T16BR-TX ARC Sports Bar
Product Information:
I-SHEET PART NUMBER: INST-00272
PART NUMBER: T16BR-TX
PRODUCT: SPORT BAR
APPLICATION: 16-21 TACOMA
HARDWARE: HWKT-11806X
- 3/8X1 CARRIAGE BOLT – 4 pieces
- 3/8 FLANGED NUT – 4 pieces
- M8-1.25 X 25MM CLASS 8.8 HEX SERRATED FLANGE – 4 pieces
- M8 CHANNEL NUT – 4 pieces
PARTS INCLUDED:
- CENTER LIGHT MOUNT ASSEMBLY – 1 piece
- DRIVER SIDE ASSEMBLY – 1 piece
- PASSENGER SIDE ASSEMBLY – 1 piece
Product Usage Instructions:
- Began by removing the end caps from each end of the bed rail
near the tailgate and set aside. NOTE: The end caps will be
re-installed later in the install. - Assemble the supplied M8 bolts and threaded channel nuts (x4).
NOTE: Do not show exposed threads past nut. KEEP
FLUSH - Install one bolt and nut assembly in each bed rail by sliding
through the channel opening until it makes contact with the end cap
on the opposite end. - Next, slide the two remaining bolt and nut assemblies halfway
through the channel. - Attach the Center section to the driver and passenger side
assemblies using the supplied 3/8 x 1 carriage bolt (x4) and 3/8
flanged nut (x4) and leave finger tight for now. NOTE: Begin
with the upper bolt and nut first to have easier access to the
lower fasteners. - With an associate on each side, carefully walk the Style Bar
back towards the cab. Begin lowering down evenly on both sides to
avoid contact with bed rail. Place into position, aligning the
Style Bar with the bulkhead. - Next, fully tighten the carriage bolts in the center
section. - Slide the four bolt and nut assemblies through the open slots
in the Style Bar until contact is made and hand tighten. - Tighten all four mounting positions to 16 ft/lbs (+/- 2lbs).
Follow torque sequence in (Fig. 4-1) - Finish by re-installing bed rail end caps removed in Step 1.
Periodically check all fasteners for tightness.
I-SHEET PART NUMBER: INST-00272 PART NUMBER: T16BR-TX PRODUCT: SPORT BAR APPLICATION: 16-21 TACOMA
HARDWARE: HWKT-11806X
3/8″X1″ CARRIAGE BOLT
4
3/8″ FLANGED NUT
4
M8-1.25 X 25MM CLASS 8.8 HEX SERRATED FLANGE
4
M8 CHANNEL NUT
4
PARTS INCLUDED
QTY
CENTER LIGHT MOUNT ASSEMBLY
1
DRIVER SIDE ASSEMBLY
1
PASSENGER SIDE ASSEMBLY
1
Step 1. Began by removing the end caps from each end of the bed rail near the tailgate and set aside. NOTE: The end caps will be re-installed later in the install.
12302 Shiloh Church Rd. Houston TX 77066 Phone (281) 880-6322 – Fax (281) 880-6325
Step 2. Assemble the supplied M8 bolts and threaded channel nuts (x4).
NOTE: Do not show exposed threads past nut.
KEEP FLUSH Step 3. Install one bolt and nut assembly in each bed rail by sliding through the channel opening until it makes contact with the end cap on the opposite end.
Step 4. Next, slide the two remaining bolt and nut assemblies half way through the channel.
I-SHEET PART NUMBER: INST-00272 PART NUMBER: T16BR-TX PRODUCT: SPORT BAR APPLICATION: 16-21 TACOMA
Step 5. Attach the Center section to the driver and passenger side assemblies using the supplied 3/8″ x 1″ carriage bolt (x4) and 3/8″ fanged nut (x4) and leave finger tight for now. *NOTE: Begin with the upper bolt and nut first to have easier access to the lower fasteners. *
Step 6. With an associate on each side, carefully walk the Style Bar back towards the cab. Began lowering down evenly on both sides to avoid contact with bed rail. Place into position, aligning the Style Bar with the bulk head.
Align
12302 Shiloh Church Rd. Houston TX 77066 Phone (281) 880-6322 – Fax (281) 880-6325
Step 7: Next, fully tighten the carriage bolts in the center section.
Step 8. Slide the four bolt and nut assemblies through the open slots in the Style Bar until contact made and hand tighten.
Step 9. Tighten all four mounting positions to 16 ft/lbs (+/- 2lbs). *** Follow torque sequence in ( Fig. 4-1 ) ***
Step 10. Finish by re-installing bed rail end caps removed in Step 1. ** Periodical check all fasteners for tightness. **
