11 200 5805 Sport-Thieme Rolling Bar Slide System
Product Information: Sport-Thieme Rolling Bar Slide System
The Sport-Thieme Rolling Bar Slide System is a climbing
equipment that consists of a high platform (prod. code: 11 201
7411) and a universal platform (prod. code: 11 201 7424). The high
platform has holes on the sides for climbing and can be used with
Sport-Thieme rolling bar slides with product codes: 11 200 5805
(2.0 m), 11 200 5818 (2.5 m), and 11 200 5821 (3.0m). The universal
platform is the ideal addition to the Sport-Thieme low platform
(prod. code: 11 201 7408) and the Sport-Thieme high platform (prod.
code: 11 201 7411), suitable as a starting platform for the rolling
bar slides (prod. code: 11 200 5805, 11 200 5818, 11 200 5821) and
the roller board track (prod. code: 11 201 5402).
The high platform comes with two rungs for attaching the rolling
bar slide on opposite sides. The platforms are designed to be
screwed together, and there are endless ways to combine the
alternating high and lower platforms. Please note that there is no
guarantee for the combination with products from other
manufacturers.
Product Usage Instructions
High Platform Assembly Instructions
- When you open the package, ensure all necessary parts are
included:- 2x side with rung for attaching rolling bar slide, with
climbing holes - 2x front and back with large hole
- 2x ng for attaching rolling bar slide
- 1x cover 645 x 660 mm connector for two podiums
- Hexnut M8 hex bolt 8×60 plastic spacer washer
- 1x hex key 5 mm
- 2x side with rung for attaching rolling bar slide, with
- Follow the exploded view drawing (illustration 2) and put the
parts a to d together for assembly, screw together using the
included hex key and sleeve nuts (see illustration 2 and 3). - Insert the rungs into the respective recesses and screw using
spax screws 5 x 50. Caution: To prevent rung c from bursting,
please pre-drill the ends in the center!
Universal Platform Assembly Instructions
- When you open the package, ensure all necessary parts are
included:- side, right and left
- front and back
- cover
- 1 x rung + 2x spax screws 5 x 30
- 1x hex key 5 mm
- set of screws: 24x hanger bolt (pre-assembled) and sleeve nut
M6
- The Sport-Thieme `Universal’ platform has the following
dimensions: 73 cm x 66 cm x approx. 82 cm (WxHxD). Follow the
exploded view drawing (illustration 5) and put the parts a to f
together for assembly, screw together using the included hex key
and sleeve nuts (see illustration 5).
Safety and Maintenance
Before each use, carry out a visual inspection of the high
platform. The high platform is only suitable for its intended use.
Improper use voids the warranty.
Operating/assembly instructions
Sport-Thieme rolling bar slide system
Prod. code 11 200 5805 11 200 5818 11 200 5821 11 201 5402 11 201 7408 11 201 7411 11 201 7424 11 262 1409
1221208 · © 2021 Sport-Thieme GmbH
D-38367 Grasleben · Germany sport-thieme.com · info @sport-thieme.com Phone: +49 53 57 181 543 · Fax: +49 53 57 181 921
Operating/assembly instructions
1. Sport-Thieme high platform (prod. code: 11 201 7411)
Abb. 1: high platform, assembled
High platform
d
c
Operating/assembly instructions
Abb. 2: exploded view drawing, high platform
c
High platform
d
b
a
1.1 When you open the package, please ensure all the necessary parts are included: a 2x side with rung for attaching rolling bar slide, with climbing holes b 2x front and back with large hole c 2x ng for attaching rolling bar slide d 1x cover 645 x 660 mm connector for two podiums Hexnut M8 hex bolt 8×60 plastic spacer washer 1x hex key 5 mm
1.2 General The high platform is an exciting piece of climbing equipment. There are holes in the sides for climbing the platform.
The high platform is suitable for Sport-Thieme rolling bar slides with product codes: 11 200 5805 (2.0 m), 11 200 5818 (2.5 m) and 11 200 5821 (3.0m).
The high platform can be used as free-standing platform, together with further Sport-Thieme platforms or with Sport-Thieme rolling bar slides.
There is no guarantee for the combination with products from other manufacturers. The high platform comes with 2 rungs for attaching the rolling bar slide on opposite sides. It is up to you whether you want to attach a rolling bar slide on the left, on the right or on both sides.
There are endless ways to combine the alternating high and lower platforms. The platforms are designed to be screwed together (see low platform).
2
sport-thieme.com · [email protected]
b a
1.3 Assembly instructions Illustration 2 shows an exploded view drawing of the platform elements in assembly position.
Follow ill. 2 and put the parts a to d together for assembly, screw together using the included hex key and sleeve nuts (see ill. 2 and 3).
The rungs are inserted into the respective recesses and screwed using spax screws 5 x 50. Caution: To prevent rung c from bursting, please pre-drill the ends in the centre!
1.4 Safety
· Only use the high platform under supervision. · Place fall protection mats around the platform to prevent injuries! · The platform is not fixed to the floor. · Improper use can lead to a risk of tipping over! · The maximum load is 1.5 kN (150 kg).
