19171-8BK Chicago 8-Light Unique Traditional Chandelier
Product Information
The product is a light fixture that includes a mounting bracket,
canopy, sling chain, central pipe, crystal, twigs 1 and 2, lamp arm
1 and 2, decorative cover, crystal ball, and wire connection
diagram. The light bulb is not included, and it is rated for
110-130V/60Hz with a maximum of 60W. All glass components are
fragile and require careful handling. The wires must meet safety
standards to connect the electrical circuit.
There are warnings and cautions in the user manual that must be
followed to avoid any harm or damage. If there are any questions
about the fixture’s installation, contact a qualified electric
contractor. It is highly recommended to get an electrician to
install this light. Turn off the electricity at the main circuit
breaker before beginning installation. California residents should
be aware that this product contains lead, which can cause cancer
and birth defects or other reproductive harm. Do not place the
product in your mouth, and wash your hands after handling this
product.
Product Usage Instructions
- Unscrew the cover and connect the wires. Make sure to turn off
the power supply before installation. - Fix the lamp arm first, connect the black wire to the positive
(+) of the main wire L, and connect the white wire to the negative
(-) of the main wire L. - Screw together the parts included in steps 3-8.
- If any special control devices are used with this fixture,
follow the instructions carefully to assure full compliance with
N.E.C.requirements. If there are any questions, contact a qualified
electric contractor. - For video instruction, search MX19171-8BK-P on
Youtube.com. - Share your experience by leaving a short product review on the
platform where you bought this product. - If you have any questions or problems, send an email to
[email protected] or call 469-312-6428.
Assembly & Installation Instructions
Dear Customer:
Thank you for your business!
Step 7
If you have any questions or problems, please send us
an email to [email protected] or call us at
469-312-6428. We will do everything possible to make
you completely satisfied with your purchase.
For video instruction, please search
” MX19171-8BK-P “on Youtube.com
Product reviews help future customers to make their
purchase decision. You are encouraged to share your
A
experience by leaving a short product review on the
Step 6
B
platform where you bought this product.
Screw together
Thank you!
Zgear Team
Step 5
Screw together
Step 4
Screw together
Warning: If any special control devices are used
with this fixture, follow the instructions carefully to assure full compliance with N.E.C.requirements. If there are any questions, contact a qualified electric contractor.
Warning: California Residents Proposition 65
This product contains lead, a chemical known to the state of California to cause cancer and birth defects or other reproductive harm. Do not place the product in your mouth. Wash your hands after handling this product.
Caution: It is highly recommended to get an
electrician to install this light. Please make sure to turn the electricity off at the main circuit breaker before beginning installation. All glass is fragile.Use care when handling glass component(s)and/or lamp(s).
Step 3
Fix the lamp arm first, connect the black wire to the positive (+) of the main wire L, and connect the white wire to the negative (-) of the main wire L.
Step 2
Step 8 J Put the nails through K first and bend them
Step 1
Unscrew the cover, connect the wires, and then tighten
Light Bulb (Not included)
( Rated 110-130V/60Hz, bulb 60W maximum.)
E12
WIRE CONNECTION DIAGRAM
Wires meeting safety standards are required to connect the electrical circuit.
CAUTION: Risk of fire
L N
Please read all instructions carefully. Before you proceed to install, make sure that the power supply is turned off and remains off until installation is completed.
PARTS INCLUDED
Code
A
Part Description
Mounting Bracket
B
Canopy
C
Sling Chain
D
Central Pipe
E
Crystal
F
Twigs 1
G
Iamp Arm 1
H
Iamp Arm 2
I
Twigs 2
J
Decorative Cover
K
Crystal Ball
QTY
1 1 1 1 155 8 3 3 8 1 1
