10. Follow all safety
guidelines and precautions mentioned in the user manual for proper
installation and usage of the sensor. 11. For further assistance or
technical support, refer to the contact information provided in the
user manual or visit the manufacturer’s website.

View Fullscreen

PSE

( )

NPN NPN

PSE-TM20D PSE-TM20DNB PSE-TM20D-E3 PSE-TM20DNB-E3

PSE-TM10DR PSE-TM10DNBR

PSE-TM5DR PSE-TM5DNBR

PSE-TM10DR-E3 PSE-TM10DNBR-E3 PSE-TM5DR-E3 PSE-TM5DNBR-E3

PNP

PSE-TM20D PSE-TM20DPB

PSE-TM10DR PSE-TM10DPBR

PSE-TM5DR PSE-TM5DPBR

PNP PSE-TM20D-E3 PSE-TM20DPB-E3 PSE-TM10DR-E3 PSE-TM10DPBR-E3 PSE-TM5DR-E3 PSE-TM5DPBR-E3

0…20

0…10

0…5

PSE-PM3DNBR PSE-PM3DNBR-E3 PSE-PM3DPBR PSE-PM3DPBR-E3
0…3 *

PSE-BC100DNB

PSE-BC30DNBR

PSE-BC100DNB-E3 PSE-BC30DNBR-E3

PSE-BC100DPB

PSE-BC30DPBR

PSE-BC100DPB-E3 PSE-BC30DPBR-E3

0…100

0…30

PSE-BC10DNB PSE-BC10DNB-E3 PSE-BC10DPB PSE-BC10DPB-E3
0…10

/ 10 ( Sn)

8 (30 )

(850)

2°

/ (630)

±2°
(640)

(640)

3…20% / (860) (640) (860)

2…5 , 4 . , . 8 3 , , .

10…30 DC

20 20

200 1

, , ,

NO/NC

5…8 , 2 . , .

1 , ( ) ; ()
10,000 ; 3,000

0,5

-25…+55

teko-com.ru
.: 8 (800) 333-70-75 E-mail: [email protected]

-25…+70 IP67 CE
EN60947-5-2:2012, IEC60947-5-2:2012 : ABS; : PMMA : 50; : 10 .

10% . , .
100 , , 100 .
.
, , .
( ..) .
, .

, .
. . . . ,
. ,
.

* OR12.

, — 2 , OR12 ( ), ZJP-8

, , NPN

()

1 . +

4 .
3 . –

()

10…30

, , PNP

()

. +
1
4 .

. –
3

()

10…30

, ,

1 + 3 –
. + . –

1 + 3 4
. + . .

10…30

()

. +
1
. –
3

()

, ,

( )
M8 : CS S48L-3-2 ( CS S48R-3-2)

M8 : CS S49L-3-2 ( CS S49R-3-2)

()

: FJP-01

FJP-01A FJP-01B FJP-01C

0,5 1,0 2,0

(SUS304)

PVC : 3.9, 4 2 : 12

: OR12 ()

: OR13

: OR10

: FJP-02

FJP-02A FJP-02B FJP-02C

0,5 1,0 2,0

(SUS304)

: OR15

: OR14

: ZJP-8 ()

1. «t» (2…5 ), t < 2 : ,

t 8 , , NO/NC ,

– ;

. 8

3 .

2. ,

«t» (2…5 ), 2 t < 5 , : 4 .

312

, .

t = 2…5

t = 5…8
3. «t» (5…8 ), 5 t < 8 , 2 . , NO/NC.

() ZJP-8
: , 0,5 *

Photoelectric sensor Operation manual

PSE series

teko-com.ru
Tel.: 8 (800) 333-70-75 E-mail: [email protected]

Technical specifications

Detection type

Through beam

Polarized reflection

Diffuse reflection

NPN cable Emitter PSE-TM20D Receiver PSE-TM20DNB Emitter PSE-TM10DR Receiver PSE-TM10DNBR Emitter PSE-TM5DR Receiver PSE-TM5DNBR

PSE-PM3DNBR

PSE-BC100DNB

PSE-BC30DNBR

NPN connector Emitter PSE-TM20D-E3 Receiver PSE-TM20DNB-E3 Emitter PSE-TM10DR-E3 Receiver PSE-TM10DNBR-E3 Emitter PSE-TM5DR-E3 Receiver PSE-TM5DNBR-E3

Model PNP cable

Emitter PSE-TM20D Receiver PSE-TM20DPB Emitter PSE-TM10DR Receiver PSE-TM10DPBR Emitter PSE-TM5DR Receiver PSE-TM5DPBR

PSE-PM3DNBR-E3 PSE-PM3DPBR

PSE-BC100DNB-E3 PSE-BC30DNBR-E3

PSE-BC100DPB

PSE-BC30DPBR

PNP connector Emitter PSE-TM20D-E3 Receiver PSE-TM20DPB-E3 Emitter PSE-TM10DR-E3 Receiver PSE-TM10DPBR-E3 Emitter PSE-TM5DR-E3 Receiver PSE-TM5DPBR-E3 PSE-PM3DPBR-E3 PSE-BC100DPB-E3 PSE-BC30DPBR-E3

Sensing distance

0…20m

0…10m

0…5m

0…3m*

0…100cm

0…30cm

Wide-angle PSE-BC10DNB PSE-BC10DNB-E3 PSE-BC10DPB PSE-BC10DPB-E3
0…10cm

Spot diameter

8mm@30cm

Sensing object Hysteresis range Direction angle Light source
Distance adjustment

Infrared(850nm)

10mm opaque object(within Sn range)

3…20

2°

±2°

Red light(630nm)

Red light(640nm)

Red light(640nm) Infrared(860nm) Red light(640nm) Infrared(860nm)

Press the button for 2 …5s, when the yellow and green light flash synchronously at 4Hz, and lift to finish the distance setting. If the yellow and green light flash asynchronously @8Hz for 3s, setting fails and the product distance goes to the maximum.