Abb. 3: screw connection
1.5 Maintenance and inspection
A visual inspection must be carried out before each use. The high platform is only suitable for its intended use. Improper use voids the warranty.
3
Operating/assembly instructions
`Universal’ platform
2. Sport-Thieme `Universal’ platform (prod. code: 11 201 7424)
Abb. 4: view of Sport-Thieme `Universal’ platform, assembled
c
Countersunk holes on top
d e
Operating/assembly instructions
Abb. 5: Eexploded view drawing, `universal’ platform
sleeve nut M6
`Universal’ platform
c d
a
b
2.1 When you open the package, please ensure all the necessary parts are included: a side, right and left b front and back c cover d 1 x rung + 2x spax screws 5 x 30 e 1x hex key 5 mm f set of screws: 24x hanger bolt (pre-assembled) and sleeve nut M6
2.2 General The Sport-Thieme `Universal’ platform is the ideal addition to the Sport-Thieme low platform (prod. code: 11 201 7408) and the Sport-Thieme high platform (prod. code: 11 201 7411). It is suitable as a starting platform for the rolling bar slides (prod. code: 11 200 5805, 11 200 5818, 11 200 5821) and the roller board track (prod. code: 11 201 5402). The Sport-Thieme `Universal’ platform has the following dimensions: 73 cm x 66 cm x approx. 82 cm (WxHxD).
The `Universal’ platform can be used as free-standing platform, together with further Sport-Thieme platforms or with Sport-Thieme rolling bar slides.
4
sport-thieme.com · [email protected]
hanger bolts M6 x 25 mm
b
a
2.3 Assembly instructions Illustration 5 shows an exploded view drawing of the platform elements in assembly position.
Follow ill. 5 and put the parts a to d together for assembly, screw together using the included hex key and sleeve nuts (see ill. 5 and 6).
The rungs are inserted into the respective recesses and screwed using spax screws 5 x 30. Caution: To prevent rung c from bursting, please pre-drill the ends in the centre!
2.4 Safety
· Only use the high platform under supervision. · Place fall protection mats around the platform to prevent injuries! · The platform is not fixed to the floor. · Improper use can lead to a risk of tipping! · The maximum load is 1.5 kN (150 kg).
Abb. 6: screw connection
2.5 Maintenance and inspection
A visual inspection must be carried out before each use. The `Universal’ platform is only suitable for its intended use. Improper use voids the warranty.
5
Operating/assembly instructions
3. Sport-Thieme low platform (prod. code: 11 201 7408)
Abb. 7: view of low platform, assembled
c
Low platform
Operating/assembly instructions
Abb. 8: exploded view drawing, low platform
c
Low platform
b
a
3.1 When you open the package, please ensure all the necessary parts are included:
a 2x side with step
b 2x front and back with climbing holes
c 1x cover, large 645 x 733 mm
Caution: Countersunk holes for roller board track at the top!
20x sleeve nut M6
20x hanger bolt (pre-assembled)
} 4x hex bolt 8 x 60
4x hex nut M8 4x plastic spacer
Connecting materials platform/platform
8x washer 8
1x hex key 5 mm
3.2 General The low platform is an exciting piece of climbing equipment. There are holes (steps) in the sides for climbing the platform.
It is designed to be an attachment point for the roller board track (prod. code: 11 201 5402).
The low platform can be used as free-standing platform, together with further Sport-Thieme platforms or with the Sport-Thieme rolling bar slide. There is no guarantee for the combination with products from other manufacturers.
6
sport-thieme.com · [email protected]
a
b
3.3 Assembly instructions Illustration 8 shows an exploded view drawing of the platform elements in assembly position.
Follow ill. 8 and put the parts a to c together for assembly, screw together using the included hex key and sleeve nuts (see ill. 8 and 9).
The low platform comes with pre-drilled holes for the hinges or the roller board track stop strip on opposite sides.
It is up to you whether you want to attach a roller board track on the left, on the right or on both sides. 4 plastic spacers and screws for assembling the platforms are included.
Abb. 9: screw connection
3.4 Safety
· Only use the platform under supervision. · The platform is not fixed to the floor. · Improper use can lead to a risk of tipping! · The maximum load is 1.5 kN (150 kg).
3.5 Maintenance and inspection
A visual inspection must be carried out before each use. The low platform is only suitable for its intended use. Improper use voids the warranty.
7
Operating/assembly instructions
Rolling bar slide
4. Sport-Thieme rolling bar slide Length 2 m: 11 200 5805; length 2.5 m: 11 200 5818; length 3 m: 11 200 5821
Abb. 10: rolling bar slide
Operating/assembly instructions
5.Buck for rolling bar slide 11 262 1409
Abb. 11: rolling bar slides with buck
Rolling bar slide
4.1 Includes: The rolling bar slide is completely pre-assembled. It consists of 2 wooden sides and padded rolling bars with easy-to-clean, smooth surfaces in-between. The number of bars depends on the length of the rolling bar slide.
