F32T8-TL935-ALTO TG 30PK Tuff Guard High CRI Lamps
Product Information:
The Tuff Guard High CRI T8 Lamps are a part of the lighting
product family. These lamps are designed to help protect your
customers, employees, and reputation by providing high-quality
lighting.
Product Version: LPPR1 F-T8-ADV G13 GB
Dimensional Drawing:
- Length (C): 1,213.6 mm
- Diameter (D): 27.9 mm
Light Technical Information:
- Beam Angle: 0 degree(s)
- Lamp Current (Nom): 265 mA
- Voltage (Nom): 137 V
- Bulb Finish: Coated glass
- Bulb Shape: T-8 (T8)
- Mercury (Hg) Content (Nom): 1.7 mg
- Cap-Base: G13
Product Usage Instructions:
- Ensure the power source is turned off before installing or
replacing the Tuff Guard High CRI T8 Lamp. - Remove the existing lamp by gently twisting it counterclockwise
and pulling it out of the socket. - Insert the new Tuff Guard High CRI T8 Lamp into the socket and
twist it clockwise until it is securely in place. - Turn on the power source to activate the lamp.
- The lamp provides high-quality lighting with a beam angle of 0
degrees and a color temperature of 4100 Kelvin. - If a different color temperature is desired, refer to the order
codes provided to select the appropriate product. - For optimal performance and safety, do not exceed the specified
lamp current and voltage ratings. - Dispose of used lamps properly according to local regulations
to minimize environmental impact.
For more information and updates, please visit www.lighting.philips.com
Date of Product Family Leaflet: 2023, April 15
Data subject to change
Lighting
Help protect your customers, employees,and reputation
Tuff Guard High CRI T8 Lamps
Tuff Guard T8 lamps are designed to contain shattered glass particles in case of accidental breakage. Coated lighting is essential to help ensure the welfare of your customers, employees, and operation. Benefits · Reduced impact on the environment without sacrificing performance · ALTO II means 50% less mercury than the original ALTO T8 lamps · High Color Rendering Indez Features · 95% lumen maintenance and reduced lamp-end blackening · 90 color rendering index · Only 1.7mg of mercury with ALTO II technology · Protective coating may reduce initial lumens by 5-7% Application · Industry · Food & Retail
Product family leaflet, 2023, April 15
data subject to change
Tuff Guard High CRI T8 Lamps
Warnings and Safety · The lamps must be installed and operating in ambient temperatures below 120°F. · The lamps cannot be used in fixtures employing defective ballasts, ballasts that have been used longer than their rated life or
ballasts that are improperly wired. · The lamps cannot be used in fixtures where poor pin contact occurs. · Lamp types and ballast types must be compatible (rapid start lamps with rapid start ballast, etc.). · Lamps are recommended for open fixtures.
Versions
LPPR1 F-T8-ADV G13 GB
Dimensional drawing
D
Product F32T8/TL935/ALTO TG 30PK F32T8/TL941/ALTO TG 30PK F32T8/TL950/ALTO TG 30PK F32T8/TL965/ALTO TG 30PK
C (max) 1,213.6 mm 1,213.6 mm 1,213.6 mm 1,213.6 mm
D (max) 27.9 mm 27.9 mm 27.9 mm 27.9 mm
C
Product family leaflet, 2023, April 15
2
data subject to change
Tuff Guard High CRI T8 Lamps
Light Technical Beam Angle (Nom)
Operating and Electrical Lamp Current (Nom) Voltage (Nom)
Mechanical and Housing Bulb Finish Bulb Shape
Approval and Application Mercury (Hg) Content (Nom)
General Information Cap-Base
0 degree(s)
265 mA 137 V
Coated glass T-8 (T8)
1.7 mg
G13
Light Technical
Order Code Full Product Name 927871203913 F32T8/TL941/ALTO TG
30PK 927871204905 F32T8/TL935/ALTO TG
30PK
Correlated Color
Color Designation Temperature (Nom)
4100 Kelvin
4100 K
–
3500 K
Order Code Full Product Name 927871205506 F32T8/TL950/ALTO TG
30PK 927871205708 F32T8/TL965/ALTO TG
30PK
Correlated Color
Color Designation Temperature (Nom)
5000 Kelvin
5000 K
6500 Kelvin
6500 K
© 2023 Signify Holding All rights reserved. Signify does not give any representation or warranty as to the accuracy or completeness of the information included herein and shall not be liable for any action in reliance thereon. The information presented in this document is not intended as any commercial offer and does not form part of any quotation or contract, unless otherwise agreed by Signify. All trademarks are owned by Signify Holding or their respective owners.
www.lighting.philips.com 2023, April 15 – data subject to change
