LDTS 160/0.5 Electric Under Floor Heating
It’s like Walking on Sunshine
Owner’s Manual
Key Features Include:
- Luxurious comfort
- Single end connection for easy install
- Can be controlled by ATC HS500
Digital Thermostat or the
Nexum RF Thermostat - Maintenance free
- Miniseries dust & air movement
Experience Luxurious comfort – electric under floor heating is an efficient and economical addition or alternative to standard heating systems. Suited to residential and hospitality settings such as bathrooms and kitchens.
For Tiled Floors Only
The ATC range of electric underfloor heating mats should be installed by an electrician or installer who has knowledge of underfloor heating installations. The heating mats can only be installed under tiles. It is recommended that the mat is laid on an insulation board such as the F-Board. This will speed up heating time and also ensure that 97% of the heat output is upwards. Heating mats are primarily used for direct heat installations.
Product Features
- Heating load is 160 w/m 2
- Mat sizes from 0.5 M 2 through to 16.3 M 2
- Mats can be joined together at the thermostat
- Optional Digital thermostat available for simple and accurate control
- Minimizes dust and air movement
- Must be installed on F-Board insulation board for most efficient heat output
Warranty
- 10 year Warranty on cable mats*
* With return of completed warranty document or else 12 month warranty.
Table of Heating Mat Sizes
| Code 160 W/M 2 | Output W | Width M | Area M 2 |
| LDTS 160/ 0.5 | 80 | 0.5 | 0.5 |
| LDTS 160/ 1 | 160 | 0.5 | 1 |
| LDTS 160/ 1.5 | 240 | 0.5 | 1.5 |
| LDTS 160/ 2 | 320 | 0.5 | 2 |
| LDTS 160/ 2.5 | 400 | 0.5 | 2.5 |
| LDTS 160/ 3 | 480 | 0.5 | 3 |
| LDTS 160/ 3.5 | 560 | 0.5 | 3.5 |
| LDTS 160/ 4 | 640 | 0.5 | 4 |
| LDTS 160/ 5 | 800 | 0.5 | 5 |
| LDTS 160/ 6 | 960 | 0.5 | 6 |
| LDTS160/ 7 | 1120 | 0.5 | 7 |
| LDTS160/ 8 | 1280 | 0.5 | 8 |
| LDTS160/ 10 | 1600 | 0.5 | 10 |
| LDTS160/ 11 | 1760 | 0.5 | 11 |
| LDTS160/ 12 | 1920 | 0.5 | 12 |
| LDTS160/ 13.3 | 2150 | 0.5 | 13.3 |
| LDTS160/ 16.3 | 2600 | 0.5 | 16.3 |
Technical Details
| Model | ATC Eco floor Underfloor Heating |
| Product Code | LDTS160/XX |
| Heat Cable Colour | Orange |
| Connection Cable Colour | Black |
| Electrical Specifications | |
| Voltage (Volts) | 230-240 Vac 1Ø |
| Frequency (Hertz) | 50 |
| Power (Watts) | 160w/M ² |
| Product Specifications | |
| Mat Width (M) | 0.5 |
| Heating type | Direct |
| Complete with floor probe | No |
| Connection Cable length (M) | 3 |