4.2 General The rolling bar slide is a very popular piece of apparatus. It promotes the urge to move around. The rolling bar slide is available in 3 lengths. The rolling bar slide is designed for attaching to the Sport-Thieme high platform (prod. code: 11 201 7411), to the SportThieme `Universal’ platform (prod. code: 11 201 7424) to Varianta vaulting boxes (prod. code: 11 129 7906, 11 129 7919) or to wall bars. It should not be attached to square bars as this can damage the sides.
The rounded attachment holes in the sides of the rolling bar slide enable free adjustment of the incline. The lower side ends are rounded to protect the floor. There is no guarantee when combined with products from other manufacturers.
4.3 Assembly instructions Attach the rolling bar slide to the respective rung. Ensure safe positioning of the slide.
4.4 Safety · The rolling bar slide must only be used under supervision. · Place fall protection mats around the slide to prevent injuries! · The maximum load is 1.5 kN (150 kg). · Do not reach between the rolling bars! · The rolling bar slide must only be used when sitting or lying. · Do not stand on the slide! · Use: barefoot, with plimsolls or flexible trainers. · In order to prevent damage to the hygienic surface of the foam rolling bars, ensure that no sharp or pointed objects can damage the rolling bars.
4.5 Maintenance and inspection A visual inspection must be carried out before each use. The six screws on the sides must be retightened if necessary. The rolling bar slide is only suitable for its intended use. Improper use voids the warranty.
8
sport-thieme.com · [email protected]
Abb. 9: Bock für Rollenrutschbahn
5.1 General This buck makes it easy to connect two rolling bar slides. This extends the rolling fun. Simply attach one end of the first rolling bar slide to wall bars, to a Sport-Thieme trapeze buck (prod. code: 11 220 7823) or to another piece of apparatus that is designed for this purpose. Then, attach the other to the buck’s top rung. The second rolling bar slide can now be attached to the second rung from the top. Should you have an older model of the rolling bar slide with only one attachment point, use this as the bottom element. 5.2 Safety
· Only use the buck under supervision. · The buck is not fixed to the floor. · Improper use can lead to a risk of tipping! · The maximum load is 1.5 kN (150 kg). 5.3 Maintenance and care instructions Carry out a visual check at regular intervals. Due to our continuous quality control of the products, technical changes may occur which may lead to slight deviations in the instructions. Check at regular intervals that the screw connections are tight. Check the equipment for possible damage and replace worn-out parts. Check the condition of wooden elements as chipping and other signs of wear can result from use. Caution: Do not overload the equipment! Maximum load 100 kg.
9
Operating/assembly instructions
6. Roller board track 11 201 5402
Abb. 12: roller board track with low platform
Roller board track
b
a
Low platform
6.1 When you open the package, please ensure all the necessary parts are included: a 1x roller board track 0.6 x 1.5 m b 1x stop strip c 1x hinge d 1x safety pin with rubber tensioning cord e 2x coach bolt M6 x 45 with washer and nut f 5x countersunk bolt with locking nut
6.2 General The roller board track a can only be used in combination with the Sport-Thieme low platform (prod. code: 11 201 7408) (see ill. 12). Alternatively, attachment to a rung is possible using attachment hooks (prod. code: 11 128 5664). The roller board track a is completely pre-assembled. It consists of two guide rails on the sides and a rolling track. The upper hinge half is also pre-assembled. You can attach the roller board track to the left or the right side of the low platform. The required holes are pre-drilled. There is no guarantee when combined with products from other manufacturers.
10
sport-thieme.com · [email protected]
Operating/assembly instructions
Abb. 13: mounting the roller board track to the platform
e
g
Roller board track
b f c
Abb. 14: mounting the safety pin
d
a
f
6.3 Assembly instructions Follow ill. 13 and screw the loose hinge part c underneath the cover of the low platform g Use the countersunk bolts with the locking nuts.
On the platforms’ g opposite side, attach the stop strip b using coach bolt, washer and nut e (see ill. 13).
The stop strip b is designed to prevent slipping off the platform g with the roller board. Once everything is assembled, attach the roller board track a.
Insert the safety pin d into the hinges’ holes and secure using the rubber tensioning cord.
6.4 Safety · The roller board track must only be used under supervision. · Place fall protection mats around the platform and the roller board track to prevent injuries. · The maximum load is 1.5 kN (150 kg).
6.5 Maintenance and inspection A visual inspection must be carried out before each use.
When attaching the roller board track a ensure that the safety pin d is secured using the included rubber tensioning cord with hook.
The roller board track is only suitable for its intended use. Improper use voids the warranty.
11
Operating/assembly
The Sport-Thieme `rolling bar / roller board track system’ is a particularly versatile and motivating piece of sports and gymnastics equipment for nurseries, schools and therapeutic facilities that is great for integration into movement landscapes.
The individual components can be combined in a variety of ways. The slides can be attached to the platform on one or two sides.
You can set up an endless row of high and low platforms connected by slides.
Wall bars with rolling bar slides
12
`Universal’ platform with rolling bar slide sport-thieme.com · [email protected]
