HDP-EHB100V3K HDBaseT 3.0 Extender
Product Information:
Product Name: HDBaseT 3.0 Extender with
eARC/ARC (100m)
Version: 1.1
Features:
- HDMI 2.0b, HDCP 2.2 and HDBaseT 3.0 compliant
- Uncompressed 4K@60Hz 4:4:4 up to 18Gbps video bandwidth
- HDR, HDR10, HDR10+, Dolby Vision and HLG pass through
- LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX,
DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD pass through - Transmission distance up to 328ft/100 meters via a single CAT
6A/7 cable - Supports eARC/ARC function
- Supports SPDIF audio reverse transmission
- Bi-directional IR, RS-232 and 1G Ethernet signal pass
through - Supports USB2.0 transmission, Host/Device is configurable
- Bi-directional 24V POC function
Package Contents:
- 1 x HDBaseT 3.0 Extender (Transmitter)
- 1 x HDBaseT 3.0 Extender (Receiver)
- 1 x IR Blaster Cable (1.5 meters)
- 1 x IR Receiver Cable (1.5 meters)
- 2 x 3pin-3.81mm Phoenix Connectors
- 4 x Mounting Ears
- 8 x Machine Screws (KM3*4)
- 1 x 24V/1A Locking Power Supply
- 1x User Manual
Specifications:
Technical:
- HDMI Compliance: HDMI 2.0b
- HDCP Compliance: HDCP 2.2
- Video Bandwidth: 18Gbps
- Video Resolution: Up to 4K@60Hz 4:4:4
- HDBaseT Bandwidth HDR: 16Gbps on main and 2Gbps on return
link - Color Space: RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
- Color Depth: 8/10/12-bit
- Audio Formats: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS,
DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD - L/R Audio Formats: PCM 2.0
- SPDIF Audio Formats: LPCM2.0, AC3 5.1, DTS 5.1
- IR Level: 12Vp-p
- IR Bandwidth: 20K – 60KHz
- USB Bandwidth: Up to 350Mbps
- Ethernet: 1000Mbps
- RS-232 Transmission Distance: Up to 921600bps
- ESD Protection
Connection:
Transmitter:
- Input: 1 x HDMI IN [Type A, 19-pin female]
- Output: 1 x HDMI OUT [Type A, 19-pin female]
- Output: 1 x HDBT OUT [RJ45, 8-pin female]
- Output: 1 x SPDIF OUT [S/PDIF]
- Output: 1 x L/R OUT [3.5mm Stereo Mini-jack]
- Control: 1 x IR IN [3.5mm Stereo Mini-jack]
- Control: 1 x IR OUT [3.5mm Stereo Mini-jack]
- Control: 1 x RS-232 [3pin-3.81mm Phoenix jack]
- Control: 1 x SERVICE [Mini-USB, Update port]
- Control: 1 x USB HOST [USB Type B]
- Control: 2 x USB DEVICES [USB Type A]
- Control: 1 x LAN [RJ45]
Receiver:
- Input: 1 x HDBT IN [RJ45, 8-pin female]
- Input: 1 x SPDIF IN [S/PDIF]
- Output: 1 x HDMI OUT [Type A, 19-pin female]
- Output: 1 x L/R OUT [3.5mm Stereo Mini-jack]
- Control: 1 x IR IN [3.5mm Stereo Mini-jack]
- Control: 1 x IR OUT [3.5mm Stereo Mini-jack]
- Control: 1 x RS-232 [3pin-3.81mm Phoenix jack]
- Control: 1 x SERVICE [Mini-USB, Update port]
- Control: 1 x USB HOST [USB Type B]
- Control: 2 x USB DEVICES [USB Type A]
- Control: 1 x LAN [RJ45]
HDBaseT 3.0 Extender with eARC/ARC (100m)
VER 1.1
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment.
