V-LOCK Skimmer Lid
Product Information
The product is an outer frame and lid for a skimmer box used in
swimming pools. The kit includes V-lock adhesive, spacer plates,
and a lid key. The outer frame is available in four models: V10,
V15, V20, and V30, with varying dimensions. The lid inlay is
available separately and can be installed on stone/tile or decking
surfaces.
Kit Contents
- 1 V-LOCK Adhesive
- 2 Spacer Plate
- 3 Lid Key
Optional Accessory
An install plate (P/N: 475-209) is available separately.
Outer Frame Dimensions (in mm)
| Model | Overall Depth | Overall Width | Overall Length | Internal Lid Depth | Inlay Thickness Range | Overall Inlay Width | Overall Inlay Length |
|---|---|---|---|---|---|---|---|
| V10 | 26.0 | 342.0 | 342.0 | 12.0 | 8.0 ~ 11.0 | 322.0 | 322.0 |
| V15 | 32.0 | 342.0 | 342.0 | 18.0 | 12.0 ~ 16.0 | 322.0 | 322.0 |
| V20 | 37.0 | 342.0 | 342.0 | 23.0 | 15.0 ~ 22.0 | 322.0 | 322.0 |
| V30 | 47.0 | 342.0 | 342.0 | 33.0 | 25.0 ~ 32.0 | 322.0 | 322.0 |
Product Usage Instructions
Before installation, read the installation and care guide
carefully to avoid voiding the warranty.
Safety Precautions
Always use suitable personal protection equipment and safe work
practices when installing or servicing the product.
Installation Requirements
- The product is to be installed and serviced by a suitably
qualified professional. - The installation must meet all applicable engineering and
regulatory requirements. - Do not use acid/chemical washes as discoloration may occur and
will void the warranty. - Do not carry the lid with the key.
- Always remove the key from the lid once locked and keep it out
of reach of children. - After installation, provide the manual to the owner/operator to
store in a safe place.
Outer Frame Installation on Stone/Tile
- For new builds, allow for a mortar bed allowance (A) as
specified on page 2 of the installation guide. - For retro-fit, create a recess for the outer frame, ensuring
that any mortar that falls into the skimmer box opening is
immediately removed. - Apply mortar into the recess surrounding the skimmer box
opening, making sure to remove any excess mortar that falls into
the skimmer box. - Install the outer frame while the mortar is still wet, making
sure to leave a small clearance gap (A) and aligning the
pre-moulded mounting holes (B). - Optional: remove the install plate (P/N: 475-209) after the
compound is fully cured (B).
Outer Frame Installation on Decking
- Create a sub-frame slightly larger than the outer frame and
centered over the skimmer box opening (A). - Ensure that the outer frame is square, level, and centered on
the skimmer box opening (A). - Align the pre-moulded mounting holes (B) and attach the outer
frame to the sub-frame, leaving a small clearance gap (A). - Optional: cut boards spanning the outer frame so that a section
equal to the width of the lid is removed for a seamless
installation.
Lid Inlay Installation on Stone/Tile
- Prepare the inlay on a flat surface.
- Apply V-lock adhesive to the underside of the inlay, making
sure to maximize the adhesive bond strength (B). - Ensure that the inlay is free from dust, oil, debris, and
completely dry before continuing. - Place the lid over the inlay and press down until the lid outer
rim is touching the work surface (B). - Leave for approximately 15 minutes to allow the adhesive to
partially cure. - Remove the lid and inlay, apply more adhesive if necessary, and
reposition the inlay, making sure it is centered for consistent
grout line thickness (A). - Leave for approximately 24 hours to allow the adhesive to fully
cure.
If you have any feedback or suggestions regarding the product,
please contact [email protected].
