Baudcom Bd-onu-114g-be+ Gpon Poe Onu Device Owner's Manual

BD-ONU-114G-BE+ GPON PoE ONU Device

Product Information

Product Usage Instructions

To use the BD-ONU-114G-BE+ 4GE PoE GPON ONT, please follow these
instructions:

1. Connect the BD-ONU-114G-BE+ to a power source using the
   provided DC48V external power supply.
2. Connect the GPON ONU to your network using the SC/PC PON
   connector.
3. Connect your devices to the 4 fixed 10/100/1000Mbps
   auto-adapted PoE ports.
4. If your devices support IEEE802.3af or IEEE802.3at standard,
   the BD-ONU-114G-BE+ will automatically discover them and supply
   power.
5. Configure and manage the GPON ONU by cooperating with the
   center OLT. This allows you to implement management configuration
   and software upgrades.

Please refer to the user manual or contact SHANGHAI BAUDCOM
COMMUNICATION DEVICE CO.,LTD for further assistance.

Website: www.baudcom.com.cn

Email: [email protected]

Tel: +86 21 37709251

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD

Model: BD-ONU-114G-BE+

4GE PoE GPON ONT

Overview The GPON ONU is type POE product, with 4 fixed 10/100/1000Mbps auto-adapted POE ports. It
supports IEEE802.3af 15.4W and IEEE802.3at 30W POE standards. It can auto discovery the power receiving devices which support IEEE802.3af/at standard and supply power to it.
To the connected devices which not support PoE, it will auto stop supplying power. The ONU supports to work with IP camera, IP phone, wireless AP and other network devices, and supply power to these devices. It works with central device OLT to implement integrated management, long-distance fault location and decrease maintenance workload. It is metal casing design and suitable for FTTB/FTTH. It is mainly applied to security surveillance, smart city,tunnel monitoring, coal mine network etc. Feature
Apply to ITU-T G.984/G.988 Support auto discovery and auto register (real-time operation) Support DBA and multi types SLA Support IGMP Snooping V2 multi-broadcast function Support EMI and ESD identification Support VLAN Support powerful OAM and remote management Support state detection and fault location Support power failure alarm Each PoE port supports to auto discovery the standard power receiving devices Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
Website: www.baudcom.com.cn Email: [email protected] Tel: +86 21 37709251

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD

Technical Parameter

Parameter

Specification

Wavelength

1310TX/1490RX

Optical power

-1~+4dBm

Receiving sensitivity

-25dBm

Max transmission distance

20 km

Space of buffer storage

1.25MB

MTBF

100,000 hours

PON connector

SC/PC

Support IEEE802.3ah

PON trait

Support Dynamic Bandwidth Allocation (DBA) Support ONU auto-searching and automatic registration (real-time

operation)

Support IEEE802.3, IEEE802.3u

Standard and Protocol

IGMP Snooping V2 Support IEEE802.1q WLAN

Support IEEE802.1p QOS

Supplying power port: 4 ports

POE

Standard: IEEE802.3af 15.4W, IEEE802.3at 30W Working mode: auto discover and power/dis-power receiving power

device

Network management

Cooperating with center OLT, implement management configuration and software upgrade to ONU

Working Environment

Parameter

Specification

Power

DC48V (external)

Power consumption

4.5W, Max POE supplying power 120W

Operating temperature

-2070

Storage temperature

-4085

Humidity

5%90% non-condensing

Dimension

31mm(H)×126mm(W)×123mm(D) (external)

Weight

0.43Kg

Order information: BD-ONU-114G-BE+ 4GE GPON ONT, metal case, poe, with power adapter

Website: www.baudcom.com.cn Email: [email protected] Tel: +86 21 37709251

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Email: [email protected] Tel: +86 21 37709251
