Owner’s Manual
Gigabit Fiber to Ethernet
Media Converters with PoE
Models (North America): N785-P01-LC-MM1,
N785-P01-SC-MM1, N785-P01-SC-MM2,
N785-P01-SC-SM1, N785-P01-SFP
Models (International): N785-INT-PLCMM1,
N785-INT-PSCMM2, N785-INT-PSFP

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.

PROTECT YOUR INVESTMENT!

Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—
a $100 value!
tripplite.com/warranty

http://www.tripplite.com/warranty

Package Includes

• N785-P01-Series or N785-INT-Series Media Converter
• External Power Supply with NEMA 1-15P Power Cord (100-240V), (N785-P01-Series only)
• External Power Supply with AU, EU, UK and US Power Cables (N785-INT-Series Only)

Product Features

All Models:

• Convert your fiber network to a copper network with the addition of power
• Supports 10/100/1000 Mbps speeds
• Supports up to 100 m (328 ft.) over Cat5e/Cat6 cable to your PoEcompliant device
• IEEE 802.3af Power over Ethernet (PoE) and IEEE 802.3at compliant
• Auto identification of MDI/MDI-X
• Supports full-duplex and half-duplex modes.
• LED indicators to monitor Ethernet and Fiber link status
• Link Fault Pass-Through (LFP) allows network personnel to quickly identify faults

Accessories

All Models:

• N001-Series Cat5e Snagless Patch Cables
• N201-Series Cat6 Snagless Patch Cables

N785-P01-SFP and N785-INT-PSFP Models Only:

• N286-01GSX-MDLC SFP to LC Multimode Transceiver (850 nm / 550 m)
• N286-01GLX-SLX SFP to LC Singlemode Transceiver (1310 nm / 10 km)

Installation

Notes:

• To avoid Electrostatic Discharge (ESD) damage, it is recommended you handle the product while wearing an ESD wrist grounding strap, or touch a conductive surface (such as metal) to discharge any potential ESD prior to handling the product.
• Before installation, verify your fiber equipment’s wavelength (850 nm or 1310 nm) and model type (Single or Multi) matches that of the N785-P01-Series or N785-INT-Series Media Converter.

1. Ensure all equipment in the installation is powered off.
2. (N785-P01-SFP and N785-INT-PSFP Models Only): Install a user-supplied SFP transceiver that matches your fiber equipment’s credentials.
   Note: Your fiber equipment’s wavelength and mode type must match that of the N785-P01-Series or N785-INT-Series Media Converter.
3. Using existing fiber cable from your network infrastructure, connect the media converter to your fiber network.
4. With a user-supplied Cat5e/Cat6 cable (up to 100 m / 328 ft.), connect your IEEE 802.3 af/at PoE-compliant device to the media converter’s 10/100/1000Base-T UTP port.
   Note: If your PoE-compliant device is farther than 100 m (328 ft.) away, moving DIP switch 3 (10M) to the ON position allows you to run an additional 230 m (750 ft.) of Cat5e/6 cable (up to 330 m / 1082 ft. away in total) at 10 Mbps speeds only.
5. Connect the included power supply to the media converter.
6. Turn on power to all equipment in the installation.

DIP Switch Settings

Note: DIP switches 2 and 4 have no function.
DIP Switch 1 – Link Fault Pass-Through (LFP)
To enable the LFP function, move DIP switch 1 to the ON position.

Link Fault Pass-Through (LFP)
LFP provides constant monitoring of the links connected to the media converter. If either the copper or fiber link fails, the media converter will pass the fail state through both links (copper and fiber), preventing the connected equipment from transmitting packets that would otherwise end up lost.
The LFP function includes both the LLCF (Link Loss Carry Forward) and LLF (Link Loss Return) functions. LLCF and LLR functions can immediately alarm network administrators to the problem of the link media and provide an efficient solution to monitor the network.
Link Loss Carry Forward (LLCF)
LLC occurs when a device is connected to the converter and the TP (copper) line of the media converter loses the link, resulting in the media converter’s fiber disconnecting from the transmission link.
Link Loss Return (LLR)
LLR occurs when a device is connected to the converter and the FP (fiber) line loses the link, resulting in the media converter’s fiber disconnecting from the transmission link.

DIP Switch 3 – 10M
With DIP switch 3 In the ON position, the supported transfer distance of the RJ45 port changes to 330 m (1082 ft.), and the data transfer rate changes to 10 Mbps. This allows you to extend beyond the 100 m (328 ft.) limit while running at lower speeds. When in this mode, speeds of 100 and 1000 Mbps are not supported.

LED Functions