INSTALL ATION & C ARE GUIDE
PART NO. 475-201 | 475-203 | 475-205 | 475-207
NOTE:
1. READ THIS DOCUMENT PRIOR TO INSTALLATION. IMPROPER INSTALLATION WILL VOID WARRANTY. 2. PRODUCT ONLY TO BE INSTALLED & SERVICED BY A SUITABLY QUALIFIED PROFESSIONAL. 3. DO NOT USE ACID/CHEMICAL WASHES . DISCOLORATION MAY OCCUR AND WILL VOID WARRANTY. 4. INSTALLER TO ENSURE INSTALLATION MEETS ALL APPLICABLE ENGINEERING & REGULATORY
REQUIREMENTS. 5. DO NOT CARRY LID WITH KEY. 6. ALWAYS REMOVE KEY FROM LID ONCE LOCKED. KEEP KEY OUT OF REACH OF CHILDREN. 7. THIS MANUAL CONTAINS IMPORTANT INFORMATION. ONCE INSTALLATION IS COMPLETE
INSTALLER MUST PROVIDE THIS MANUAL TO OWNER/OPERATOR TO STORE IN A SAFE PLACE.
IMPORTANT – PLEASE NOTE:
1. SEE “GENERAL USAGE” SECTION FOR INSTRUCTIONS REGARDING CORRECT OPERATION OF LID (SEE PAGE 9) 2. DO NOT CARRY LID WITH LID KEY AS THIS MAY RESULT IN INJURY OR DAMAGE 3. DO NOT USE HARSH CHEMICALS, ACIDS OR ABRASIVE MATERIALS TO CLEAN LID, OUTER FRAME OR LID KEY 4. KEEP LID KEY OUT OF REACH OF CHILDREN. LID SHOULD ONLY BE OPERATED BY A CAPABLE ADULT 5. ENSURE FINGERS & TOES ARE CLEAR OF LID WHEN LOWERING TO AVOID INJURY 6. DO NOT OPEN SKIMMER WHILE PUMP IS OPERATING 7. DO NOT LEAVE LID KEY IN LID WHEN NOT IN USE. STORE LID KEY IN A SAFE PLACE 8. FOR SMOOTH AND RELIABLE OPERATION, KEEP YOUR V-LOCK LID FREE OF DIRT, SAND, LEAF MATTER AND DEBRIS
SAFETY FIRST
PLEASE ENSURE SUITABLE PERSONAL PROTECTION EQUIPMENT AND SAFE
WORK PRACTICES ARE USED.
Ref: 475-818-03 Registered Design. Specifications subject to change without notice. AQUEA® is a registered trademark of Vantage Products Pty. Ltd.
The contents of this manual are the exclusive copyright of AQUEA® and may not be reproduced without written
© permission. 2022
Whilst every care was taken in preparation of this document, AQUEA® accepts no responsibility for the accuracy of
the information supplied.
1
KIT CONTENTS
1 V-LOCK Adhesive
2 Spacer Plate
3 Lid Key
OPTIONAL ACCESSORY
INSTALL PLATE (See page 4) (P/N: 475-209)
4 Lid
Outer Frame 5
AVAILABLE SEPARATELY
key dimensions*
OUTER FRAME
MODEL
Overall Depth Overall Width Overall Length Internal Lid Depth Inlay Thickness Range Overall Inlay Width Overall Inlay Length
V10
V15
V20
V30
26.0
32.0
37.0
47.0
342.0
342.0
12.0
18.0
23.0
33.0
8.0 ~ 11.0 12.0 ~ 16.0 15.0 ~ 22.0 25.0 ~ 32.0
322.0
322.0
* All dimensions in millimeters. Tolerance +/- 1.0mm
LID
FEEDBACK & SUGGESTIONS
We are continually looking for ways to improve and expand our product range. Please contact us at [email protected] if you have any feedback or suggestions!
2
OUTER FRAME PREPARATION – STONE/TILE
1
NEW BUILD NEW BUILD
· Check & confirm finished height of stone/tile.
· Check & confirm overall height of V-LOCK model to be installed
(See Page 2).
· Prepare a level bed slightly larger than overall size of Outer Frame including
mortar bed allowance (A).
1
RETRO-FIT RETRO-FIT
· Align & centre Outer Frame over existing skimmer box opening (A).
· Mark perimeter of Outer Frame on surrounding stone/tile (B).
2
3
RETRO-FIT
To create recess for Outer Frame:
· Carefully cut existing tile/stone to create recess for Outer Frame (A).
