MultiVac 310-MS-T Vacuum Filtration System
Product Information
The Laboratory Filtration / Filtration System is a vacuum
filtration system designed for large number of samples. It includes
the MultiVac 310 / 610 – MS – T, an aluminum-made manifold that is
light, cost-effective, and autoclavable. The manifold can be easily
removed for cleaning and autoclaving. The system also comes with a
magnetic filter holder that allows for one-handed operation and
prevents the membrane from being twisted or torn. It features a
4000 mL PP vacuum bottle with drain, providing convenience for
collecting and draining liquid waste. The system is certified with
CE certification, CSA certification (Rocker 400), IP 30 protection
(Rocker 400), and RoHS certification (Rocker 400). It comes with a
two-year warranty (Rocker 400) or a two-year warranty (MultiVac 310
/ 610 – MS).
Applications
- Suspended solid test
- Microbiological test
- Vacuum filtration
Ordering Information
Model: MultiVac 310 / 610 – MS – T
Voltage: 110V (MultiVac 310 – MS – T), 220V (MultiVac 310 – MS –
T), 110V (MultiVac 610 – MS – T), 220V (MultiVac 610 – MS – T)
Max. power: 100W (MultiVac 310 – MS – T), 80W (MultiVac 310 – MS
– T), 100W (MultiVac 610 – MS – T), 80W (MultiVac 610 – MS – T)
Specification
Max. vacuum: 99 mbar abs.
Max. flow rate: 37 L/min @60Hz, 34 L/min @50Hz (MultiVac 310 –
MS – T), 37 L/min @60Hz, 34 L/min @50Hz (MultiVac 610 – MS – T)
Vacuum regulator: Yes
Overflow protection: Yes
Noise level: 52 dB
Number of branch: 3 (MultiVac 310 – MS – T), 6 (MultiVac 610 –
MS – T)
Filter holder: MF 3, 300 mL x 3 (MultiVac 310 – MS – T), MF 3,
300 mL x 6 (MultiVac 610 – MS – T)
Filter diameter: 47 mm
Material contact with filtrate: Aluminum
Product Usage Instructions
- Connect the MultiVac 310 / 610 – MS – T vacuum filtration
system to a power source with the appropriate voltage (110V or
220V). - Ensure that the MultiVac 310 / 610 – MS – T manifold is clean
and autoclaved before use. - Attach the magnetic filter holder to the manifold. This will
allow for one-handed operation and prevent the membrane from being
twisted or torn. - Place the desired filter diameter (47 mm) onto the filter
holder. - Connect the PP vacuum bottle with drain (4000 mL) to the
manifold. - Connect the silicone tube to the appropriate ports on the
manifold. - Turn on the vacuum pump (Rocker 400) to create a vacuum.
- Adjust the vacuum regulator to the desired level.
- Perform the suspended solid test, microbiological test, or
vacuum filtration as needed. - After use, clean and autoclave the manifold, filter holder, and
vacuum bottle for future use.
Laboratory Filtration / Filtration System
Vacuum Filtration System
VIDEO
Features
ffFor large number of samples MultiVac 310 / 610 – MS – T is an economical kit for filtration with large number samples.
ffLight and handy This aluminum-made manifold is light, cost-effective and autoclavable. Each component can be easily removed for cleaning and autoclaving.
ffMagnetic filter holder is included Magnetic filter holder allows for one-handed operation, and can prevent the membrane from being twisted or torn.
ff4000 mL PP vacuum bottle with drain The large capacity of 4000 mL vacuum bottle with drain offers convenience of collecting and draining liquid waste.
ffInternational certification CE certification CSA certification (Rocker 400) IP 30 protection (Rocker 400) RoHS certification (Rocker 400)
ffTwo-Year Warranty (Rocker 400) ffTwo-Year Warranty
(MultiVac 310 / 610 – MS)
MultiVac 310 – MS – T MultiVac 610 – MS – T
Applications
ffSuspended solid test ffMicrobiological test ffVacuum filtration
Ordering Information
Specification
Model Voltage Max. power
180311-11(22)-T 180611-11(22)-T MultiVac 310 / 610 – MS – T, Vacuum Filtration System, complete set includes : * Rocker 400, Oil Free Vacuum Pump * MultiVac 310 / 610 – MS, 3/6 Places
Aluminum Manifold * MF 3, Magnetic Filter Holder, 300 mL (3/6 pcs) * PP Vacuum Bottle with drain, 4000 mL * Silicone Tube (2 pcs)
Max. vacuum Max. flow rate Vacuum regulator Overflow protection Noise level OTHER DATA Number of branch Filter holder
MultiVac 310 – MS – T
MultiVac 610 – MS – T
110V
220V
110V
220V
100W
80W
100W
80W
99 mbar abs.
37 L/min @60Hz 34 L/min @50Hz 37 L/min @60Hz 34 L/min @50Hz
Yes
Yes
52 dB
3 MF 3, 300 mL x 3
6 MF 3, 300 mL x 6
Filter diameter
47 mm
47 mm
Material contact with filtrate
Aluminum
Aluminum