Table of Contents
1. Introduction………………………………………………………………………………..1 2. Features……………………………………………………………………………………..1 3. Package Contents…………………………………………………………………….. 1 4. Specifications……………………………………………………………………………. 2 5. Operation Controls and Functions……………………………………………… 4
5.1 Transmitter Panel………………………………………………………………….. 4 5.2 Receiver Panel…………………………………………………………………….. 6 5.3 Input & Output Switching………………………………………………………. 7 5.4 Audio Embedding and De-embedding………………………………… 9 5.5 USB Mode Applications………………………………………………………… 10 5.6 IR Pin Definition…………………………………………………………………….. 11 6. Application Example…………………………………………………………………. 12
1. Introduction
This HDBaseT 3.0 Extender can extend uncompressed HD/UHD video and audio signals, eARC/ARC, RS-232, bi-directional IR, 1GbE Ethernet and USB2.0 signals up to 100m/328ft via a single CAT6A/7 cable. The Transmitter supports audio embedding or de-embedding. The Receiver supports audio de-embedding. It also supports eARC/ARC from RX’s HDMI output pass through to TX’s HDMI input or de-embedding to TX’s HDMI audio only and SPDIF output ports, USB 2.0 (Host/Device is configurable) and bi-directional POC. The Extender offers the most convenient solution for HDMI extension via a single CAT cable with long distance capability, and is the perfect solution for home/commercial application.
2. Features
HDMI 2.0b, HDCP 2.2 and HDBaseT 3.0 compliant Uncompressed 4K@60Hz 4:4:4 up to 18Gbps video bandwidth HDR, HDR10, HDR10+, Dolby Vision and HLG pass through LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24,
DTS High Res, DTS-HD Master Audio, DSD pass through Transmission distance up to 328ft/100 meters via a single CAT 6A/7 cable Supports eARC/ARC function (the audio is returned to the HDMI IN port,
HDMI OUT (AUDIO ONLY) port and SPDIF OUT port of the transmitter.) Supports SPDIF audio reverse transmission Bi-directional IR, RS-232 and 1G Ethernet signal pass through Supports USB2.0 transmission, Host/Device is configurable Bi-directional 24V POC function
3. Package Contents
1 x HDBaseT 3.0 Extender (Transmitter) 1 x HDBaseT 3.0 Extender (Receiver) 1 x IR Blaster Cable (1.5 meters) 1 x IR Receiver Cable (1.5 meters) 2 x 3pin-3.81mm Phoenix Connectors 4 x Mounting Ears 8 x Machine Screws (KM3*4) 1 x 24V/1A Locking Power Supply 1x User Manual
1 / 12
4. Specifications
Technical
HDMI Compliance HDMI 2.0b
HDCP Compliance HDCP 2.2 Video Bandwidth 18Gbps
Video Resolution Up to 4K@60Hz 4:4:4
HDBaseT Bandwidth HDR
16Gbps on main and 2Gbps on return link HDR, HDR10, HDR10+, Dolby Vision, HLG
Color Space
RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
Color Depth
8/10/12-bit
Audio Formats
LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
L/R Audio Formats PCM 2.0
SPDIF Audio Formats LPCM2.0, AC3 5.1, DTS 5.1
IR Level
12Vp-p
IR Bandwidth
20K – 60KHz
USB Bandwidth Ethernet RS-232 Transmission Distance ESD Protection Connection
Transmitter
Up to 350Mbps
1000Mbps
Up to 921600bps
100m (via a single CAT 6A/7 cable)
Human body model — ±8kV (Air-gap discharge) & ±4kV (Contact discharge)
Input: 1 x HDMI IN [Type A, 19-pin female] Output: 1 x HDMI OUT [Type A, 19-pin female]
1 x HDBT OUT [RJ45, 8-pin female] 1 x SPDIF OUT [S/PDIF] 1 x L/R OUT [3.5mm Stereo Mini-jack] Control: 1 x IR IN [3.5mm Stereo Mini-jack] 1 x IR OUT [3.5mm Stereo Mini-jack] 1 x RS-232 [3pin-3.81mm Phoenix jack] 1 x SERVICE [Mini-USB, Update port] 1 x USB HOST [USB Type B] 2 x USB DEVICES [USB Type A] 1 x LAN [RJ45]
2 / 12
Receiver
Input: 1 x HDBT IN [RJ45, 8-pin female] 1 x SPDIF IN [S/PDIF] Output: 1 x HDMI OUT [Type A, 19-pin female] 1 x L/R OUT [3.5mm Stereo Mini-jack] Control: 1 x IR IN [3.5mm Stereo Mini-jack] 1 x IR OUT [3.5mm Stereo Mini-jack] 1 x RS-232 [3pin-3.81mm Phoenix jack] 1 x SERVICE [Mini-USB, Update port] 1 x USB HOST [USB Type B] 2 x USB DEVICES [USB Type A] 1 x LAN [RJ45]
Mechanical Housing Color Dimensions Weight
Metal Enclosure Black Transmitter / Receiver: 170mm [W] x 102mm [D] x 22mm [H] Transmitter: 425g, Receiver: 437g
Power Supply
Input: AC 100 – 240V 50/60Hz Output: DC 24V/1A (US/EU standard, CE/FCC/UL certified)
Power Consumption 15.36W (POC)
Operating Temperature
32 – 104°F / 0 – 40°C
Storage Temperature -4 – 140°F / -20 – 60°C
Relative Humidity 20 – 90% RH (no condensation)
Resolution / Cable Length
4K60 Feet / Meters
4K30 Feet / Meters
1080P60 Feet / Meters
HDMI IN / OUT
16ft / 5M
32ft / 10M
50ft / 15M
The use of “Premium High Speed HDMI” cable is highly recommended.