· Remove debris to a depth suitable for overall height of V-LOCK model to be installed (See Page 2) plus mortar bed allowance (B).
OUTER FRAME INSTALLATION – STONE/TILE
1
To lay mortar bed: · Using appropriate mortar mix, insert
mortar into recess surrounding
skimmer box opening (A).
IMMEDIATELY REMOVE ANY MORTAR THAT FALLS INTO SKIMMER BOX
2
3
P/N: 475-209
To position Outer Frame: · Place Outer Frame on mortar bed.
Mortar must fully support Outer Frame (A). · Ensure top rim of Outer Frame is flush with top face of surrounding stone/tile. · Remove any excess mortar and ensure skimmer box opening is fully accessible through Outer Frame (B).
IMMEDIATELY REMOVE ANY MORTAR THAT FALLS INTO SKIMMER BOX
**WHILE MORTAR IS WET**
To install Outer Frame:
· OPTIONAL – Insert Install Plate (P/N. 475-209) into Outer Frame with label facing upwards, and press down gently until it rests on stop ribs (A).
· Adjust as required to ensure Outer Frame is level, square and top rim is flush with surrounding surface (B).
**AFTER MORTAR HAS SET**
4
To finish Outer Frame:
· PREFERRED – Fill gap surrounding Outer Frame using a suitable expansion joint gap filler (A).
· ALTERNATE – Apply grout around Outer Frame perimeter using preferred mortar/grout compound*.
OPTIONAL – Remove Install Plate
P/N: 475-209
(P/N. 475-209) after compound is fully cured (B).
* Using rigid grout or mortar may result in gaps/cracking appearing over time due to natural expansion & contraction.
4
OUTER FRAME INSTALLATION – Decking
1
To prepare sub-frame: · Construct square opening in
sub-frame slightly larger than Outer
Frame, centred over skimmer box
opening (A).
· Fix corner gussets to sub-frame opening. Ensure gussets are recessed so top surface of Outer Frame rim is flush with finished decking level (B).
2
To install Outer Frame: · Adjust as required to ensure Outer
Frame is square, level and centred on
skimmer box opening (A).
· Attach Outer Frame to sub-frame with suitable fasteners through
pre-moulded mounting holes (B).
3
Applying decking: · Lay decking around Outer Frame
leaving a small clearance gap (A).
HINT: For a seamless installation, cut boards spanning Outer Frame so that a section equal to width of Lid is removed. These pieces can be used to create a perfectly grain-matched Lid inlay.
5
LID INLAY INSTALLATION – STONE/TILE
1
To cut inlay material to size: · Place inlay material in desired layout
on a flat surface.
· Carefully cut to correct size to suit V-LOCK Lid (A). (See Page 2)
2 3 4A
1~3mm
To mark V-notch cut-out: · Place inlay material with preferred
surface facing upwards. · Position Spacer Plate on inlay material. · Align & centre V-notch edge of Spacer
Plate with selected edge of inlay (A). · Mark V-notch cut-out profile (B).
Prepare inlay for installation: · Carefully cut and remove V-notch
material from inlay (A). · Thoroughly clean and dry inlay to
maximise adhesive bond strength (B).
ENSURE INLAY IS FREE FROM DUST, OIL , DEBRIS AND
COMPLETELY DRY BEFORE CONTINUING.
FOR INLAYS 1~3mm THINNER THAN INTERNAL LID DEPTH
To apply adhesive : · Insert V-LOCK Adhesive into caulking
gun & cut nozzle to provide a minimum 6mm wide bead. · Apply a generous, even bead across entire internal surface of Lid (A).
6
4B 5
3+ mm
FOR INLAYS MORE THAN 3 mm THINNER THAN INTERNAL LID DEPTH To apply adhesive : · Insert V-LOCK Adhesive into caulking
gun & cut nozzle to provide a minimum 6mm wide bead. · Apply a generous, even bead across entire internal surface of Lid (A). · Insert Spacer Plate into Lid (B). · Apply generous, even bead across entire top surface of Spacer Plate (C).
To install inlay material into Lid: · Place inlay material face-down on a
flat work surface. · Invert Lid and lower onto inlay material
(A) until Lid outer rim is touching work surface (B).
