Nvent Elcn124v Connector Female Instruction Manual

ELCN124V Connector Female

Product Information

The product is a set of Steckverbinder 24 V DC connectors, which
are designed to provide a secure and reliable connection for
devices operating at 24 volts DC. The connectors are manufactured
by nVent and have the model number ELCN124V. The product is
suitable for a voltage range of 3.5 to 6.6 volts.

The manufacturer’s address is nVent, located at 2100 Hoffman
Way, Anoka, MN 55303-1745. For more information about the company
and its products, please visit their website at www.nvent.com. The product has a unique
identification number of 89183936.

Product Usage Instructions

1. Ensure that the power source is disconnected before attempting
   to connect the Steckverbinder 24 V DC connectors.
2. Identify the positive (+) and negative (-) terminals on the
   devices that need to be connected.
3. Insert the positive (+) terminal of one device into the
   corresponding positive (+) terminal of the Steckverbinder
   connector.
4. Insert the negative (-) terminal of the same device into the
   corresponding negative (-) terminal of the Steckverbinder
   connector.
5. Repeat steps 3 and 4 for the remaining devices that need to be
   connected.
6. Once all the devices are connected, ensure that the connections
   are secure and properly aligned.
7. Reconnect the power source and test the functionality of the
   connected devices.

Note: If any issues arise during the connection process or while
using the product, refer to the troubleshooting section of the user
manual or contact nVent customer support for assistance.

Steckverbinder 24 V DC Connectors 24 V DC Connecteurs 24 V DC Conectores 24 V DC

Art.-Nr.: ELCN124V

3,5 – 6,6

1. Adern einlegen, Kontaktschrauben anziehen Insert wires, tighten contact screws Insérer les fils, serrer les vis de contact Inserte los cables, apriete los tornillos de contacto

2. Zugentlastung anbringen Attach strain relief Fixer un dispositif de soulagement des contraintes Fijar el alivio de tensión

nVent 2100 Hoffman Way Anoka, MN 55303-1745

www.nvent.com

© 2020 nVent

89183936

3. Zugentlastungsschrauben anziehen Tighten strain relief screws Serrer les vis de décharge de traction Apriete los tornillos de alivio de tensión

4. Entriegelung der Steckverbinder Unlocking the connectors Déverrouillage des connecteurs Desbloquear los conectores
