HBL16PB Heavy Duty Industrial Weatherproof Reels
Product Information:
The Cable, Cord and Hose Reels are heavy-duty industrial
weatherproof reels designed for use in dry, indoor, and wet and
damp outdoor non-hazardous locations. They come in various sizes
and configurations to meet different needs. The reels are UL 355
and CSA certified and have a Type 4X enclosure.
Features and Benefits:
- Can rotate 360 degrees, allowing the cable to be directed in
any direction - Weatherproof design ensures protection against the
elements - Available in yellow or white housing
- Comes with various cable lengths and types
- Heavy-duty construction for durability
Accessories:
- 14 Pivot Base (Catalog Number: HBL14PB)
- 16 Pivot Base (Catalog Number: HBL16PB)
- Replacement Stop (Catalog Number: HBLWPBS)
Specifications:
The dimensions of the 14 Reel are as follows:
- A: 6.50 inches (165 mm)
- B: 8.12 inches (206 mm)
- C: 16.25 inches (413 mm)
- D: 13.75 inches (349 mm)
- E: 3.00 inches (76 mm)
- F: 12.19 inches (310 mm)
- G: 3.00 inches (76 mm)
- H: 3.00 inches (76 mm)
- I: 3.00 inches (76 mm)
- J: 6.50 inches (165 mm)
The dimensions of the 16 Reel are as follows:
- A: 6.50 inches (165 mm)
- B: 9.12 inches (232 mm)
- C: 18.25 inches (464 mm)
- D: 15.75 inches (400 mm)
- E: 3.00 inches (76 mm)
- F: 14.19 inches (360 mm)
- G: 6.00 inches (152 mm)
- H: 6.00 inches (152 mm)
- I: 4.94 inches (125 mm)
- J: 6.50 inches (165 mm)
Note: The pivot base is designed for use only with the
Weatherproof Cable Reel.
For more information, visit www.hubbell.com/wiringdevice-kellems/en
Product Usage:
To use the Cable, Cord and Hose Reels, follow these steps:
- Choose the appropriate reel size and configuration based on
your requirements. - Ensure that the location where the reel will be used is dry,
indoor, or wet and damp outdoor non-hazardous. - Connect the desired cable length and type to the reel.
- If needed, attach the pivot base to the reel using the
appropriate catalog number (HBL14PB for 14 Reel, HBL16PB for 16
Reel). - Mount the reel on a suitable surface using the provided
mounting holes. - Ensure that the reel is securely mounted and can rotate 360
degrees. - Direct the cable in the desired direction by rotating the
reel. - Make sure to handle the cable, cord, or hose with care to avoid
damage.
For any further information or troubleshooting, refer to the
user manual or contact customer support.
Cable, Cord and Hose Reels
Features and Benefits
Heavy Duty Industrial Weatherproof Reels · Powder coated, solid U.S. steel construction · Multi-position roller guide can be mounted in four different positions · Ratchet lock can be disengaged in field for constant tension application · UL Type 4X enclosure protects spring motor, junction box, slip ring
assembly and cable entrance from hosedown or corrosion · Optional pivot base allows 340° rotation of reel and increases range
of cable to nearly any direction
HBL501242W with HBL16PB
Heavy Duty Industrial Weatherproof Reels*
Description 14″ yellow weatherproof reel
16″ weatherproof reel yellow housing white housing
Amps 15 20
Cable Length Volts AC Feet (m) Cable Type
600 50 (15.2) 14/3 SOW-A
600 50 (15.2) 12/3 SOW-A
16″ yellow weatherproof reel
16
600
50 (15.2) 12/4 SOW-A
16″ weatherproof reel yellow housing 25
600
50 (15.2) 10/3 SOW-A
white housing
16″ yellow weatherproof reel
20
600
50 (15.2) 10/4 SOW-A
Weight Lbs. (kg) Catalog Number 55 (24.9) HBL501431W
80 (36.3) HBL501232W HBL501232WM1
86 (39.0) HBL501242W
86 (39.0) HBL501032W HBL501032WM1
92 (41.7) HBL501042W
HBL501232WM1
Note: *All heavy duty industrial cord reels are supplied with wire leads and ¾” NPT hub feed. Power supply cable not supplied.
Accessories
Description 14″ pivot base. 16″ pivot base. Replacement stop.
Weight Lbs. (kg) 5 (2.3) 13 (5.9) .2 (.09)
Catalog Number HBL14PB HBL16PB HBLWPBS
HBL501242W with HBL16PB
Specifications
Listing/Certification
Environment
Dimensions
Inch (mm) 14″ Reel
16″ Reel
A 6.50″ (165) 6.50″ (165)
UL 355 and CSA, C22.2 No. 308. Type 4X enclosure, CAN/CSA – C22.2 No. 308. Dry, indoor and wet and damp outdoor non-hazardous location.
B 8.12″ (206) 9.12″ (232)
C 16.25″ (413) 18.25″ (464)
D 13.75″ (349) 15.75″ (400)
E 3.00″ (76) 3.00″ (76)
F 12.19″ (310) 14.19″ (360)
G 3.00″ (76) 6.00″ (152)
H 3.00″ (76) 6.00″ (152)
I 3.00″ (76) 4.94″ (125)
J 6.50″ (165) 6.50″ (165)
HBL14PB HBLWPBS
A Ø D
Line Entrance ¾” NPT
Pivot Base E
340° Pivot Base (Optional)
B C
F
H
G
Mounting Surface 4 Holes
14″ 0.44 (11) diameter
16″ 0.53 (13) diameter
Reel Base 4 Holes
I
J
14″ 0.47 (12) diameter 16″ 0.53 (13) diameter
Note: Pivot base for use only with Weatherproof Cable Reel.
Dimensions in Inches (mm)
www.hubbell.com/wiringdevice-kellems/en
®
Wiring Device-Kellems
K-5