3 / 12
5. Operation Controls and Functions
5.1 Transmitter Panel
POWER LINK VIDEO ARC SPDIF SELECT
LOOPOUT / HOST / IN/OUT AUDIO ONLY DEVICE
HDMI OUT
USB
1
2
USB DEVICES
SERVICE USB HOST
1 2345 6 7 8 9
10
11 12
HDMI IN
HDMI OUT
SPDIF OUT
IR IN IR OUT TX RX
DC 24V
HDBT OUT
(eARC/ARC)
RS-232
13
14 16 15 17 18
19 20 21 22 23 24
No. Name
Function Description
1 Power LED Red LED indicates that the Transmitter is powered on.
2 LINK LED
Light on: Transmitter and Receiver are in good connection status. Light flashing: Transmitter and Receiver are in Low Power Mode. Light off: Transmitter and Receiver are not connected.
Light on: The video is encrypted.
3 VIDEO LED Light flashing: The video is not encrypted. Light off: No HDMI input.
4 ARC LED
Light on: The device is switched to the ARC mode. Light off: The device is switched to the SPDIF mode.
5
SPDIF LED
Light on: The device is switched to the SPDIF mode. Light off: The device is switched to the ARC mode.
6
SELECT button
Used for switching the ARC mode and SPDIF mode.
7
L/R IN/OUT switch
Switch to left, the L/R IN/OUT port is the audio embedding port; Switch to right, the L/R IN/OUT port is the audio de-embedding port.
Switch to left (LOOPOUT), the HDMI OUT port is the loopout port
LOOP OUT/ for the HDMI IN port;
8 AUDIO ONLY Switch to right (AUDIO ONLY), the HDMI OUT port outputs 720P
switch
black screen image, and the audio is from ARC or SPDIF.
4 / 12
9
HOST/
Switch to left (HOST), the USB HOST mode is enabled;
DEVICE USB Switch to right (DEVICE), the USB DEVICE mode is enabled.
switch
USB 10 DEVICES
Two USB device ports, connected to U disk, mouse or keyboard.
11 USB HOST USB extension host port, connected to PC.
12 SERVICE Firmware update port.
13 DC 24V
DC 24V/1A power supply input port. Note that the extender supports POC function, it means that either transmitter or receiver is powered on by 24V/1A power adapter, the other one doesn’t need power supply.
14 LAN 15 HDBT OUT
1G Network port. When it switches to Gigabit Ethernet, the green indicator lights on; When it switches to 100M Ethernet, the yellow indicator lights on.
10G Network port, connected to the HDBT IN port of Receiver with a CAT 6A/7 cable. It is used for various signals pass-through.
Data Signal 16 Indicator
(Yellow)
Illuminating: HDMI signal with HDCP. Flashing: HDMI signal without HDCP. Dark: No HDMI signal.
Link Signal 17 Indicator
(Green)
18 HDMI IN
Illuminating: Transmitter and Receiver are in good connection status.
Flashing: Transmitter and Receiver are in poor connection status. Dark: Transmitter and Receiver are not connected.
HDMI signal input port, connected to signal source device, supporting eARC/ARC amplifier.
19 HDMI OUT
HDMI signal loopout port. It can choose to be a LOOP OUT or AUDIO ONLY port through the LOOP OUT/AUDIO ONLY switch.
20 L/R IN/OUT
Audio embedding/de-embedding port. It can be used for audio embedding/de-embedding through the L/R IN/OUT switch.
21 SPDIF OUT Optical output port.
22 IR IN
IR signal input port, connected to IR Receiver cable.
23 IR OUT
IR signal output port, connected to IR Blaster cable.
24 RS-232
RS-232 serial port, used for serial port command transmission.
