EC 1046 Capiz and Wood Bead Wall Sconce
Product Information:
The 10L X 18H Capiz & Metal Wall Sconce w Beads, Matte Gold
EC 1046 is an indoor lighting fixture that comes with all the
necessary parts required for installation. The package includes 1
pc fixture (A), 2 pcs mounting screws (E), 1 pc lamp holder (B), 3
pcs plastic wire connectors (F), 3 pcs canopy screws (C), 1 set
shoebox canopy G (G1 and G2), 1 pc ground screw (D) and a bulb (H)
which is not included. The fixture is rated for one (1) 7watt
maximum TYPE B standard incandescent light bulb. The product is
made in the Philippines.
Product Usage Instructions:
- Before starting the installation, make sure the power to the
circuit is turned off at the main fuse box/circuit breaker utility
box. - Separate Shoebox Canopy (G) from fixture (A) by removing the
three small screws (C). Do not discard small screws (C), as these
will be used later. - Separate Shoebox Canopy (G), G1 and G2.
- Gently pull existing wire down from the wall junction box and
allow it to hang. - Attach the Shoebox Canopy (G2) to the ceiling outlet box using
the J-box Mounting Screws (E). Tighten screws with a
screwdriver. - Carefully inspect the Fixture’s wires. The NEUTRAL FIXTURE WIRE
is White insulation. The HOT wire is Black insulation. The GROUND
wire is Green or Bare Copper insulation. Connect the wires as
follows: Connect White fixture wire to White supply wire, Black
fixture wire to Black supply wire, and Green or Bare Copper fixture
wire to Green or Bare Copper supply wire. - Use the plastic wire connectors (F) to secure the connections.
Twist each connector clockwise until tight. Tug gently on each
connection to ensure a secure connection. - Attach the Fixture (A) to the Shoebox Canopy (G2) using the
three small screws (C). - Install the bulb (H) by carefully inserting it into the lamp
holder (B). To avoid the risk of fire, do not exceed the
recommended wattage. - Turn on the power to the circuit at the main fuse box/circuit
breaker utility box.
Important Safety Instructions:
- This product must be installed in accordance with the
applicable installation codes by a person familiar with the
construction and operation of the product and the hazards
involved. - Professional installation is required. It is recommended that
two (2) people install this lighting fixture. - The lighting fixture is meant for indoor use, damp or dry
location. - It must be connected only to 3-wire, single-phase electrical
supply systems (provided with Ground wire or equivalent protection
system). - To reduce the risk of fire, electrical shock or personal
injury, always turn off light fixture and allow it to cool prior to
replacing light bulb. - Do not touch bulb when fixture is turned on. Do not look
directly at lit bulb. Keep flammable materials away from lit
bulb. - This lighting fixture contains lead, a chemical known to the
State of California to cause cancer, birth defects and other
reproductive harm. Wash hands after installing, handling, cleaning
or otherwise touching this light fixture.
Care Instructions:
- Always turn off power to fixture before cleaning.
- Wipe clean with a soft, dry cloth or static duster.
- Do not use harsh chemicals or abrasive cleaners as they may
cause damage to the fixture’s finish.
10″L X 18″H Capiz & Metal Wall Sconce w Beads,Matte Gold EC 1046
G1 G2
Parts required (all parts included inside package unless otherwise indicated. Please check packaging for parts.)
1 pc fixture (A)
2 pcs mounting screws (E)
1 pc lamp holder (B)
3 pcs plastic wire connectors (F)
3 pcs canopy screws (C)
1 set shoebox canopy G)- (G1 and G2)
1 pc ground screw (D)
1 pc bulb (H) – not included
Tools Required: (not included)
1. Electrical Tape 2. Philips Screwdriver 3. Wire Cutters 4. Pliers 5. Step Ladder
Before installing fixture, make sure the power to the circuit is TURNED OFF at the main FUSE BOX
/ CIRCUIT BREAKER utility box.
