True Fine Td10042w 13 Inch 2-light Wall Sconce Instruction Manual (+ PDF)

WARNING: Before beginning assembly of the
product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is
missing or damaged, do not attempt to assemble the product.

Estimated Assembly Times: 25 minutes

Tools Required for Assembly (not included):

Flathead screwdriver
Phillips screwdriver
Pliers
Electrical tape
Wire cutters
Safety glasses

Helpful Tools (not included):

Wire strippers
Step ladder

Customer Service: [email protected]

Assembly Instructions

Install the shade (B) to the fixture body (A) and fix it with
screws (C).
Attach the mounting plate (DD) to the outlet box (not included)
with the long mounting screws (CC).
Strip 3/4 in. of insulation from wire ends. Twist stripped ends
together with pliers (not included), black to black (power) and
white to white (neutral). Attach copper wire to ground wire.
Helpful hint: If necessary, attach copper ground wire to grounded
outlet box.
Attach wire nuts (BB). Tape wire nuts (BB) and wires
together.
Place fixture (A) onto the mounting plate (DD). Secure with
short mounting screws (AA).
Install the bulbs (not included), use two E26 bulbs.

View Fullscreen

Wall Sconce

Instruction Manual

HARDWARE CONTENTS(shown actual size)

ABA

BBB

CBC

DBD

Print in china

PACKAGE CONTENTS

PART A Fixture B Shade C Screw

DESCRIPTION

C
B
A
QUANTITY 1 1 2

Short monting x 2 screw

Wire nut x 3

Long monting x 2 screw

Mounting plate (Not actual size) x 1

SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the product.

WARNING
· TURN OFF ELECTRICITY at main fuse box (or circuit breaker box) before beginning installation by removing fuse (or switching off circuit breaker). · MINIMUM 90°C SUPPLY CONDUCTORS.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Assembly Times: 25 minnutes Tools Required for Assembly (not included): Flathead screwdriver , Phillips screwdriver, Pliers, Electrical tape, Wire cutters, Safety glasses. Helpful Tools (not included): Wire strippers, Step ladder.
Customer Service: [email protected]

ASSEMBLY INSTRUCTIONS
1. Install the shade (B) to the fixture body (A) 1 and fix it with screws (C).

2. Attach the mounting plate (DD) to the

outlet box (not included) with the long

mounting screws (CC).

Hardware Used

CC Long mounting screw

x 2

DD Mounting plate

x 1

3. Strip 3/4 in. of insulation from wire ends. 3 Twist stripped ends together with pliers (not included), black to black (power) and white to white (neutral). Attach copper wire to ground wire. Helpful hint: If necessary, attach copper ground wire to grounded outlet box.

C B A
DD CC

ASSEMBLY INSTRUCTIONS

4. Attach wire nuts (BB).Tape wire nuts (BB) 4 and wires together.
Hardware Used

BB Wire nut

5. Place fixeture (A) onto the mounting

plate (DD). Secure with short mounting

screws (AA).

Hardware Used

AA Short mounting screw

x 2

DD Mounting plate

x 1
AA
