TTSCW-DCS-159 PCPD: Wall Sections

Product Information

The TTSCW-DCS-159 PCPD is a set of wall sections that are
designed for assembly. These wall sections are made from bendy
wood, which is specifically designed to curve around a designed
frame. The product comes with a series of icons that are used
throughout the instructions to assist with assembly. It is
important to note that some parts or their placement may be
optional, and the process order or specific parts used may
vary.

Product Usage Instructions

1. Before starting the assembly, carefully read through the entire
   set of instructions to familiarize yourself with the process.
2. Do not use glue during the assembly process.
3. For each wall section, carefully score and fold the indicated
   parts according to the instructions.
4. Some parts or their placement may be optional. Refer to the
   instructions to determine if a specific part is required.
5. Pay close attention to each step and ensure that the process
   order or specific parts used are followed as indicated.
6. If instructed, repeat the process of making a specific part for
   the specified number of times.
7. At certain points in the instructions, you may need to assemble
   the same part from a different angle. Follow the instructions
   carefully to ensure correct assembly.
8. Once a sub-assembly is complete, it is ready to be added to the
   main kit.
9. Once all the assembly steps are completed, check if there are
   any additional optional parts that need to be added according to
   the instructions.
10. Handle the wall sections with care as they may be fragile. Do
    not bend them unless it is required to fit around a designed
    frame.

TTSCW-DCS-159 PCPD: Wall Sections
1

TTSCW-DCS-159 PCPD: Wall Sections
These are a series of icons that may be used throughout the instructions to help your assembly. If in doubt, scroll ahead to confirm.

Do not glue

Carefully score and fold

This part or its placement is completely optional

Look closely at this step. The process order or part
used, may be specific

Repeat making this
part for the specified numberof times

The next instruction step will be the same
assembly but from
a different angle

Sub-assembly complete. This smaller construction
is ready to aidd to the main kit
2

Assembly Complete! There may be more optional parts so check
to the very end of the instructions

FRAGILE: DO NOT BEND. “Bendy wood” is designed
to curve around a designed frame only.

TTSCW-DCS-159 PCPD: Wall Sections
3
