Rocstor Y10g007-b1 Truereach Usb Type-c To Hdmi Extender User Manual

Transmitter:

• USB Type-C signal input: Connect with the source device.
• RJ45 signal output: Connect with CAT6/6A/7 network.

Receiver:

• HDMI signal output: Connect with the display device.
• RJ45 signal input: Connect with CAT6/6A/7 network.
• Power input: Connect to the USB port with the Micro USB cable.
  In case of unstable transmission, connect the Micro USB cable to
  the DC5V power adapter.

1. How to make a network cable, follow the standard of IEEE-568B:
   1-white and orange, 2-orange, 3-white and green, 4-blue, 5-white
   and blue, 6-green, 7-white and brown, 8-brown.
2. Connection:

• Connect the signal sources through the Type-C port of the
  transmitter.
• Connect the displays via the HDMI port of the receiver.
• Connect the transmitter and receiver using CAT6/6A/7 network
  cable.
• Power on the receiver by connecting it with the Micro USB
  cable.

Q: No image is displayed when the signal source is a
smartphone?

A:

• When the output mode of the signal source is Phone Mode or
  Screen Mirror Mode and the display device supports 4K@120/144Hz,
  make sure the network cable is less than or equal to 30
  meters.
• If the length of the network cable is more than 30 meters,
  please set the output mode of the signal source to Desktop Mode or
  Samsung Dex.

Q: How do I fix black screen or screen flickering?

A:

• It is recommended to replace the network cable with better
  quality or reduce the length of the network cable.
• If it still doesn’t work, try to reduce the output resolution
  of the signal source.

Q: There is no output on the screen when all connections are
correct?

A:

• Check whether the network cable meets the requirements and
  complies with the IEEE-568B standard.
• Check whether the RX power cable is firmly connected.
• Check whether the signal source has a signal output.
• Check whether the display device is set to the correct
  input.

H22047AH1 : 0106010022015
:157g 90x124mm

® TrueReach
USB®Type-C to HDMITM EXTENDER
4K/60Hz
User Manual Y10G007-B1

Important Safety Instructions:
1. Do not mix up the transmitter and the receiver before installation. 2. Keep the installation environment dry and ventilated.
Introduction
Rocstor TrueReach features a Type-C transmitter and an HDMI receiver. This product achieves zero latency transmission via CAT6/6A/7 network cable of UHD audio and video signals. It supports 4K@60Hz Type-C video signal transmission up to 197 ft (60 m) and 98 ft (30m) for 4K@120/144Hz. A variety of applications can be achieved with this kit, such as education, training, conferences, etc.
Features
· Zero latency transmission · Support up to 4K@60/120/144Hz resolution, backward compatible · Compatible with Cat6/6A/7network cable, transmission distance up to 197 ft (60 m) for 4K@60Hz signal and 30 meters for 4K@120/144Hz signal · Supports HDR10 · Supports EDID pass-through and auto downscaling · Supports Type-C input and HDMI output · The transmitter can take power from the source signal device through the Type-C port · Compact design, plug and play

Package Contents

Transmitter x1

Receiver x1

Micro USB cable x1

User manual x1

Installation Requirements
1. USB Type-C source device like smartphone, tablet, PC, etc. with Type-C port.
2. HDMI display device like TV, projector, LED screen, etc. with HDMI port. 3. UTP/STP CAT6/6A/7 cable, follow standard IEEE-568B.

Panel Description
Transmitter

1

2

1 USB Type-C signal input Connect with the source device

2 RJ45 signal output

Connect with CAT6/6A/7 network

CAT6 CAT6

Panel Description

1

2

3

1 HDMI signal output 2 RJ45 signal input
3 Power input

Connect with the display device
Connect with CAT6/6A/7 network
Connect to the USB port with the Micro USB cable. In case of unstable transmission, connect the Micro USB cable to the DC5V power adapter

2

3

4

Installation and Connection
1. How to make a network cable, follow the standard of IEEE-568B: 1-white and orange 2-orange 3-white and green 4-blue 5-white and blue 6-green 7-white and brown 8-brown

2. Connection

Macbook

Transmitter

CAT6 60m

Receiver

HDMI Display

3. Connection instruction
1) Signal sources are connected through the Type-C port of the transmitter, and displays are connected via the HDMI port of the receiver.
2) The transmitter and receiver are connected by CAT6/6A/7 network cable. 3) Using the micro USB cable to power on the receiver, the product is ready to use.

5

Q&A
QNo image is displayed when the signal source is a smartphone? A 1) When the output mode of the signal source is Phone Mode or Screen Mirror Mode
and the display device supports 4K@120/144Hz, make sure the network cable is less than or equal to 30 meters. 2) If the length of the network cable is more than 30 meters, please set the output mode of the signal source to Desktop Mode or Samsung Dex.
QHow do I fix black screen or screen flickering? A 1) It is recommended to replace the network cable with better quality or reduce the
length of the network cable. 2) If it still doesn’t work, try to reduce the output resolution of the signal source.
QThere is no output on screen when all connections are correct? A 1) Check whether the network cable meets the requirements and complies with the
IEEE-568B standard. 2) Check whether the RX power cable is firmly connected. 3) Check whether the signal source has a signal output. 4) Check whether the display device is set to the correct input.
Disclaimer
©2023 Rocstroge, Inc. Rocstor is registered trademark of Rocstorage, Inc. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. The product name and brand name may be registered trademark of related manufactures. TM and ® may be omitted on the user manual. The pictures in this user manual are just for reference We reserve the rights to make changes without further notice to a product or system described herein to improve reliability, function or design.
6

Specification

Items Compatibility
HDMI performance
Transmission distance Audio formats HDR10 HDMI 3D EDID passthrough Operating environment
Physical properties

Voltage
Power consumption HDMI version HDCP version Max transmission rate

Specifications TX: Power by the signal source RX: DC 5V500mA TX < 3W, RX < 3W HDMI 2.0 HDCP 2.2, HDCP 1.4
18Gbps

Resolution

1280×720, 1280×960, 1366×768, 1440×900, 1680×1050, 1920×1080, 1920×1200, 720p@50/60Hz, 1080i@50/60Hz, 1080p@24/25/30/50/60/120/144Hz, 3840×2160@24/25/30/50/60/120/144Hz, 4096×2160@24/25/30/50/60/120/144Hz

TMDS signal

0.7~1.2Vp-p (TMDS)

DDC signal

5Vp-p (TTL)

CAT6/6A/7

4K@60Hz 60m 4K@120/144Hz 30m

PCM, DTS, Dolby

Supported

Supported

Supported, auto downscaling

Working temperature

-20~55

Storage temperature -30~60

Humidity

0~90%RH (no condensation)

Material

ABS

Color

Black

Dimension

71.5 (L) x 26.0 (W) x 15.0 (H) mm

Weight

TX: 17g RX: 17.5g

7

ESD protection

1a Contact discharge level 2 (±4KV) 1b Air discharge level 3 (±8KV) Implementation of the standard: IEC61000-4-2