IMPORTANT SAFETY INSTRUCTIONS:
**These instructions are provided for your safety. Read carefully and completely before beginning the assembly and installation.**
1. THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODES BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
2. PROFESSIONAL INSTALLATION REQUIRED. It is recommended that two (2) people install this lighting fixture.
3. The lighting fixture is meant for indoor use, damp or dry location. 4. It must be connected only to 3-wire, single-phase electrical supply systems (provided with Ground
wire or equivalent protection system). 5. This fixture has been rated for one (1) 7watt maximum TYPE B standard incandescent light bulb (not
included). To avoid the risk of fire, do not exceed the recommended wattage. 6. To reduce the risk of fire, electrical shock or personal injury, always turn off light fixture and allow it to
cool prior to replacing light bulb. 7. Do not touch bulb when fixture is turned on. Do not look directly at lit bulb. 8. Keep flammable materials away from lit bulb.
9. This lighting fixture contains lead, a chemical known to the State of California to cause cancer, birth defects and other reproductive harm. Wash hands after installing, handling, cleaning or otherwise touching this light fixture.
PRE-ASSEMBLY:
Remove all parts and hardware from box along with any plastic protective packaging. Do not
discard any contents from the packaging until after assembly is complete, to avoid accidentally discarding small parts or hardware.
Carefully unpack all fixture parts and hardware and lay out on a clear workspace.
INSTALLATION INSTRUCTIONS:
1. SHUT OFF THE MAIN ELECTRICAL SUPPLY FROM THE MAIN FUSE BOX/CIRCUIT BREAKER! 2. Separate Shoebox Canopy (G) from fixture (A) by removing the three small screws (C). Do not
discard small screws (C), as these will be used later. 3. Separate Shoebox Canopy (G), G1 and G2. 4. Gently pull existing wire down from the wall junction box and allow it to hang. 5. Attach the Shoebox Canopy (G2) to the ceiling outlet box using the J-box Mounting Screws (E).
Tighten screws with a screwdriver. 6. Carefully inspect the Fixture’s wires. The NEUTRAL FIXTURE WIRE is White insulation. The HOT
FIXTURE WIRE is Black insulation, and the GROUND WIRE is Green-Yellow insulation. If you have any doubt and cannot identify the power-supply wires with confidence, then we recommend that you ask an electrician and that you not continue with the installation. 7. Attach the GROUND WIRE from the fixture to the GROUND JUNCTION BOX WIRE from the outlet junction box (J-box) (usually green insulation or bare wire). Fasten each together with a Plastic Wire Connector (F) by twisting the connector in a clockwise direction and wrap the connection with electrical tape. Be sure that no wire strands are exposed. If your outlet junction box DOES NOT have a GROUND WIRE, be sure to insert the Green Ground Screw (D) into Shoebox Canopy (G2) marked as “GND” and wrap the fixture’s bare ground wire around the Green Ground Screw (D). IT IS IMPERATIVE THAT THE JUNCTION BOX IN YOUR HOME IS PROPERLY GROUNDED! 8. Connect the NEUTRAL FIXTURE WIRE to the NEUTRAL JUNCTION BOX WIRE (usually white insulation). Fasten each together with a Plastic Wire Connector (F) by twisting the connector in a clockwise direction and wrap the connection with electrical tape. Be sure that no wire strands are exposed. 9. Connect the HOT FIXTURE WIRE to the HOT JUNCTION BOX WIRE (usually black insulation). Fasten each together with a Plastic Wire Connector (F) by twisting the connector in a clockwise direction and wrap the connection with electrical tape. Be sure that no wire strands are exposed. DO NOT REVERSE THE HOT AND NEUTRAL CONNECTIONS OR SAFETY WILL BE COMPROMISED. 10. Gently tuck the wire connections neatly into the Shoebox Canopy (G). 11. Attached shoebox Canopy (G1) at Shoebox canopy (G2), insert small screw (C) at the bottom and tighten with a screwdriver. 12. Attached Shoebox Canopy (G) into Fixture (A). Insert the two small screws (C) and tighten with a screwdriver. 13. Insert one (1) 7-watt bulb (not included). 14. Restore power to junction box and test fixture. 15. Installation is complete.
CARE INSTRUCTIONS:
Always turn off power to fixture.
Wipe clean with a soft, dry cloth or static duster.
Do not use harsh chemicals or abrasive cleaners as they may cause damage to the fixture’s finish.
MADE IN PHILIPPINES
