SD125 Communicating Grade 2 Standard Duty Cylindrical Lock

Product Information

The SD Series Grade 2 Standard Duty Cylindrical Lock is a
product that is designed for commercial use. The lock is ADA
compliant and suitable for various types of doors. It comes with an
antimicrobial coating technology that inhibits the growth of
microbes, providing additional hygiene benefits. The lock is
available in different finishes, including Bright Brass, Oil Rubbed
Bronze, Satin Nickel, Flat Black, and Satin Chromium. It also has
several functions, levers, and accessories that can be customized
according to the user’s needs.

Specifications

Backset: Adjustable 2-3/8″ to 2-3/4″
Chassis: Steel, zinc dichromate finish for corrosion
resistance
Front: Wrought brass or stainless steel, 2-1/4″ x 1-1/8″
beveled
Strike: Wrought brass or stainless steel, ANSI curved lip,
4-7/8″ x 1-1/4″ x 1-1/4″ lip to center standard
Levers: Zinc die-cast, plated to match finish symbols
Rose: Wrought brass or stainless steel, 3-1/2″ diameter
Latchbolt: Stainless steel with 1/2″ throw
Hand: Non-handed
Trim: Levers are reversible without disassembling the lock
Keys: Two nickel silver standard
Keyways: Schlage “C” keyway standard
Interchangeable core: Standard Schlage “C” keyway 6 or 7-pin
length
Cylinder: Brass, 6-pin, keyed-random, C keyway, 2 keys per
lock
Keying: Available in keyed different (KD), keyed alike (KA), or
master keyed (MK) options
Certifications, listings, compliances: UL Listed for use on
fire doors (F-rated), UL Listed to Canadian Safety Standards
Warranty: Limited lifetime mechanical warranty

Product Usage Instructions

The SD Series Grade 2 Standard Duty Cylindrical Lock can be
installed on various types of doors. The lock is non-handed, which
means it can be used on both left and right-handed doors without
any modifications. Before installation, ensure that the door is
properly aligned with the frame and that the lock’s backset matches
the door’s thickness.

To install the lock:

Remove the old lock and prepare the door according to the
manufacturer’s instructions.
Install the latchbolt in the door edge and secure it with
screws.
Insert the chassis into the door hole and align it with the
latchbolt.
Secure the chassis with screws.
Install the levers, rose, and strike plate according to the
manufacturer’s instructions.
Test the lock for proper operation before use.

To rekey the lock:

Remove the cylinder from the lock.
Remove the old pins from the cylinder and replace them with new
ones according to the new key’s specifications.
Reinsert the cylinder into the lock and test it with the new
key.

For more information on the lock’s functions, levers, finishes,
and accessories, refer to the product manual or contact the
manufacturer’s customer service department.

View Fullscreen

SD
Series

Grade 2 Standard Duty Cylindrical Lock
Architectural Submittal Sheet

Typical Applications
· Assisted Living · Hospitality · Houses of Worship · Industrial · Medium/Light Commercial Installations · Multi-family · Offices · Retail

Specifications

ADA COMPLIANT

FOR DOORS:
APPLICATION:
BACKSET: CHASSIS:
FRONT: STRIKE: LEVERS:
ROSE: LATCHBOLT:
HAND: TRIM: KEYS: KEYWAYS: INTERCHANGEABLE CORE: CYLINDER:
KEYING:
FINISHES:
CERTIFICATIONS, LISTINGS,
COMPLIANCES:
WARRANTY:

· 1-3/8″ to 1-3/4″ thick · Preset for 1-3/4″ door
· Through door thru-bolting · Fits standard 160 and 161 Door prep · Thru-Bolts are removable
· 2-3/4″ standard · 2-3/8,” 3-3/4,” 5″ optional · Heavy-gauge cold rolled steel mechanism · Dichromated for corrosion resistance · 2-1/4″ x 1-1/8″ or 2-1/4″ x 1″ · Beveled 1/8″ on 2″ · Stainless Steel or Wrought Brass · ASA standard · T-Strike or Full Lip Strike optional · Stainless Steel or Wrought Brass · Philadelphia, Boston, Miami, Memphis, Orlando · 3-3/8″ DIA Wrought · 1/2″ Throw · Non-handed (Except Memphis) · Solid diecast PHL, BSN, MIA, MEM and ORL Levers · Wrought Brass Roses · Concealed Screws · Two (2) per Lock · SCC standard (Schlage C Compatible) · Also available in keyways of other manufacturers
· 6 or 7-pin · Compatible with Best, Falcon & Arrow. Not available with Memphis lever.
· 6-pin Brass Insert Cylinder keyed to 5-pins · Standard High Security and UL437 Cylinders Available · Options: MK, CMK or GMK / Zero Bitted (KO), Keyed Different (KD) or Keyed Alike (KA) · Can be keyed into existing master key systems · 605 (US3), 613 (US10B), 622 (19D), 626 (US26D) · UL listed for 3 hrs, for single doors up to 4’0″ x 8’0″ · Certified to ANSI/BHMA A156.2 Grade 2 · Complies with ADA (Americans with Disabilities Act) and ICC/ANSI 117.1 for Accessible and Usable Buildings · TAA compliant. Country of origin: KR · Five (5) year Limited Warranty

Available with antimicrobial coating, technology that is known to inhibit the growth of microbes.

www.pdqlocks.com

SD Series

PDQFunctions

FUNCTION

FUNCTION NUMBER

OUTSIDE | INSIDE

DESCRIPTION

Communicating

SD125

NONKEYED
· Latchbolt operated by inside lever · Blank plate outside · Minimum clearance of 1-1/2″ between doors · Deadlocking (guarded) latchbolt

ANSI NUMBER
—

Passage
Privacy Bedroom Bathroom

SD126 SD176

Storeroom

SD115

Entrance

SD116

Classroom

SD148

· Latchbolt operated by lever from either side at all times

F75

· Latchbolt operated by lever from either side or emergency release in outside lever

· Outside lever locked by push button on inside · Outside lever unlocked by emergency release from outside, rotating inside lever, or

F76

closing door

KEYED

· Latchbolt operated from outside by key, inside by lever

· Outside lever always fixed

F86

· Inside lever always free

· Deadlocking (guarded) latchbolt

· Latchbolt operated by lever from either side or key in outside lever · Outside lever locked by push/turn button on inside · When outside lever is locked by push button on inside key from outside,
or rotating inside lever unlocks outside lever · When outside lever is locked by pushing and turning the button on the inside,
key from outside or rotating inside lever retracts latch but does not unlock outside lever · Deadlocking (guarded) latchbolt

F109

· Latchbolt operated by lever from either side

· Outside lever locked or unlocked by key from outside

F84

· Inside lever always operates latch

· Deadlocking (guarded) latchbolt

Entry

SD182

Single Dummy

SD211

· Latchbolt operated by lever from either side or key in outside lever

· Outside lever locked by push button on inside