LEAVE FOR APPROXIMATELY 15 MINUTES TO ALLOW ADHESIVE TO
PARTIALLY CURE.
6
To position inlay material: · Carefully flip Lid over and check inlay is
centred for consistent grout line
thickness.
· If required insert tiling wedges or similar to adjust inlay to correct
position (A).
LEAVE FOR APPROXIMATELY 24 HOURS TO ALLOW ADHESIVE TO
CURE FULLY.
7
Finishing Lid: · PREFERRED – Fill gap surrounding
inlay material using an appropriate
expansion joint gap filler (A).
· ALTERNATE – Apply grout around
inlay perimeter using preferred
mortar/grout compound (B)*.
DO NOT USE HARSH CHEMICALS, ACID WASHES OR ABRASIVE MATERIALS TO CLEAN LID
7 * Using rigid grout or mortar may result in gaps/cracking appearing over time due to natural expansion & contraction.
LID INLAY INSTALLATION – Decking
1
To prepare Lid for mounting battens: · Invert Lid and select preferred
mounting points for correct batten
orientation.
· Drill holes in pre-moulded locations to suit preferred fasteners and batten
direction (A).
2
To attach battens: · Pre-cut two timber battens ensuring
batten thickness equals internal Lid
depth minus decking thickness (A).
DECKING THICKNESS
· Fasten battens into Lid using a combination of fasteners and appropriate adhesive (B).
3
To install decking inlay: · Pre-cut decking to fit Lid. Use Spacer
Plate as template for V-notch if
required (A).
· Attach decking to battens with appropriate timber fasteners (B) or adhesive.
ENSURE FASTENER LENGTH IS MINIMUM 2.0mm LESS THAN LID
INTERNAL DEPTH.
8
GENERAL USAGE
1
LOCK
TO OPEN LID
To unlock Lid:
· Insert Lid Key into lock as shown (A).
UNLOCK
· Rotate Key 90 degrees clockwise to unlock position. Lid Key is now captive
in Lid.
2
To remove Lid: · Using Lid Key as a handle lift Lid
upwards (A), then grab edges of Lid by
hands and remove from Outer Frame.
DO NOT CARRY LID WITH LID KEY.
1 2
9
TO CLOSE LID
To close Lid: · Angle and slide Lid’s rear edge
towards `double’ pocket in Outer Frame (A). · Engage hooks on rear edge of Lid into pocket and carefully lower Lid into Outer Frame (B).
LID MUST BE INSERTED IN CORRECT ORIENTATION TO LOCK.
LOCK UNLOCK
To lock Lid:
· Rotate Lid Key 90 degrees anti-clockwise to locked position, ensuring latch engages correctly in outer frame (A).
· Remove Lid Key vertically from lock and store in safe place (B).
KEEP LID KEY OUT OF REACH OF CHILDREN.
WARRANTY POLICY
AQUEA (a division of Vantage Products Pty. Ltd.) warrants that, subject to the exclusions and limitations below, its products will be free from defects in materials and workmanship for a minimum period of 12 MONTHS from the date of purchase. All warranty periods commence on the date of purchase by the customer and are only valid in original country of purchase. The provisions of this warranty are not transferable.
If a defect appears in any Product supplied by AQUEA before the end of the Warranty Period due solely to defective materials or workmanship, AQUEA will in its sole discretion, and subject to these terms and conditions, either:
a) repair the Product or the defective part of the Product free of charge; or b) have the Product or the defective part of the Product repaired by a qualified repairer free of charge; or c) replace the Product. AQUEA at its sole discretion may replace defective parts of the Products with parts and components of similar quality, grade and composition where an identical part or component is not available. Refurbished parts may be used to repair the Products.
All repairs are to be carried out by AQUEA or its authorised repairer only. This warranty does not cover any costs related to travel, removal or re-installation associated with repair or replacement of the Product.
TO MAKE A WARRANTY CLAIM
To claim under this warranty the customer should immediately cease use of the Product once alleged defect is identified, and contact AQUEA within 30 days.
