Product Information: TTCombat & Vallejo Paint Rack 36

The TTCombat & Vallejo Paint Rack 36 is a product designed
to assist with the organization and storage of paint bottles used
in miniature painting. The rack can hold up to 36 paint bottles and
is compatible with Vallejo brand paints. The product comes with
optional feet stands that can provide extra support, but glue is
still recommended for added stability.

Product Usage Instructions:

1. Begin by unpacking all the components of the product from its
packaging.

2. Match the positioning of the highlighted parts as shown in
the instruction manual.

3. Optional: Attach the feet stands to the bottom of the rack by
twisting them into place. Glue is recommended for added
stability.

4. Carefully score and fold each part of the rack according to
the instruction manual.

5. Assemble the rack by following the step-by-step instructions
in the manual, making sure to repeat any steps as indicated.

6. Once assembly is complete, check the end of the instruction
manual for any additional optional parts that may be included.

TTSCW-HBA-044 TTCombat & Vallejo
Paint Rack 36

TTSCW-HBA-044 TTCombat & Vallejo
Paint Rack 36
2
These are a series of icons that may be used throughout the instructions to help your assembly:

Do not glue this part

Carefully score and fold this part

This part – or its placement is completely optional

Look closely at this step – its process order or part
used may be specific

Repeat making this part the specified number of times

The next instruction step will be the same assembly so far, but from a different
angle

Sub-assembly complete. This smaller construction
is ready to aidd to the main kit

Assembly Complete! There could be more optional
parts – check to the very end of instructions