5 / 12
5.2 Receiver Panel
POWER LINK VIDEO ARC SPDIF SELECT
1 2345 6
DEVICE / HOST
USB
1
2
USB DEVICES
SERVICE USB HOST
7
HDMI OUT
8
9 10
SPDIF IN
IR IN IR OUT TX RX
DC 24V
HDBT IN
(eARC/ARC)
RS-232
11
12 14 13 15
16 17 18 19 20 21
No. Name
Function Description
1 Power LED Red LED indicates that the Receiver is powered on.
2 LINK LED
Light on: Transmitter and Receiver are in good connection status. Light flashing: Transmitter and Receiver are in Low Power Mode. Light off: Transmitter and Receiver are not connected.
Light on: The video is encrypted. 3 VIDEO LED Light flashing: The video is not encrypted.
Light off: No HDMI input.
4 ARC LED
Light on: The device is switched to the ARC mode. Light off: The device is switched to the SPDIF mode.
5
SPDIF LED
Light on: The device is switched to the SPDIF mode. Light off: The device is switched to the ARC mode.
6
SELECT button
Used for switching the ARC mode and SPDIF mode.
DEVICE/ 7 HOST USB
switch
Switch to right (HOST), the USB HOST mode is enabled; Switch to left (DEVICE), the USB DEVICE mode is enabled.
8
USB DEVICES
Two USB device ports, connected to U disk, mouse or keyboard.
9 USB HOST USB extension host port, connected to PC.
10 SERVICE Firmware update port.
11 DC 24V
DC 24V/1A power supply input port. Note that the extender supports POC function, it means that either transmitter or receiver is powered on by 24V/1A power adapter, the other one doesn’t need power supply.
6 / 12
12 LAN
1G Network port. When it switches to Gigabit Ethernet, the green indicator lights on; When it switches to 100M Ethernet, the yellow indicator lights on.
13 HDBT IN
Data Signal 14 Indicator
(Yellow) Link Signal 15 Indicator (Green)
10G Network port, connected to the HDBT OUT port of Transmitter with a CAT 6A/7 cable. It is used for various signals pass-through.
Illuminating: HDMI signal with HDCP. Flashing: HDMI signal without HDCP. Dark: No HDMI signal.
Illuminating: Transmitter and Receiver are in good connection status. Flashing: Transmitter and Receiver are in poor connection status. Dark: Transmitter and Receiver are not connected.
16 HDMI OUT HDMI signal output port, supporting eARC/ARC TV.
17 L/R OUT 18 SPDIF IN 19 IR IN
Audio de-embedding output port. Optical input port. IR signal input port, connected to IR Receiver cable.
20 IR OUT
IR signal output port, connected to IR Blaster cable.
21 RS-232
RS-232 serial port, used for serial port command transmission.
5.3 Input & Output Switching
The Extender can switch to ARC/SPDIF mode by pressing the SELECT button on the front panel of both transmitter and receiver. The HDMI OUT port of the transmitter can turn to LOOP OUT or AUDIO ONLY through the LOOP OUT/AUDIO ONLY switch. The input and output routing are different for different scenarios, as shown in the diagrams below:
Scene 1: Set the Extender to SPDIF Mode. Then switch the LOOP OUT/ AUDIO ONLY switch to right, the HDMI OUT port of the transmitter is set to AUDIO ONLY.
DVD
HDMI IN ARC
AUDIO ONLY
UTP Cable
HDMI OUT
Audio Amplifier SPDIF OUT
SPDIF IN TV
Speakers
7 / 12
Scene 2: Set the Extender to SPDIF Mode. Then switch the LOOP OUT/ AUDIO ONLY switch to left, the HDMI OUT port of the transmitter is set to LOOP OUT.
DVD
HDMI IN ARC
LOOP OUT
UTP Cable
HDMI OUT
SPDIF OUT TV
SPDIF IN TV
Audio Amplifier
Scene 3: Set the Extender to ARC Mode. Then switch the LOOP OUT/ AUDIO ONLY switch to right, the HDMI OUT port of the transmitter is set to AUDIO ONLY.
Soundbar with ARC
HDMI IN ARC
AUDIO ONLY
Audio Amplifier SPDIF OUT
UTP Cable
HDMI OUT ARC
TV with ARC
Speakers
Scene 4: Set the Extender to ARC Mode. Then switch the LOOP OUT/ AUDIO ONLY switch to left, the HDMI OUT port of the transmitter is set to LOOP OUT.