To make a claim the customer must:
1. Provide the following information:
(a) proof of purchase disclosing date and place of purchase; (b) full details of the alleged defect; and (c) any other appropriate documentation. 2. The customer must make the Product or site available to AQUEA or its authorised repair agent for inspection and testing. If such inspection and testing finds no defect in the Product, the customer must pay AQUEA’s usual costs of service work and testing.
3. The customer agrees to pay AQUEA’s usual charges (including any service fee) for any goods or services provided by AQUEA not covered by this product warranty.
4. The customer is responsible for the cost of transport and all insurance of the Product to and from AQUEA or its authorised repair agent.
WARRANTY CONDITIONS
This warranty only applies where the following conditions are met:
1. The customer complies with the following general maintenance requirements:
(a) The Product is maintained free from general debris or foreign matter. (b) The Product is maintained and serviced regularly (at least every 12 months) by a suitably qualified professional. (c) Where applicable, the Product is replaced at specified intervals as outlined in product literature by AQUEA. 2. Where applicable, Product has been used in pool or spa water which:
(a) is maintained within a pH range of 7.2-7.6, and chemically balanced as per accepted industry standards. (b) is regularly (at least once a month) treated with a sanitising system in compliance with applicable regulatory recommendations or regulations. (c) has not exceeded 40 degrees Celsius in temperature. (d) has not been exposed to freezing conditions.
WARRANTY EXCLUSIONS
This warranty will not apply where:
(a) the Product has not been installed in accordance with the installation instructions provided with the Product, any statutory requirements and these terms and conditions;
(b) the Product has not been installed by a suitably qualified professional trained in the installation and operation of such products with more than 12 months industry experience;
(c) a failure to observe and comply with the instructions supplied with product for the proper use, service or maintenance of the Product has occurred;
(d) the Product has been used for a purpose other than that for which it was designed and manufactured;
(e) removal or installation of the Product has contributed to, or resulted in, the defect or damage;
(f) the Product has been repaired, altered or modified by someone other than AQUEA or its authorised agent;
(g) substitute or replacement parts not provided by AQUEA have been used;
(h) the defect has arisen due to abuse, misuse, neglect, or accident;
(i) the Product has been subject to abnormal conditions, including environment, temperature, water, fire or other acts of nature;
(j) the Product has been subject to abnormal corrosive conditions or abrasive chemicals;
(k) the defect is the result of corrosion or normal wear and tear;
(l) the defect is the result of insect and/or vermin infestation;
(m) concrete, cement, render, pebbles or other pool surface finishes contribute to the defect, or inhibit proper function of the Product;
(n) the damage occurred in transit;
(o) after testing and inspection AQUEA cannot establish any fault in the Product;
(p) the Product has been used in a commercial application;
(q) the Product has not been supplied by AQUEA;
(r) the defect is related to any cause other than a defect in the materials or workmanship of the Product.
LIMITATIONS
AQUEA makes no express warranties or representations other than set out in this warranty.
Except to the extent required by the Australian Consumer Law, the repair or replacement of the Product or part of the Product is the absolute limit of AQUEA’s liability under this express warranty.
To the extent permitted by law, AQUEA will not be liable for:
(a) Damage to any other property caused by defect in the Product.
(b) Any indirect, special or consequential loss arising from or related to defects in the Product, including, but not limited to, loss of time, loss of use of the product, loss of business opportunity, loss of profits, loss of revenue, loss of goodwill, or inconvenience.
(c) Any other damage as a result of weather or natural disaster.
(d) Any claim against the customer by other parties.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
The benefits of this warranty are in addition to any rights and remedies imposed by Australian State and Federal legislation that cannot be excluded. Nothing in this warranty is to be interpreted as excluding, restricting or modifying any State or Federal legislation applicable to the supply of goods and services which cannot be excluded, restricted or modified.
Contact
For warranty claims visit www.aquea.com.au or contact AQUEA using details overleaf.
(Policy Revision 03)
10
A Q U E A ® (a division of Vantage Products Pty. Ltd.) U11/22-24 REDLAND DRIVE, MITCHAM, VICTORIA 3132.
SALES & SUPPORT ENQUIRIES – [email protected] PHONE – 0481 875 870