Supply voltage Consumption current Load current Voltage drop

Emitter 20mA Receviver 20mA

10…30 VDC
200mA 1V

25mA

Circuit protection NO/NC adjustment

Short circuit, Reverse polarity, Overload, Zener protection Press the button for 5 …8s, when the yellow and green light flash synchronously at 2Hz,and lift to finish the state switching.

Response time Green
Indicator Yellow
Anti-ambient light
Ambient temperature Storage temperature Protection degree

1ms Power, stable signal(unstable signal flash) Output, overload or short circuit(flash)
Anti-ambient light interference10,000lux; Anti-incandescent light interference3,000lux -25…55 -25…70 IP67

0.5ms

Certification

Production standards Material Weight Accessories

EN60947-5-2:2012 IEC60947-5-2:2012 Housing material: ABS Filter: PMMA Cable:about 50g Connector:about 10g Operation manual,screw,reflector OR12(only for polarized reflection sensor) Mounting bracket ZJP-8

Precautions

*The data is the result of the PSE polarized reflection sensor with standard reflector OR12.

The maximum allowable voltage of the sensor is 10% of the rated voltage, Please confirm that the supply voltage is less than the maximum allowable value before powering on
The time from powering-on to normal detection of the sensor is 100ms, please ensure that the sensor is used after 100ms of powering-on
When using different power sources for the sensor and load, be sure to turn on the power of the sensor first
When the sensor is not used, it is recommended to cut off the power of the load first and then turn off the power of the sensor
When installing the sensor, do not subject the sensor to severe external force (such as hammering, etc.), which may damage the sensor performance
Avoid using thinner, alcohol or other organic solvents when cleaning
Safety Warning
Do not use in an environment with flammable, explosive or corrosive gases Do not use in oil or chemical environments Do not use in a high humidity environment Do not use in direct sunlight Do not use in other environmental conditions that exceed the rated value Do not disassemble, repair or modify this product without authorization
Scrap Treatment
When the product is scrapped, please dispose of it as industrial waste

Wiring diagram

Through Beam-receiver, Diffuse Reflection, Polarized Reflection, Wide-angle-NPN Output

Output indication (Yellow)
Photoelectric sensor main circuit

BN 1

Load BK Output 4

BU 3

–

Stability indication (Green)

Through Beam-Emitter

Power indication (Green)
Photoelectric sensor main circuit

BN +
1 10…30V
BU –
3

Through Beam-receiver, Diffuse Reflection, Polarized Reflection, Wide-angle-PNP Output

Output indication (Yellow)
Photoelectric sensor main circuit

BN +
1
BK Output
4
Load BU –
3

Stability indication (Green)

10…30V 10…30V

Terminal Wiring Diagram

Through Beam-Emitter

Diffuse Reflection,Wide-angle Polarized Reflection, Through Beam-Receiver

1 + 3 –
BN + BU –

1 + 3 4 OUT
BN + BU BK OUT

Dimensions
Through Beam, Diffuse Reflection,Polarized Reflection, Wide-angle

Power indication (Green)
Through Beam, Diffuse Reflection,Polarized Reflection, Wide-angle

Accessory Dimensions Sold Separately
M8 Connector:CS S48L-3-2

M8 Connector:CS S49L-3-2

Stable indicator (green)

Action indicator (yellow)

Stable indicator (green)

Action indicator (yellow)

PVC cable: 3.9 4 pins
Standard length 2m Minimum bending radium: 12mm

Diffuse Reflection, Wide-angle Polarized Reflection

Through Beam

Diffuse Reflection, Wide-angle Polarized Reflection

Through Beam

Narrow Slit:FJP-01

Model FJP-01A FJP-01B FJP-01C

A Size 0.5mm 1.0mm 2.0mm

Material
Stainless steel (SUS304)

Reflector:OR12(accessory

Reflector:OR13

Receiver Emitter

Optical axis

Receiver Emitter

Optical axis

Reflector:OR10

Narrow Slit:FJP-02

Model FJP-02A FJP-02B FJP-02C

A Size 0.5mm 1.0mm 2.0mm

Material
Stainless steel (SUS304)

Reflector:OR15

Reflector:OR14

Mounting Bracket:ZJP-8(accessory

Button instruction
1.Press the button for the duration time “t”, if t<2s or t8s, the setting is invalid, NO/NC maintains in the original state, and the product distance maintains the original;
2.Put the product in face to the sensing object, and press the button for the duration “t”, if 2s t < 5s, the yellow and green lights flash synchronously at 4 Hz, when the button is released to finish distance setting. as shown in the following figure

t=2…5s

GREEN

YELLOW

Note: For distancing setting, if the distance between the sensing object and the sensor exceeds the detection ability of the product, in duration 2s t < 5s, the yellow and green lights flash synchronously at 4Hz, when the button is released to finish the distance setting but not successfully. If the yellow and green lights flash asynchronously at 8 Hz, meaning that the product distance setting fails, and the product distance is automatically set to the maximum value, as shown in the following figure:

t=2…5s

GREEN

YELLOW GREEN

Mounting
Screw Maximum torque: 0.5N·m

Flash synchronously at 4Hz

Flash asynchronously at 8Hz

3.Press the button for the duration “t”, if 5st<8s, the yellow and green lights flash synchronously at 2 Hz, when the button is released to finish NO/NC state switchover .

t=5…8s

GREEN

YELLOW

Flash synchronously at 2Hz

Mounting bracket(accessory ZJP-8