Soundbar with ARC
HDMI IN ARC
SPDIF OUT
UTP Cable
HDMI OUT ARC
Audio Amplifier
TV with ARC
8 / 12
Scene 5: Set the Extender to eARC Mode. Then switch the LOOP OUT/ AUDIO ONLY switch to right, the HDMI OUT port of the transmitter is set to AUDIO ONLY.
Soundbar with eARC HDMI IN eARC
AUDIO ONLY
UTP Cable
HDMI OUT eARC
Audio Amplifier
SPDIF OUT 5.1CH
TV with eARC
Speakers
Scene 6: Set the Extender to eARC Mode. Then switch the LOOP OUT/ AUDIO ONLY switch to left, the HDMI OUT port of the transmitter is set to LOOP OUT.
Soundbar with eARC
HDMI IN eARC
SPDIF OUT 5.1CH
UTP Cable
HDMI OUT eARC
TV with eARC
Audio Amplifier
Note: In eARC mode, the SPDIF OUT port can only output the audio up to 5.1CH.
5.4 Audio Embedding and De-embedding
The Transmitter supports audio embedding and de-embedding. The L/R IN/OUT port can be used for audio embedding or de-embedding through the L/R IN/OUT switch.
9 / 12
TX Audio Embedding When the L/R IN/OUT switch is switched to left, the audio from external audio device will be embedded to the L/R IN/OUT port.
DVD
HDMI IN
MP3 Player
L/R IN
UTP Cable
HDMI OUT
TV
TX Audio De-embedding When the L/R IN/OUT switch is switched to right, The L/R IN/OUT port will output the audio de-embedded from the HDMI IN port.
DVD
HDMI IN
L/R OUT
UTP Cable
HDMI OUT
Audio Amplifier TV
5.5 USB Mode Applications
The Extender supports USB2.0 transmission, and Host/Device is configurable.
Mode 1: USB forward from TX to RX Switch the HOST/DEVICE USB switch to left, then power off and reboot the transmitter to set to USB Host mode. Meanwhile, switch the DEVICE/HOST USB switch to left, then power off and reboot the receiver to set to USB Device mode.
Computer Host
HDMI IN USB Host LOOPOUT
USB / Host
USB / Device USB Host No Function
UTP Cable
HDMI OUT
Local Monitor &
Keyboard Mouse
USB Devices
10 / 12
USB Devices Remote Monitor &
Keyboard Mouse
Mode 2: USB reverse from RX to TX Switch the HOST/DEVICE USB switch to right, then power off and reboot the transmitter to set to USB Device mode. Meanwhile, switch the DEVICE/HOST USB switch to right, then power off and reboot the receiver to set to USB Host mode.
NoteBook No Function
HDMI IN USB Host LOOPOUT
USB / Device
USB / Host USB Host
UTP Cable
HDMI OUT
Computer Host
Local Monitor &
Keyboard Mouse
USB Devices
USB Devices
Remote Monitor &
Keyboard Mouse
5.6 IR Pin Definition IR Receiver and Blaster pin’s definition as below:
IR BLASTER
IR RECEIVER
IR BLASTER + –
IR RECEIVER
Power 12V
Note: When the angle between the IR receiver and the remote control is ± 45 °, the transmission distance is 0-5 meters; when the angle between the IR receiver and the remote control is ± 90 °, the transmission distance is 0-8 meters.
11 / 12
6. Application Example
Transmitter
POWER LINK VIDEO ARC SPDIF SELECT
LOOPOUT / HOST / IN/OUT AUDIO ONLY DEVICE
HDMI OUT
USB
HDMI IN
HDMI OUT
1
2
USB DEVICES
SERVICE USB HOST
SPDIF OUT
IR IN IR OUT TX RX
DC 24V LAN
HDBT OUT LAN
(eARC/ARC)
RS-232
PC1
Power Supply
TP-LINK
Router
PC2
TV or Amplifier DVD or Blu-ray
Player or Amplifier
IR Blaster
IR Receiver
HDMI Matrix with RS-232 function
CAT 6A/7 cable
Audio Amplifier
Speakers
IR Blaster
PC3
TV with eARC/ ARC function
IR Receiver
LAN
LAN
DC 24V
Receiver
HDBT IN
POWER LINK VIDEO ARC SPDIF SELECT
HDMI OUT (eARC/ARC)
SPDIF IN
IR IN IR OUT TX RX
RS-232
DEVICE / HOST
USB
1
2
USB DEVICES
SERVICE USB HOST
Mouse
Keyboard
The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
12 / 12
